- Corded remote and mini-rocker control with universal mounting bracket
- 55-feet long and 0.03-inch wide aircraft-grade wire rope
- Has sealed all-metal 3-stage planetary geartrain
- Electrical system for long pulls and less battery drain
- 4000 pound line capacity
See all vehicles this product fits.
Product Features |
Frequently Bought Together
Product Details
Would you like to give feedback on images?
|
Product Specifications
| Product Information | |
| Brand: | Warn |
| Manufacturer Part Number: | 77000 |
| Sizing and Specifications | |
| Item Weight: | 34 Pounds |
| Height: | 6.10 inches |
| Length: | 17.80 inches |
| Width: | 13 inches |
Product Description
Amazon.com Product Description
Riders looking for on-the-job performance and outstanding durability will want the RT40 for their Side X Side. The winch showcases 4,000 lbs. of pulling muscle and 55 feet of durable wire rope--the longest in the WARN Powersports lineup. This winch has tons of standard features including a patented disc brake for great control, a fully sealed drivetrain, a reliable and smooth all-metal 3-stage planetary geartrain, short-throw clutch, a corded remote and mini-rocker control switch for winch operation, and an efficient electrical system for long pulls and less battery drain.
Powerful winching for extreme rescuesThe Importance of Winch Sealing
Powersports winches see a wide variety of conditions including water, mud, dirt, and sand. These outside forces are constantly trying to get inside your winch--the more that gets in, the less reliability, durability, and performance the winch has.
The best way to keep the elements out of your winch is to buy a product that is well sealed. WARN RT/XT 25, 30, and 40 series winches are designed from the ground up with full sealing to provide the best protection from the worst that Mother Nature can throw at you.
WARN places eight specifically designed seals at locations where water and debris are prone to enter, allowing the winch to operate at its peak performance. Some areas, such as the winch drum, are even double sealed for extra protection. These features ensure that WARN Powersports winches are the most weather-resistant, reliable, and best-performing winches you can buy.
When you're looking to buy a winch, don't fall for claims of waterproofing. You want a product that is designed and engineered for the ultimate in performance, reliability, and durability. Get the best-sealed and highest-performing winches on the market: Get a WARN winch and Go Prepared.
About Warn
Warn Industries designs, manufactures and markets a full line of off-road equipment and accessories that enhance the performance of four-wheel-drive vehicles, ATV's and utility vehicles. In addition, the company's Industrial Division markets electric and hydraulic winches and hoists to commercial, industrial and severe duty customers around the world. The company also has a line of utility winches and hoists that are specifically designed for professional trade workers and do-it-yourself consumers who need powerful tools to assist them in pulling, hauling, dragging or lifting. Warn has four divisions focused on specific customers and markets (WARN Truck & Auto, Power Systems, Industrial, and Powersports). With customers in more than 65 countries on six continents, Warn is one of the world's most recognized brands in vehicle performance enhancing equipment.
Technical Specifications
- Rated Line Pull: 4000 lbs. (1814 kgs)
- Motor: 12V DC, 1.5hp (1.1 kW) permanent magnet
- Controls: Corded remote and mini-rocker control with universal mounting bracket
- Geartrain: Sealed, all-metal 3-stage planetary
- Gear Ratio: 136:1
- Clutch (freespooling): Sliding pin and ring gear
- Brake: patented disc brake
- Drum Diameter/Length: 2.0"/4.7" (52mm/119mm)
- Fairlead: Roller
- Rope: 55' Aircraft-grade Wire, 7/32" diameter (16.8m, 5.5 mm diam.)
- Recommended Battery: 14 amp/hour minimum
- Battery Leads: 6 gauge
- Duty Cyle: Intermittent
- Winch Weight: 14.4 lbs. (6.5 kgs)
Product Description
Warn RT40 Rugged Terrain 4000 pound Winch is designed specifically for UTVs. The RT40 has a massive 4000 pound line capacity and the longest wire rope in the Warn Powersports winch lineup to facilitate pulling heavier loads farther. This winch has tons of standard features including a patent-pending disc brake that holds strong on inclines, a fully sealed gear train to guard against the elements, a reliable and smooth-running all-metal 3-stage planetary gear train, a corded remote, mini-rocker control and an efficient electrical system for long pulls and less battery drain.
