- Platform: Windows 7 / Vista / XP, Mac OS X 10.6 Snow Leopard
- Media: CD-ROM
- Item Quantity: 1
System Requirements
What Other Items Do Customers Buy After Viewing This Item?
Product Details
Would you like to update product info or give feedback on images?
|
Product Description
From the Manufacturer
Get a native DWG, high-performance CAD solution—without the high price—with new CorelCAD. Open, work with and save files in DWG format for easy collaboration with colleagues, suppliers, and partners. Be productive immediately in an environment filled with industry-standard features and tools. Communicate your ideas with precision using customizable 2D and 3D design tools. Innovative features like VoiceNotes* let you add messages and instructions in your drawing, and CorelDRAW and Corel DESIGNER compatibility* enhance collaboration. Plus, CorelCAD is built for both Windows and Mac OS, so it delivers impressive speed and performance on the platform of your choice.
* Windows version only
(view larger).
(view larger).
A True CAD Solution
Native DWG file format- Unlike many CAD tools that import and export DWG files, CorelCAD uses DWG as its primary drawing format. That means you can confidently exchange files with colleagues, suppliers, and partners for worry-free collaboration. CorelCAD supports DWG, DXF and DWF up to the current AutoCAD 2010 file format version.
Industry-standard CAD features- Be productive immediately in an environment filled with familiar features and tools. CorelCAD is compatible with all major CAD programs, so experienced users will feel comfortable with the familiar command bar, command aliases, and menu and toolbar items. Dockable toolbars, right-click shortcut menus and a Properties palette are also included to help you work more efficiently.
Legacy file format support- Save drawings back to R12 DWG or DXF format, and recover damaged DWG and DXF files in all format versions.
Precision 2D Drafting Tools
Smart editing tools- Work faster with CorelCAD smart tools, such as entity snap, entity snap guides, and polar guides. Entity grips let you quickly reposition, align, copy or resize entities.
Properties palette- Manipulate entity attributes, such as layer, color, line style, and more with the Properties palette or copy properties from other entities.
Custom coordinates- Create custom coordinate systems to align the construction plane to drawing objects.
3D Modeling Tools
3D modeling tools- Add 3D solid primitives to your design and use Boolean operations to unite, intersect, and subtract bodies.
From 2D to 3D- Extrude or revolve 2D entities, sweep 2D entities along a path, or loft between 2D entities to create solid objects.
Editing solids- Slice and intersect solids, and edit edges, faces, and bodies of 3D solids.
Compatibility for a Smoother Workflow
Easy file sharing- Collaborate and share more easily with colleagues and clients with support for leading formats, including PDF, SVG, ACIS, SAT, and DWF.
CorelDRAW and Corel DESIGNER compatibility- Export to CorelDRAW X5 (CDR) and Corel DESIGNER X5 (DES)* formats to easily re-purpose your work in presentations and marketing-related deliverables.
Annotation and collaboration- Take collaboration a step further with the innovative VoiceNotes* tool, which lets you add recorded messages, reminders or instructions directly in your drawing. You can also easily mark up drawing items with freehand sketches and mask portions of a drawing to exempt them from annotations.
Automation and Custom Enhancements
Extend your productivity- Take advantage of support for LISP and Microsoft Visual Studio Tools for Applications (VSTA)* to create your own functions, routines and plug-ins in the CorelCAD automation interface.
Add-ons and enhancements- Access the plug-in store* for third-party enhancements to CorelCAD that can help you automate tasks or add new functionality to the application.
Interface customization- Create and store multiple configurations of the interface in user profiles—no programming knowledge required. Aliases for frequently used commands also help speed you through common tasks.
*Export to CorelDRAW (CDR) and Corel DESIGNER (DES) file formats, VoiceNotes, Microsoft VSTA and access to the plug-in store are only available in CorelCAD for Windows.
System Requirements
Windows Version
- Microsoft Windows 7, Windows Vista, or Windows XP with latest Service Pack (32-bit or 64-bit editions)
- Intel Pentium 4 processor (2 GHz or faster)
- 1 GB RAM (2 GB or higher recommended)
- 500 MB hard disk space
- High Color (16 bit) graphics card (3D graphics accelerator card recommended)
- 1024 x 768 screen resolution (768 x 1024 on a Tablet PC)
- Mouse or Tablet
- CD-ROM drive for installation from CD
- Internet connection for product activation and access to the plug-in store
(view larger).
Macintosh Version
- Apple Mac with Intel processor
- Mac OS X v10.5.8 (Leopard ) or v10.6.x (Snow Leopard )
- 1 GB RAM (2 GB recommended)
- 2 GB hard disk space
- 1024 x 768 display (1280 x 800 recommended) with 16-bit video card
- Mouse or Tablet
- CD-ROM drive for installation from CD
- Internet connection for product activation
(view larger).
Product Description
Get a native DWG, high-performance CAD solution—without the high price—with new CorelCAD. Open, work with and save files in DWG format for easy collaboration with colleagues, suppliers and partners.
