Extech EX470 True RMS Multimeter and Infrared Thermometer with Capacitance, Frequency, and Duty Cycle Measurements; and 2 K-Type Remote Probes.

by Extech

Product Description

Amazon.com Product Description

Compact and powerful, the Extech EX470 12-Function True RMS Professional MultiMeter provides the versatility of multiple meters in one convenient device. The autoranging EX470 measures AC/DC voltage and current, resistance, diode, and temperature. It also includes a built-in, non-contact infrared thermometer that allows you to detect invisible hot spots, as well as a True RMS function to ensure accurate AC voltage and current measurements without distortion from electronic devices. A large, backlit display and 1-inch high digits allow for easy reading, while the ergonomically designed housing offers comfortable, one-handed operation.

12 Function True RMS Professional MultiMeter and IR Thermometer At a Glance: Accurately performs 12 basic and advanced measurements Built-in, non-contact infrared thermometer finds hidden hot spots True RMS capability corrects for distortion from electronic devices High-contrast LED display with 1-inch numbers for easy viewing Type K bead wire temperature probe for surface or air measurements Three-year limited warranty on parts and labor

Performs 12 basic and advanced measurements with +/-0.5 percent basic accuracy. View larger.

12 Functions in One Convenient Meter
The EX470 offers multiple functions so professionals can carry one meter into the field instead of several. The autoranging EX470 measures AC/DC voltage, AC/DC current, resistance, diode test, capacitance, and continuity, all with +/-0.5 percent basic accuracy. The unit has low current capability, measuring down to 0.1uA, and features input fuse protection and mis-connection warnings. A Type K thermometer is built in for surface or air temperature measurements.

For greater convenience, the unit comes with a multi-position tilt stand, a Velcro strap for hanging, and a protective holster with handy test lead holder. CAT III test leads are included.

True RMS Prevents Distortion from Electronic Devices
It can be very difficult to make accurate current and voltage readings in industrial and commercial applications when electronic devices are present. Fluorescent lights, motor drives, computer power supplies, and other electronic systems can distort the AC waveform, making it hard for averaging meters to get an accurate read. True RMS uses a more advanced formula to compensate for this kind of distortion.

Built-In Non-Contact Infrared Thermometer
Find hot spots quickly and safely, even when they're invisible, with the built-in non-contact infrared thermometer. The convenient thermometer has no cables or probes to connect, break, or lose. Just point and shoot, and you get the results in seconds. The laser pointer helps you make sure that the invisible problem spots you're measuring line up exactly with what you can see. The thermometer has an eight-to-one distance to target ratio, allowing measurements in areas that are normally difficult or unsafe to reach.

Large, Backlit LCD Screen For Clear Reading
Readings on the EX470 are displayed on a large, backlit LCD screen with easy-to-read, 1-inch-tall digits. The 2,000-count screen offers high resolution over wide ranges, and features data hold to "freeze" the information on the screen for longer viewing. To preserve your batteries, the unit also features an auto power-off.

Compact, Ergonomic Design for Comfortable Handling
The EX470 is ergonomically designed and weighs less than 1 pound, so it offers a comfortable grip for one-handed operation. It measures a slim 7-2/5 by 3-1/5 by 2 inches (H x W x D), and uses one 9-volt battery.

Product and Warranty Information
The EX470 12-Function True RMS Professional MultiMeter is backed by a manufacturer's three-year limited warranty on parts and labor. The multimeter is UL and CE listed.

What's in the Box
Multimeter, CAT III test leads, stand, hanging strap, holster with built-in test lead storage, Type K bead wire temperature probe, battery, and owner manual.

Product Description

Combination autoranging multimeter features a non-contact infrared laser thermometer and True RMS. Unit has 11 functions, including capacitance, frequency and duty cycle, displayed on a large backlit screen. Infrared thermometer has laser pointer to measure surface temperatures of objects that are unsafe to contact or hard to reach. Unit also has a Type K contact thermometer. Laser Guide: Yes, Accuracy: 0.3%, Ratio: Distance to target ratio of 8:1, Temperature Scale: Celsius and Fahrenheit, Thermostate Range (deg F): non-contact readings from -58deg to 518deg F, Common Usage: Diagnostics Thermometer, LCD Display: Yes, Batteries Required: Yes, Battery Type: 9V, Charger Included: No, Dimensions L x W x H (in.): 7 3/8 x 3 3/16 x 2, Single, Pair, or Set: Single, Includes: 1 Second response time, Storage Case Included: No

See all Product Description

Product Details

Product Manual [760kb PDF]

• Product Dimensions: 7.4 x 3.2 x 2 inches ; 12 ounces
• Shipping Weight: 1 pounds (View shipping rates and policies)
• Shipping: Currently, item can be shipped only within the U.S. and to APO/FPO addresses. For APO/FPO shipments, please check with the manufacturer regarding warranty and support issues.
• ASIN: B0000WU1A2
• Item model number: EX470
• Average Customer Review: 3.0 out of 5 stars  See all reviews (2 customer reviews)
• Amazon Best Sellers Rank: #96,609 in Home Improvement (See Top 100 in Home Improvement)

Customer Reviews

Most Helpful Customer Reviews

5 of 5 people found the following review helpful:

4.0 out of 5 stars Not a Fluke, but still a worthy meter, July 12, 2009

By

Benedict J. Jackson (Portland, OR USA) - See all my reviews
(REAL NAME)

This review is from: Extech EX470 True RMS Multimeter and Infrared Thermometer with Capacitance, Frequency, and Duty Cycle Measurements; and 2 K-Type Remote Probes. (Tools & Home Improvement)

I selected this meter based on the variety of measurements (including the IR thermometer, which I had used before in a lab) and the price. I find it is a very capable meter. I like the builtin stand, the backlight, the sharp probes and the large display.

The one area where it really falls short (and even led me to believe it was broken the first time I encountered a 470 in a lab) is the auto ranging. It is much, MUCH slower than a Fluke, and while it is auto ranging it displays the random outputs at the wrong ranges. That's the main thing that keeps me from giving it 5 stars. One other slight weakness is the audible continuity tester. My Fluke 10 has some minimum beep time which you can hear even if you barely brush something. The Extech's beep is on for exactly as long as the probes are connected. If you brush against something you might only hear a strangled click or screech.

2 of 5 people found the following review helpful:

2.0 out of 5 stars Mis-represented, January 10, 2009

By

D. Nimer - See all my reviews
(REAL NAME)

This review is from: Extech EX470 True RMS Multimeter and Infrared Thermometer with Capacitance, Frequency, and Duty Cycle Measurements; and 2 K-Type Remote Probes. (Tools & Home Improvement)

The "Title" of this item indicates it comes with 2 K Type thermocouple probes. In the manufacturers description it infers the probes range is to 1832 F. "The truth is it comes with 1 type K probe only usable to 482 F". The other mis-representation is that it comes with a protective Holster. The truth is it comes with an orange protective rubber over cover.
I would like to see these inaccuracies corrected on the Amazon web site but cannot see a way to contact them.
