Product Specifications
Part Number DW745
Item Package Quantity1
Item Dimensions
Length22.80 inches
Width23.50 inches
Height18.75 inches
Product Features
|
Product Description
Amazon.com Product Description
The DEWALT versatile 10-Inch Jobsite Table Saw features the Site-Pro Modular Guarding System for application-specific setups that result in quick, accurate cuts. It pairs a portable design with a powerful 15 amp motor and large16-inch rip capacity. This saw comes with blade guards, a miter gauge, a push stick, and a dependable 10-inch, 24-tooth carbide blade to get your project started right away.
Consistent, Powerful Performance
Thanks to a 15 amp, high-torque motor, this DEWALT table saw delivers the power you need for tough jobs like cutting hardwood and pressure-treated lumber. The saw's 10-inch blade spins at a no-load speed of 3,850 rpm for quick, clean cuts--no matter what the application.
|
 This saw features a dependable 15 amp motor that delivers a no-load speed of 3,850 rpm. View larger. |
 Weighing just 45 pounds, the table saw comes with a folding stand for easy setup and tear down. View larger. |
Thanks to a 15 amp, high-torque motor, this DEWALT table saw delivers the power you need for tough jobs like cutting hardwood and pressure-treated lumber. The saw's 10-inch blade spins at a no-load speed of 3,850 rpm for quick, clean cuts--no matter what the application.
Convenient Site-Pro Modular Guarding System
The DEWALT versatile Site-Pro Modular Guarding System makes it easy to set up for a variety of applications by allowing tool-free adjustment of application-specific guarding components.
The saw's exclusive fence configuration enables a huge 16-inch rip capacity. Rack and pinion fence rails make fence adjustments fast, smooth, and accurate. The fence's telescoping design allows the rails to move out to 16 inches to rip full sheets of materials or be retracted for a compact design that's easy to transport.
In addition to offering large rip capacity, this saw features a maximum cut depth of 3-1/8 inches at 90 degrees and 2-1/4 inches at 45 degrees. Its table surface is coated to reduce friction for improved cut quality across the board, while a metal roll cage base provides a sturdy setup and improved durability when compared with plastic bases.
Portable Design for Use Anywhere
This DEWALT table saw weighs just 45 pounds which, along with the folding table saw stand makes for easy setup and tear down. You can move it from your workshop to the worksite with ease.
For added convenience, on-board storage provides easy access to the Site-Pro Guarding components and the push stick when they're not in use. A handy 2-1/2-inch dust collection port allows you to connect the saw to a Shop-Vac for efficient dust extraction and a cleaner work area.
This 10-inch jobsite table saw with Site-Pro Modular Guarding System also comes with a DEWALT warranty package that includes a three-year limited warranty, a one-year free service contract, and a 90-day money-back guarantee.
What's in the Box
DW745 DEWALT 10-Inch Job Site Table Saw, 10-inch 24-tooth carbide blades, miter gauge, push stick, blade guard.
 Quick, tool-freeadjustments |  Housing fits snuglyaround stand base |  Lock mechanism fits ontop of table stand |  Modular guard system protects hands and fingers |
Product Details
Would you like to update product info or give feedback on images?
|
Related Items
- Most Popular
- Power Tool Stands
- Power Tool Blades
- Work Safety Equipment & Gear
- Power Nailers & Staplers
- Measuring & Layout
- Routers
- Power Drills
- Sanders
Customer Reviews
Most Helpful Customer Reviews
280 of 283 people found the following review helpful
A friend got this six months ago for job-site use. It cut pretty well right from the box. The fence has a rack-and-pinion system that is clever, but not quite perfect. We measured the alignment error and have two fixes. If you want to know about them so you can save some money, read on...
Using a TS Aligner, we checked the alignment of the fence. The fence was near-perfect when we backed up to the mark, (going right) but it skewed by as much as four or five-thousandths when we moved the fence to the left. That's because the connecting rod between the two gears flexes and there is some "slop" or "play" in the gears. This is more noticeable when approaching the mark from the right. Sometimes this is referred to "lash-back or back-lash."
