Calculated Industries 4065 Construction Master Pro Advanced Construction Math Calculator

by Calculated Industries

Product Description

From the Manufacturer

More sophisticated and easier to use than ever before, the Construction Master Pro Advanced Construction-math Calculator from Calculated Industries is the most complete builder's calculator on the market! Designed for builders, general contractors, carpenters, framing contractors, concrete/foundation contractors, remodelers and other construction professionals, the Construction Master Pro features powerful new built-in solutions for more accurate bids and less waste. Perfect for completing layouts, bids and estimates, the Construction Master Pro saves time, money, materials and frustration by quickly converting all building dimensional formats with custom-set fractions. Your purchase includes a protective hard case, user guide, field guide and long life.

FEATURES

• Dimensional Math and Conversions
• Work Directly in Feet, Inches, Fractions, Yards and Metric
• Handles All Fractions: 1/2, 1/4, 1/8, 1/16, 1/32, 1/64's
• Instant Area and Volume
• Easy Right Angle and Rafter Calculations Including Slopes, Square-Ups
• Common Rafter Lengths
• Regular and Irregular Hip/Valley Rafter Lengths
• Regular and Irregular Jack Rafter Lengths
• Complete & Enhanced Stair Riser/Tread Solutions
• Board Feet/Lumber Estimation
• Per Unit Material Cost
• Six Material Estimation Functions: Block, Brick, Column, Cone, Footing, Roof
• Custom Rafter Settings
• Ascending or Descending Lengths
• Plumb, Level and Cheek Cut Angles
• Improved Rake Wall Function
• Advanced Circle Solutions
• D:M:S to Decimal Degree Conversions
• Acres, Kilograms, Pounds, Tons and Metric Tons Conversions
• Handy Backspace Key
• Memory Storage Keys
• User Set Preferences
• Paperless Tape
• Works as a Regular Calculator

SPECIFICATIONS

• Size: 5.6 x 3.0 x 0.6" (142.2 x 76.2 x 15.2 mm)
• Product Weight (Including Case and Pocket Reference Guide) 4.5 oz. (127.5 g)
• Power: Two 1.5-Volt Alkaline Batteries (LR-44/A76)
• Battery Life: Approx. 1-2 years of actual usage
• Auto Shut-off: 8-12 min.
• Keypad: 42 keys, soft-touch silicone rubber
• Pocket Reference Guide: 36 pp.; 2.4 x 4" (60.9 x 101.6 mm)
• Case: Protective hard case; black
• Operating Temperature: 32-130 deg. F (0-55 deg. C)
• Display Type: LCD segment; 11 digits (7 normal, 4 fractions), with annunciator-legends
• Display Dimensions: 0.63 x 2.5" (16.0 x 63.5 mm)
• Accuracy: 10 digit internal accuracy

Product Description

Advanced construction/math calculator is packed with solutions for building professionals. Calculates sheets of building material needed, solutions for stairs, roofing materials, compound miter cut angles, materials estimates and more. Also features cost per unit, multiple memory, exponential notation, backspace, user preferences. Stores last 20 entries. Standard calculations and auto shutoff. Perfect for completing layouts, bids and estimates. Calculates: dimensional math and conversions, right angle solutions, area and volume solutions, and various special functions. Model 4065.

Product Details

• Product Dimensions: 6 x 3 x 1 inches ; 14.4 ounces
• Shipping Weight: 14.4 ounces (View shipping rates and policies)
• Shipping: This item is also available for shipping to select countries outside the U.S.
• ASIN: B0007Q3RGQ
• Item model number: 4065
• Average Customer Review: 4.6 out of 5 stars  See all reviews (24 customer reviews)
• Amazon Best Sellers Rank: #5,969 in Home Improvement (See Top 100 in Home Improvement)

Customer Reviews

Most Helpful Customer Reviews

35 of 36 people found the following review helpful:

5.0 out of 5 stars Increases accuracy and productivity, May 12, 2007

By

Christopher Kennel "remodel carpenter" (Denver, CO United States) - See all my reviews
(REAL NAME)

Amazon Verified Purchase

This review is from: Calculated Industries 4065 Construction Master Pro Advanced Construction Math Calculator (Tools & Home Improvement)

Fine Homebuilding recently ran an article about framing a dormer that included step-by-step instructions about how to use this calculator to generate complete measurements to do much of the framing in advance on the ground. After reading the article and watching a framer I sometimes work with use one to run circles around truss manufacturing company representatives, I decided it was time to buy one for my own use.

I have a science background so I initially leaned toward buying the more expensive trig model, but decided on the regular one because it has the following features not available on the trig model: quantity estimators for various sizes of drywall sheets; volume estimators for concrete footers, slabs, & circular piers; and estimators for various sizes of brick and blocks. I carry a Palm Pilot with me that has trig functions in case I need them, but for the remodeling work I do, I haven't needed any trig values now that I no longer manually do trig calculations. The calculator can generate angles, hypotenuse lengths, side lengths, areas, volumes, etc. based on a few known quantities. For example, if two sides of a triangle (can be regular sides or one side and a hypotenuse) are known, it'll give the angle / pitch. Likewise, if the angle and one side are known it'll generate lengths for the other two sides. I've found that I no longer have a need for trig values since blueprints and field measurements only involve lengths and angles / pitches which this calculator is set up to work with.

