Technical Details
Style: H80
- Push-button fan control so you can select the fan speed and cooling performance that best suits your needs.
- Double-thick 120mm radiator for increased surface area and cooling potential.
- Two all-new 120mm fans optimize static pressure and airflow for amazing performance.
- FEP tubing provides extraordinarily low coolant evaporation levels.
- A new improved micro-channel cold-plate design more efficiently transfers heat.
- A new improved micro-channel cold-plate design more efficiently transfers heat
- Double-thick 120mm radiator for increased surface area and cooling potential
- FEP tubing provides extraordinarily low coolant evaporation levels
- Includes mounting hardware compatible with all modern CPU socket designs
- Push-button fan control so you can select the fan speed and cooling performance that best suits your needs
- Quick and easy installation brackets make it easier than ever to upgrade to watercooling.
- Two all-new 120mm fans optimize static pressure and airflow for amazing performance
Product Details
Would you like to update product info or give feedback on images?
|
Product Description
Style: H80
Amazon.com Product Description
The Hydro Series H80 and H100: efficient cooling, simple installation, and the power of Corsair Link Digital.
The digital fan control button allows you to select between Quiet, Performance, or Balanced modes.
Ready for Corsair Link Digital.
The H80 and H100 work great with Corsair Link, an ecosystem of hardware and software components designed to give you unprecedented control over your PC. Connect your H80 or H100 to the Corsair Link Commander (available separately) and monitor a wide range of parameters, including pump speed, coolant temperature, and fan speed, and customize your own performance profiles.
Control at your fingertips.
The low-profile integrated pump and cold plate includes push-button control so you can select the fan speed and cooling performance setup that best suits your needs. The cool white LED display lets you know at a glance which profile is being used.
The Hydro Series H80 uses a double-thick radiator for efficient cooling.
The Hydro Series H80: Compact and quiet.
Featuring a full 240mm radiator and two 120mm fans, the Corsair Hydro Series H100 extreme performance liquid CPU cooler is designed to deliver cooling performance that meets the needs of even the most demanding enthusiast
The Hydro Series H100: Go long
Want even more? Featuring a full 240mm radiator and two 120mm fans, the Corsair Hydro Series H100 extreme performance liquid CPU cooler is designed to deliver cooling performance that meets the needs of even the most demanding enthusiast.
Corsair Hydro Series makes it easy to go liquid.
The H100 incorporates a 240mm radiator for extreme cooling performance..
Easy installation, zero maintenance.
You no longer need to invest into finicky modular watercooling systems to get serious CPU cooling performance. Each Hydro Series Liquid CPU Cooler is a sealed, closed-loop system that comes pre-filled and never needs refilling. Tubing is constructed from low-evaporation FEP for a long lifespan. Even the thermal compound is pre-applied. You'll be up and running in minutes.
The latest cooling technology.
Both the H80 and the H100 include a low-profile, light-weight cooling unit with a micro-channel copper cold plate and a split-flow manifold. The result of all this attention to fluid dynamics is CPU cooling that's remarkably efficient, with a total noise level that's lower than most stock CPU fans.
Contents and Specifications
Package contents
- Corsair H80 Liquid CPU Cooler
- Two 120mm fans
- Mounting screws for fans and radiator
- Mounting brackets for Intel™ LGA 775/1155/1156/1136/2011 and AMD AM2/AM3
- Quick Start Guide
Technical Specifications
- Radiator dimensions: 120mm x 152mm x 38mm
- Fan dimensions: 120mm x 120mm x 25mm
- Fan speeds (+/- 10%): up to 1300 RPM (Low Noise), 2000 RPM (Balanced), and 2500 RPM (High Performance)
- Fan airflow: 46 - 92 CFM
- Fan dBA: 22 - 39
- Fan static pressure: 1.6 - 7.7mm/H20
Compatibility
- Intel LGA 775, 1155, 1156, 1366, and 2011
- AMD sockets AM2 and AM3
- Hydro Series H80 requires a case with a rear or top 120mm fan mount
Product Description
Corsair Hydro Series liquid CPU coolers provide a compact, easy-to-install, and maintenance free alternative to bulky, noisy air coolers, efficiently cooling and protecting your high-performance Intel or AMD CPU. The H80 features a double-thick radiator to maximize the surface area available for heat dissipation and dual, performance matched fans. It also includes push-button control so you can select the fan speed and cooling performance setup that best suits your needs. Performance at your fingertips The low-profile integrated pump and cold plate includes push-button control so you can select the fan speed and cooling performance setup that best suits your needs. The cool white LED display lets you know at a glance which profile is being used. Double-up for excellent cooling Featuring a double-thick radiator to maximize the surface area available for heat dissipation, and dual, performance matched fans, the H80 delivers cooling performance that lets your CPU keep its cool, even when pushed to the limit. And with all this cooling performance, the compact design still fits virtually any case with a 120mm fan mount.