The easy work-around was to always go past the mark (an inch or so to the left) , then roll the knob back slowly right to the mark and try not to overshoot. That works OK, and it is free, but it is a time-wasting nuisance and won't provide the consistent accuracy that good woodworking requires.
SO... we replaced the flimsy metal rod that connects the two rack-gears. Instead of the stock rod, we used hardened O1 tool rod, which doesn't twist or flex as easily. The rod costs $12 bucks. We also adjusted the two gears to remove the slop. (loosen set screw, twist gears forward together, then re-tighten) Now we had fair fence parallelism in both directions. Not bad for a twelve-dollar fix... but there is more.
After using the saw a while, several of us noticed it made burns marks even with reasonable feed-rates and a new blade. One rainy day, we got out the TS aligner again and checked all the critical alignments. Dewalt uses decent bearings, so the runout was not too bad. But there were a number of other small inaccuracies that added up: arbor run-out, slot-parallelism, fence alignment, blade-alignment etc.
It took about an hour of measuring, but the Dial indicator with the TS Aligner helped us get everything literally "dialed-in." Now this thing cuts as smoothly and accurately as our five-thousand dollar cabinet saws.
The secret is to choose a saw with good bearings and a design that allows adjustments.
Dewalt and Bosch contractor saws both qualify.
Use a dial indicator with a TS Aligner to accurately measure and adjust EVERYTHING. It takes an hour, but it is worth the effort MANY times over. If you buy a new saw in the box, you have to assemble it anyway, so that isn't much more work. ... You can get professional precision at a fraction of the cost of a cabinet saw. If you don't have a TS aligner, you can use a dial indicator with a magnetic base and a 1-2-3 block set.
We cut all kinds of mitered molding and trim. We make custom installations and complex speaker cabinets that require EXACT cuts. After we adjusted this with the TS Aligner, the noise-level was lower and blades stay sharp much longer. That's always a good sign!
The beautiful thing about this saw is that we can take it to a site, make measurements on a story-pole and cut exactly to the mark, repeatably and reliably. The saw's design allows you to adjust it, assuming you have the right adjustment tools. Those tools are inexpensive and pay for themselves very quickly. You get your money back fast because you waste less wood, blades last longer and the motor runs cooler when everything on the saw is tuned up.
This is a good saw because you can adjust it and it has accurate bearings. It takes some tweaking, but with a TS Aligner and a cheap dial indicator, you can get many times your money's worth! (About FIVE times in fact!) Highly recommended!
Using a TS Aligner, we checked the alignment of the fence. The fence was near-perfect when we backed up to the mark, (going right) but it skewed by as much as four or five-thousandths when we moved the fence to the left. That's because the connecting rod between the two gears flexes and there is some "slop" or "play" in the gears. This is more noticeable when approaching the mark from the right. Sometimes this is referred to "lash-back or back-lash."
The easy work-around was to always go past the mark (an inch or so to the left) , then roll the knob back slowly right to the mark and try not to overshoot. That works OK, and it is free, but it is a time-wasting nuisance and won't provide the consistent accuracy that good woodworking requires.
SO... we replaced the flimsy metal rod that connects the two rack-gears. Instead of the stock rod, we used hardened O1 tool rod, which doesn't twist or flex as easily. The rod costs $12 bucks. We also adjusted the two gears to remove the slop. (loosen set screw, twist gears forward together, then re-tighten) Now we had fair fence parallelism in both directions. Not bad for a twelve-dollar fix... but there is more.
After using the saw a while, several of us noticed it made burns marks even with reasonable feed-rates and a new blade. One rainy day, we got out the TS aligner again and checked all the critical alignments. Dewalt uses decent bearings, so the runout was not too bad. But there were a number of other small inaccuracies that added up: arbor run-out, slot-parallelism, fence alignment, blade-alignment etc.
It took about an hour of measuring, but the Dial indicator with the TS Aligner helped us get everything literally "dialed-in." Now this thing cuts as smoothly and accurately as our five-thousand dollar cabinet saws.
The secret is to choose a saw with good bearings and a design that allows adjustments.
Dewalt and Bosch contractor saws both qualify.
