  • INNOVA 3030 Diagnostic Scan Tool/Code Reader with ABS for OBD2 Vehicles
  • Sorry, this item is not available in
  • Image not available
  • To view this video download Flash Player

INNOVA 3030 Diagnostic Scan Tool/Code Reader with ABS for OBD2 Vehicles

by Innova
| 91 answered questions

List Price: $128.06
Price: $59.99 & FREE Shipping. Details
You Save: $68.07 (53%)
In Stock.
Ships from and sold by Amazon.com.
  • The perfect entry level diagnostic tool for vehicle maintenance - Erase/turn off Check Engine and ABS light
  • Reads Check Engine light warnings on any 1996 and newer car, light truck, SUV and minivan. Also includes ABS read and erase coverage
  • Unique patented all-in-one back-lit display shows 25 vital pieces of information at a time
  • Automatically refreshes data every 30 seconds when connected to the vehicle, making it easy to verify repair completion
  • Internet USB (cable included) updateable and upgradeable ensures it will work on vehicles for many years to come
See more product details
35 new from $51.32 1 used from $47.99
$59.99 & FREE Shipping. Details In Stock. Ships from and sold by Amazon.com.

Frequently Bought Together

INNOVA 3030 Diagnostic Scan Tool/Code Reader with ABS for OBD2 Vehicles + OBDII Extension Cable, 5ft (144201)
Price for both: $67.89

Buy the selected items together

Special Offers and Product Promotions

Product Information

Technical Details
Item Weight6.4 ounces
Product Dimensions10 x 6.5 x 2 inches
Item model number3030
Manufacturer Part Number3030
OEM Part Number 3030
Additional Information
Best Sellers Rank #7,310 in Automotive (See top 100)
Shipping Weight9.6 ounces (View shipping rates and policies)
ShippingThis item is also available for shipping to select countries outside the U.S.
Date First AvailableJuly 7, 2004
Warranty & Support
Warranty, Parts: Parts

Manufacturer’s warranty can be requested from customer service. Click here to make a request to customer service.
 Would you like to give feedback on images?

Product Description

Product Description

This compact hand-held OBD2 tool offers light do-it-yourselfers a quick & easy way to find out why the CHECK ENGINE light illuminated on 1996 and newer cars, light trucks, minivans and SUVs. This little tool packs a big punch with its patented single-screen display showing 19 vital pieces of diagnostic information.


Read trouble codes in a snap. See product details
It’s easy and affordable to diagnose CHECK ENGINE and ABS lights with the consumer-friendly INNOVA 3030 handheld tool. Use it to find out why these lights are on, see if your car is ready to pass its emissions test, check for road trip readiness, determine if a problem is something simple you can fix yourself, and even double-check mechanic estimates.

  • Find out why the CHECK ENGINE and ABS light is on (or if it might come on soon)
  • Learn if your vehicle is ready to pass an emissions “smog” test
  • Read the diagnostic trouble codes (in consumer-friendly terms)
  • Turn off the CHECK ENGINE light/clear codes right from your smart device
  • Vehicle Coverage

  • Compatible with any 1996 or newer car, light truck, minivan, SUV or hybrid – foreign and domestic for Check Engine Light
  • Works on most 1996 and newer GM, Ford and Chrysler vehicles
  • How it Works
    STEP 1: Plug the diagnostic tool into your car’s DLC port
    STEP 2: Download PC Link software on your Windows computer
    STEP 3: Connect diagnostic tool to computer for immediate access to time and money-saving information about your car

    Unmatched Solutions and Support
    Only Innova offers optional RepairSolutions with comprehensive coverage that goes way beyond the code to help you solve warning light issues.

    RepairSolutions allows users to take control of vehicle diagnostics by providing the complete solution as to why a vehicle’s “Check Engine" light is on. A basic report is provided free with each tool purchase. A comprehensive report is available for additional purchase.

    What’s in the Box
    The 3030 Diagnostic Tool includes the diagnostic tool, mini USB cable, Quick Reference Guide and access to Innova.com where you can find RepairSolutions, tech tips, product support and much more. Note: PC Link software is available only for Windows.

    Product Warranty
    Innova Electronics, Corp. ("Innova") warrants to the original purchaser that its units are free of defects in materials and workmanship under normal use and maintenance for a period of one (1) year from the date of original purchase.