A different reviewer was bothered that this calculator rounded to the nearest 1/16th of an inch. That's the default factory setting, but it can easily be changed to a different accuracy level all the way down to 1/64th of an inch. I keep mine set to 1/32th of an inch.

I've been using the Construction Master Pro on the job for about a month now and it has really sped up my calculations as well as helped avoid errors, especially when I'm tired. I occasionally use it to determine quantities of shingles and bricks needed for a job or to do complex calculations involving a variety of angles (it has crown molding functions for irregular walls that have replaced the charts I used to carry in my truck), but most of the time I use it for simple calculations like dividing measurements.

Here are two examples: I needed to put in a diagonal brace for a two-piece rack that held trim for a job so I just measured the height of one side of the rack and the horizontal distance between the two supports and the calculator gave me the length and plumb cut angles for my diagonal brace that went from the top of one side to the bottom of the other. This took about 10 seconds and my piece fit perfectly. To determine the number of shingles I needed for a roof, I entered length and width of the area below the roof and the roof's pitch and it calculated the area of the sloped roof as well as the number of squares and bundles of materials.

Other features that I find useful include: stair calculations (with some powerful features including limiting maximum riser heights, specifying various tread lengths, limiting the number of risers, etc.), hip / valley roof framing calculations, estimating the number of studs needed for a job, calculating rake wall stud cut angles and lengths, arc calculations, and squaring calculations (no more need to use multiples of 3-4-5; any numbers will do). Features I probably won't use much include board foot calculations, conical volumes, and tonnage calculations.

This calculator isn't a substitute for good construction knowledge and the ability to visualize the process, but it sure can help take these skills to the next level.

9 of 9 people found the following review helpful:

5.0 out of 5 stars Good Feature Set, Easy to Use, January 11, 2009

By

New England Yankee (Northern New England) - See all my reviews
(TOP 500 REVIEWER)

Amazon Verified Purchase

This review is from: Calculated Industries 4065 Construction Master Pro Advanced Construction Math Calculator (Tools & Home Improvement)

I bought this calculator for basic imperial (foot/inch) measurement system entry and math, including fractions, but have found that it excels in the feature set it offers - including circle, arc, area, volume, and right angle calculations. It also has a good conversion capability from imperial measurements to metric.

The calculations used by the built-in keys (e.g., for stairs, rafters, blocks, compound miter cuts, etc.) use common-sense default values - like 16" OC stud spacing, 6'8" stairway headroom, 16" blocks, 7 1/2" stair risers, etc. - but can be easily changed with a couple of simple keystrokes.

I found the built-in calcs very easy to learn and use. A lot of the dedicated function keys give you the results you want by just pushing the button more than once. Enter run and rise, for example, then push "DIAG" and it shows you the diagonal. Another push of "DIAG" gives you the plumb cut, and a third press gives you the level cut. Enter a circle diameter into "CIRC" and a press gives you area and a second press circumference. The rafter and jack calculations are particularly impressive, as successive presses give you the lengths of the entire series for the run, plus hip and valley lengths and bevels, all without entering any additional information.

The calculator is very flexible - you can enter values in any unit. Pitch, for example, can be entered in feet, inches per foot, degrees in two different formats, and so on. You can solve for missing values. Using pitch as an example again, if you enter pitch in degrees, along with the run, a press of "RISE" will solve for the rise.

The calculator itself is feather-weight, but appears to be made of a tough plastic. A slide-on cover is included, by the way - I didn't see the need to buy the flip-open optional cover. Whoever designed this calculator thought it out. There is actually storage for the printed pocket guide in the form of a built-in pocket on the back of the calculator. The slide-on cover also has basic instructions and a list of the default calculation values printed on it.

My only real complaint is that the printing above the keys for alternate functions accessed by the "CONV" and "STOR" key are light and hard to read. No problem in daylight, but indoor lighting makes it hard to read them. The keys themselves are good-sized, have a slightly rubbery texture, and have a good feel to them. The display is easy to read.

This is an excellent calculator, and it should satisfy anyone for virtually all routine carpentry, woodworking, and cabinetmaking needs. I went back and forth a few time trying to decide between this model and the trig model, but this one has some built in calcs the trig model does not have, and I've found that this model's right triangle, circle/arc, and degree entry capabilities meet my geometric needs.

Amazon had the best price on this calculator that I'd seen to-date at the time I bought it.

5 of 5 people found the following review helpful:

5.0 out of 5 stars No case needed, September 25, 2009

By

Damian "A Mad Violation" (West Dover, VT) - See all my reviews

Amazon Verified Purchase

The calculator is fantastic. All I I'm going to say is don't buy the Armadillo case as is suggested. This package includes an Armadillo case.