Customer Reviews
Most Helpful Customer Reviews
101 of 111 people found the following review helpful
Style Name:H60
NOTE: This review is for the H60. The Amazon product page lists all the Corsair water coolers together on one page. Therefore, regardless of which model you are looking at, you are going to see the reviews for all the different models listed together. If you are looking at the H100, you are still going to see my review for the H60. That's just the way Amazon does things.
**************************************
Pros: Rivals the some of the best air coolers out there, no maintenance like traditional water coolers, SUPER easy installation, seems to be good quality.
Cons: Instructions are lacking (see my installation tips below), must buy additional fans to unlock its full potential (I didn't ding it for this in my rating because I knew this when I decided to purchase it), no screws for a second fan, an intake setup will screw up the airflow in your case so expect to play with the case fans a little to get it right. Ideally, I would like to knock off half a star for the instructions.
---
General comments: The build quality is excellent however I did notice that a couple of the fins were slightly bent right out of the box. The threads on female thumb screws and the male thumb screws did not match up very well, so I still had to use a screwdriver after tightening them as much as possible with my hands. No big deal. The included fan has an annoying whining noise at full speed but I had planned on replacing it anyways. As with any high speed fan, I think the noise level would be reduced significantly by an anti-vibration gasket which can be purchased for about $5. At the time of writing this review, they are not on Amazon but Frozencpu has them (Feser 120mm Xvibe Noise Absorber).
I didn't keep the stock fan. I ended up doing a push/pull setup using two XIGMATEK 120MM XSF-F1252 Case Fans which are rated at 75 CFM and seem to have pretty decent static pressure. They also make a whining noise but its more tolerable than the stock fan. If you want to run a two fan setup, you will need to run to your local hardware store and pick up four 6-32x1-1/4" screws and four #6 washers.
The performance seems very good. With my OVERCLOCKED setup below, I am getting about 26C idle and 65C load with an ambient temperature around 22C. With the stock fan setup, you can expect a 4-6 degree increase in temperature. Pretty sweet if you ask me.
CPU: 2600K OC to 4.7 GHZ at 1.365v
Cooler: H60 with a push/pull intake
Mobo: Asus P8P67 Delux
RAM: Corsair Vengance 8gb 1866
Graphics: 2 x SLI MSI GTX 560Ti
SSD: OCZ Vertex 3 120gb
HDD: Samsung Spinpoint 72 1tb
PSU: Cooler Master Silent Pro M 1000w
Case: Cooler Master CM 690 Advance
---
Installation tips: There are two sets of thumb screws required for the installation, one set with two male ends, one set with female threads. To get the perfect installation, all these screws need to be evenly tensioned so that the cooling block sits evenly over the CPU. To do that, attach the back plate to the mobo using the male thumb screws. Tighten them by hand, a quarter turn past snug should do the trick. The cooling block is secured by the female thumb screws. Put the cooling block on top of the cpu and barely thread the female thumb screws on, just enough so that they are on (one or two threads). Then, in the X pattern shown in the instructions you want to tighten each about 1.5 turns at a time until they are all tight. This should ensure even tension. Don't over-tighten the thumb screws as this may mess up the contact between the CPU and the CPU pins on the mobo. A quarter turn to half turn past snug should do the trick. Remember, if you are unsure, its better to err on the side of caution.
Intake or exhaust? The instructions recommend intake for best results. I agree because cool air from outside your case is used to cool the radiator. If you run a exhaust setup, the hot air from inside your case is used to cool the radiator. Keep in mind that an intake setup will probably mess up the airflow in your case since most cases are set up so that the air flows from front to back. You will need to change the orientation of some of your case fans so that the air flows from back to front. Its important to have good exhaust fans to expel all that hot air being blown into your case by the H60. In addition to the two 120mm intake fans for the radiator, I have one 120mm side intake to keep my graphics cool, two 140mm exhausts in the top of my case, and one 140 exhaust in front.