Use a dial indicator with a TS Aligner to accurately measure and adjust EVERYTHING. It takes an hour, but it is worth the effort MANY times over. If you buy a new saw in the box, you have to assemble it anyway, so that isn't much more work. ... You can get professional precision at a fraction of the cost of a cabinet saw. If you don't have a TS aligner, you can use a dial indicator with a magnetic base and a 1-2-3 block set.
We cut all kinds of mitered molding and trim. We make custom installations and complex speaker cabinets that require EXACT cuts. After we adjusted this with the TS Aligner, the noise-level was lower and blades stay sharp much longer. That's always a good sign!
The beautiful thing about this saw is that we can take it to a site, make measurements on a story-pole and cut exactly to the mark, repeatably and reliably. The saw's design allows you to adjust it, assuming you have the right adjustment tools. Those tools are inexpensive and pay for themselves very quickly. You get your money back fast because you waste less wood, blades last longer and the motor runs cooler when everything on the saw is tuned up.
This is a good saw because you can adjust it and it has accurate bearings. It takes some tweaking, but with a TS Aligner and a cheap dial indicator, you can get many times your money's worth! (About FIVE times in fact!) Highly recommended!
71 of 72 people found the following review helpful
Amazon Verified Purchase
When I saw this, I immediately thought of how handy it would be on the jobsite. I have a Bosch 4000 that I truly love & believe its the best 10" saw in it class, but its heavy and I don't always need the capacity of that saw. This "little" DeWalt is perfect for ripping 1x stock for trim work & the like. I've even had it up on my scaffold. I've found the fence to be dead on and very easy to adjust. The motor has plenty of power. I think DeWalt hit a home run with this saw...Now if it only came in a cordless version!!
52 of 54 people found the following review helpful
Absolutely fantastic portable saw!! It's about time someone has offered a "portable" saw with small "stationary" power. This saw cuts through tough hardwoods with ease, so with it's compact size it is the perfect saw for small jobs without compromising power. I own the Bosch contractors table saw w/ gravity rise stand, another awesome portable saw, but when doing small jobs it's easier to not have to drag out a bigger saw to complete an easy job. The only draw back is the price and the chincy miter guage that comes with it.If they could cut the cost to $300 they would sell more of them but I paid more and am happy I did. I use it more than I thought I would. Other wise 5 stars easily...
Most Recent Customer Reviews
Saws through most small to medium projects with ease
This is a fantastic saw for those small projects which need a portable but efficient and functional saw. I purchased this for my roofing project. Read more
Published 3 days ago by J. Friedman
Thrilled!
Got this three weeks ago and I couldn't be happier with the results. I make furniture and after just a few practice runs on some scrap wood I was able to do everything I wanted. Read more
Published 10 days ago by Woody
DW745
The Dewalt DW745DEWALT DW745 10-Inch Compact Job-Site Table Saw with 16-Inch Max Rip Capacity saw is a good, portable job-site work horse. Read more
Published 23 days ago by bruce
great little saw
I bought this saw to use while I ordered repairs for another and then didn't end up using it for over a year. Read more
Published 1 month ago by verb
Performs to satisfaction
There's not much that I can add to what has already been noted by previous reviews. For a tablesaw that gets moved around a lot this one can't be beat.
Published 1 month ago by R. Stamey
Need accessories
Purchased this a couple days ago love the saw really do after using many others its a beast only one con the ripping fence I just wish it could extend further or atleast have... Read more
Published 2 months ago by brrtt
Major Flaw
This saw has some things going for it, most obviously that it is small, light and portable. There are not really any saws to directly compare it to, with the exception of the new... Read more
Published 2 months ago by Decaff
First table saw purchased.
This is the first table saw I have ever owned. Due to limited space in my basement, I needed to think about saving space where possible. This works out just fine. Read more
Published 3 months ago by Curt Matthes
Impossible to create a smooth cut!
I borrowed one of these saws for a few weeks and it performed well...it was a "TYPE 1".
Several months later I bought a "TYPE 2" (which is printed clearly on the... Read more
Several months later I bought a "TYPE 2" (which is printed clearly on the... Read more
Published 3 months ago by WJT
Pathetic rip capacity
With 16-in max rip capacity, I can hardly make a decent sized drawer with it. Returned on the same day.
Published 3 months ago by J. Arnoldus