The instructions tell you to plug the fan into the CPU fan header on your mobo, and the pump into any available 3 pin fan header. Since the power going to each of my 4 chassis fan headers cannot be adjusted independently, and because the pump needs a constant 12v supply of power I found it easier to plug it into my CPU fan header and change the fan setting so that it constantly gets full power. I then plug the fans into a regulated 3 pin fan header on the motherboard so that they, along with my regulated case fans, only kick into full power when needed. Or, if you prefer, just plug the pump directly into your PSU and save that CPU fan header for something else.
The thermal grease included with the unit is very good. I recommend trying it out before running out and buying some fancy $10 tube.
**************************************
Pros: Rivals the some of the best air coolers out there, no maintenance like traditional water coolers, SUPER easy installation, seems to be good quality.
Cons: Instructions are lacking (see my installation tips below), must buy additional fans to unlock its full potential (I didn't ding it for this in my rating because I knew this when I decided to purchase it), no screws for a second fan, an intake setup will screw up the airflow in your case so expect to play with the case fans a little to get it right. Ideally, I would like to knock off half a star for the instructions.
---
General comments: The build quality is excellent however I did notice that a couple of the fins were slightly bent right out of the box. The threads on female thumb screws and the male thumb screws did not match up very well, so I still had to use a screwdriver after tightening them as much as possible with my hands. No big deal. The included fan has an annoying whining noise at full speed but I had planned on replacing it anyways. As with any high speed fan, I think the noise level would be reduced significantly by an anti-vibration gasket which can be purchased for about $5. At the time of writing this review, they are not on Amazon but Frozencpu has them (Feser 120mm Xvibe Noise Absorber).
I didn't keep the stock fan. I ended up doing a push/pull setup using two XIGMATEK 120MM XSF-F1252 Case Fans which are rated at 75 CFM and seem to have pretty decent static pressure. They also make a whining noise but its more tolerable than the stock fan. If you want to run a two fan setup, you will need to run to your local hardware store and pick up four 6-32x1-1/4" screws and four #6 washers.
The performance seems very good. With my OVERCLOCKED setup below, I am getting about 26C idle and 65C load with an ambient temperature around 22C. With the stock fan setup, you can expect a 4-6 degree increase in temperature. Pretty sweet if you ask me.
CPU: 2600K OC to 4.7 GHZ at 1.365v
Cooler: H60 with a push/pull intake
Mobo: Asus P8P67 Delux
RAM: Corsair Vengance 8gb 1866
Graphics: 2 x SLI MSI GTX 560Ti
SSD: OCZ Vertex 3 120gb
HDD: Samsung Spinpoint 72 1tb
PSU: Cooler Master Silent Pro M 1000w
Case: Cooler Master CM 690 Advance
---
Installation tips: There are two sets of thumb screws required for the installation, one set with two male ends, one set with female threads. To get the perfect installation, all these screws need to be evenly tensioned so that the cooling block sits evenly over the CPU. To do that, attach the back plate to the mobo using the male thumb screws. Tighten them by hand, a quarter turn past snug should do the trick. The cooling block is secured by the female thumb screws. Put the cooling block on top of the cpu and barely thread the female thumb screws on, just enough so that they are on (one or two threads). Then, in the X pattern shown in the instructions you want to tighten each about 1.5 turns at a time until they are all tight. This should ensure even tension. Don't over-tighten the thumb screws as this may mess up the contact between the CPU and the CPU pins on the mobo. A quarter turn to half turn past snug should do the trick. Remember, if you are unsure, its better to err on the side of caution.
Intake or exhaust? The instructions recommend intake for best results. I agree because cool air from outside your case is used to cool the radiator. If you run a exhaust setup, the hot air from inside your case is used to cool the radiator. Keep in mind that an intake setup will probably mess up the airflow in your case since most cases are set up so that the air flows from front to back. You will need to change the orientation of some of your case fans so that the air flows from back to front. Its important to have good exhaust fans to expel all that hot air being blown into your case by the H60. In addition to the two 120mm intake fans for the radiator, I have one 120mm side intake to keep my graphics cool, two 140mm exhausts in the top of my case, and one 140 exhaust in front.
The instructions tell you to plug the fan into the CPU fan header on your mobo, and the pump into any available 3 pin fan header. Since the power going to each of my 4 chassis fan headers cannot be adjusted independently, and because the pump needs a constant 12v supply of power I found it easier to plug it into my CPU fan header and change the fan setting so that it constantly gets full power. I then plug the fans into a regulated 3 pin fan header on the motherboard so that they, along with my regulated case fans, only kick into full power when needed. Or, if you prefer, just plug the pump directly into your PSU and save that CPU fan header for something else.
The thermal grease included with the unit is very good. I recommend trying it out before running out and buying some fancy $10 tube.
48 of 57 people found the following review helpful
Style Name:H100
So I bought this Cooler for the new LGA2011 3960x build I put together back in December. I was really excited. For 2 months the system was phenomenal. Then today, after 20+ hours of gaming, my computer shut off. I restarted it, and it bluescreened with all kinds of gibberish. I took the case door off to find that the pump had come apart and the fluid was leaking from the hose/pump connection.
I hear 50/50 that you'll get a good cooler. I would advise you to stay away. I hope to god that my 3 GTX580s, my Asus Rampage IV Extreme, and CPU aren't ruined.
Corsair Hydro Series H100 Extreme Performance Liquid CPU Cooler (CWCH100)
I hear 50/50 that you'll get a good cooler. I would advise you to stay away. I hope to god that my 3 GTX580s, my Asus Rampage IV Extreme, and CPU aren't ruined.
Corsair Hydro Series H100 Extreme Performance Liquid CPU Cooler (CWCH100)
95 of 121 people found the following review helpful
Style Name:H70
At first appearance, I was extremely excited about purchasing a Corsair H-70 Liquid CPU cooler. I totally liked the idea of how a massive CPU air cooler would no longer restrict the overall air flow in my new CM HAF 932. Also, just the thought of much less weight on my motherboard was very attractive to me. Finally, when I read the benchmarks on the Corsair H-70, and how it did a fairly good job of cooling, I was sold on it.
After reading many, many glowing reviews and absolutely stellar reports about Corsair's Liquid cooled H-70, I eagerly purchased one and installed it in my computer.
It worked well for about 30 days. Suddenly, one day when I can home I smelled the very strong odor of something similar to anti-freeze. My computer would not boot, and at first, I could not figure out what was wrong. Then I opened my computer case...
What I discovered was shocking. The Corsair H70 had sprung a leak at the point where the hose attaches to the water pump. I still could not figure out how and why I kept smelling a strong automobile anti-freeze like odor...and then I realized the smell was from the liquid the Corsair H-70 was dumping on my motherboard. After doing a little more research, I discovered that Corsair does not use water but ethylene glycol as the liquid inside their H-70 liquid CPU cooler. I am thankful that the leak only killed my motherboard. Ethylene glycol is extremely toxic to humans and animals, in fact, every year hundreds of dogs and cats die from kidney failure caused by ingesting ethylene glycol. Accidental ingesting of ethylene glycol is the most common cause of serious accidental poisoning of dogs and cats.
I emailed and called Corsair, explaining the problem and requested a full refund for my purchase of a defective item that killed my very, very expensive motherboard. They outright refused. Instead, they insisted I package up the leaking H-70 and mail it to their factory so they could "confirm" that what I said actually occurred. I spent another $15 to mail the defective H70 to Corsair.
Finally, after 4 weeks, Corsair sent me an email, confirming the H-70 was indeed defective. They insisted on mailing me a replacement...something I did not care for.
After this experience, I ripped out every Corsair Liquid CPU Cooler I have ever installed [over the last 2 years, I've installed other Corsair liquid CPU Coolers in other systems]. I replaced these liquid coolers with simple yet effective CPU air coolers. The stress of wondering if my next system build would develop a leak was just too much. There is enough stress in the world and I did not want to needlessly add to the stress already out there by installing a component that would place the entire system at risk.
I realize many people are happy with Corsair's liquid CPU coolers. I am happy it is working out for them. For me personally, I will never trust a high end system to Corsair for a liquid cooled solution. I will continue to purchase their PSU's and RAM, but I will never touch their liquid CPU coolers ever again. Way too much risk, way too much stress and way too much irreparable damage with an accompanying deep disappointment.
After reading many, many glowing reviews and absolutely stellar reports about Corsair's Liquid cooled H-70, I eagerly purchased one and installed it in my computer.
It worked well for about 30 days. Suddenly, one day when I can home I smelled the very strong odor of something similar to anti-freeze. My computer would not boot, and at first, I could not figure out what was wrong. Then I opened my computer case...
What I discovered was shocking. The Corsair H70 had sprung a leak at the point where the hose attaches to the water pump. I still could not figure out how and why I kept smelling a strong automobile anti-freeze like odor...and then I realized the smell was from the liquid the Corsair H-70 was dumping on my motherboard. After doing a little more research, I discovered that Corsair does not use water but ethylene glycol as the liquid inside their H-70 liquid CPU cooler. I am thankful that the leak only killed my motherboard. Ethylene glycol is extremely toxic to humans and animals, in fact, every year hundreds of dogs and cats die from kidney failure caused by ingesting ethylene glycol. Accidental ingesting of ethylene glycol is the most common cause of serious accidental poisoning of dogs and cats.
I emailed and called Corsair, explaining the problem and requested a full refund for my purchase of a defective item that killed my very, very expensive motherboard. They outright refused. Instead, they insisted I package up the leaking H-70 and mail it to their factory so they could "confirm" that what I said actually occurred. I spent another $15 to mail the defective H70 to Corsair.
Finally, after 4 weeks, Corsair sent me an email, confirming the H-70 was indeed defective. They insisted on mailing me a replacement...something I did not care for.
After this experience, I ripped out every Corsair Liquid CPU Cooler I have ever installed [over the last 2 years, I've installed other Corsair liquid CPU Coolers in other systems]. I replaced these liquid coolers with simple yet effective CPU air coolers. The stress of wondering if my next system build would develop a leak was just too much. There is enough stress in the world and I did not want to needlessly add to the stress already out there by installing a component that would place the entire system at risk.
I realize many people are happy with Corsair's liquid CPU coolers. I am happy it is working out for them. For me personally, I will never trust a high end system to Corsair for a liquid cooled solution. I will continue to purchase their PSU's and RAM, but I will never touch their liquid CPU coolers ever again. Way too much risk, way too much stress and way too much irreparable damage with an accompanying deep disappointment.
Most Recent Customer Reviews
Two weeks...
Within two weeks of purchasing this product I had problems with it. The pump started making an odd, high pitched noise. Read more
Published 3 days ago by Broadmeadow
Exceptional
For a $90 solution, I couldn't have asked for more. There are air coolers that bring the actual temperature down further than this, but not with the convenience or within the... Read more
Published 7 days ago by Zachary A. Nichols
Waste of money
This thing is a complete waste of Money !!!
Bought it to a new computer an in less then 2 months the main module broke and the fan started to make a lot of LOUD noise, like... Read more
Bought it to a new computer an in less then 2 months the main module broke and the fan started to make a lot of LOUD noise, like... Read more
Published 9 days ago by Alexandre Rocha
Okay, but eh.
I was excited when I first received this item. I wanted to try "water cooling" out but did not want to make a custom loop. Read more
Published 12 days ago by DatsyukianDeke13
Can't beat the value
~$100 for the H100, $80-$90 for the H80/70 the value of these units really cannot be touched. There are currently two readily available air coolers that can compete with these... Read more
Published 14 days ago by M. Roberts
Very good deal
After debating about whether to go with liquid cooling or not, the H100 is the right way to go. Fairly easy installation suitable for Intel and AMD. Read more
Published 14 days ago by The Magician
H80 Review - Lose the fans
I love the H80. It's a wonderful cooler. The Corsair fans are unbearably loud, although they do push a lot of air. I replaced them with Cougar Hybro Bearing fans. Read more
Published 16 days ago by Mike
Amazing little cooler
This thing is AMAZING, it keeps my temps at a cool 26 C (i7 950 OC'd to 4.3ghz) under normal and ~45 under load. Read more
Published 18 days ago by Jonathon
"NOT A HAPPY CAMPER"
READ ALL THE COMMENTS
Received this on a Tues and installed it only to find that the Antec 620 it was supposed to replace provided better cooling properties, The H-100 had my... Read more
Received this on a Tues and installed it only to find that the Antec 620 it was supposed to replace provided better cooling properties, The H-100 had my... Read more
Published 19 days ago by fisherpcrepair
Great cooler but loud
The cooling system works very well, it's keeping my cpu at ~ 102-108F with two Eve Online clients, Firefox and usually one or two other small applications running. Read more
Published 19 days ago by Randy Shaver