    About Innova Electronics, Corp.
    Since 1990, Innova Electronics Corporation has been developing products to meet industry demands for diagnosing and repairing virtually any vehicle on the road today. Each Innova product strives to make automotive repairs easy, efficient, accurate and affordable. Innova was the first automotive aftermarket company to employ a staff of all Automotive Service Excellence (ASE) certified technicians. Today, this growing team continues to research, develop, test and support products for do-it-yourself to professional-level technicians.

    Unmatched Support
    Innova products are supported by unmatched technical assistance from a staff of all ASE certified technicians based in the U.S.A. The same qualified technicians who help design Innova products are available to answer customer questions from application to installation. Toll-free support is available 7 days a week.

    OBD2 Vehicle Protocol Coverage
    1996 - Present - OBD2 - European, Asian, Domestic
    CAN and 2010+ Model Diesel and Hybrid Compliance
    Tool Features & Functions
    Patented All-in-One Display Shows 20+ values on one screen
    Plug and Play - All Hot Keys for Intuitive Navigation
    Vehicle Health Monitor LED's - Confirm State Emissions Test
    Emissions Readiness Advisor - Complete OBD Trip + Drive Cycles
    Retrieve Manufacturer Specific, Global & Pending Codes
    Erase Button Turns Off "Check Engine" Light
    Back-Lit display
    Displays Freeze Frame Data
    Multilingual - On Screen Definitions in English/Spanish/French
    Shows Manufacturer Specific Code Definitions on Display
    Battery Backup for Off Vehicle Data Review
    Vehicle Information - VIN # - Mode 9
    Enhanced Engine and Transmission Codes
    On Screen Code Definitions Lookup Library
    Tool Storage Pouch Included
    OBD2 Scan Tool Functions (1996 to Present)
    OBD2 Live-Data Stream Display
    OBD2 - All Modes 1 - 10
    Bi-Directional Control / Service Mode 8 - EVAP
    Record, Graph and Playback Live Data on the Screen
    ABS & SRS Coverage
    ABS - Read + Erase most 1996+ GM, Ford, Chrysler, Toyota, Honda DTC's
    Airbag / SRS - Read + Erase most 1996+ GM, Ford, Chrysler, Toyota, Honda DTC's
    Fix Assist
    FIXassist -- Provides tech tips on initial items to inspect on the tool
    OBD1 Functions - 1981-95 Coverage
    OBD1 - Domestic: Most Ford, GM, Chrysler DTC's
    OBD1 - Import: Most Toyota / Lexus DTC's
    Software, Website, Support & Service Features
    All ASE Technical Support - Mon-Sat, 6am- 6pm PST - Spanish
    One-Year Warranty
    Repair Solutions with VIN Specific Fixes + procedures - optional
    Internet Updateable & Upgradeable

    Customer Questions & Answers

    Customer Reviews

    Codes are easy to read and clear.
    Jerome Jabson
    This scanner only gives the code number but it is easy to look the code up on the internet to find out what the code means.
    Donald S. Haas
    It works great and very easy to use.

    Most Helpful Customer Reviews

    228 of 232 people found the following review helpful By R. Al-Kazily on December 3, 2007
    Verified Purchase
    Recently the "Check Engine" light illuminated on the dashboard of my 2002 Volkswagen Jetta TDI, and I used this as an excuse to purchase a code reader. I chose the Equus 3030 based on price, richness of user interface, and sophistication of the company's website (Innova).

    I was not looking for a high-end tool, with battery-backed up memory and an internal list of code descriptions. Ideally, I will seldom use this tool, and using the manual (or even better, the company's website) to look up codes works fine for me. So I have to write down the code on a piece of paper, and take that to my computer, rather than the unit remembering it for me. Plus, no batteries to go dead while the tool sits in my toolbox.

    I did appreciate the extra indicators on the LCD display, and the Green/Yellow/Red LEDs for quickly checking the status of the system. Other inexpensive code readers have a single line of text displayed, with very little else, and you need to scroll around to get information. With the Equus 3030, icons are displayed to indicate which tests have run, or have not returned good status. Also, a count of codes, pending status, and the status of the check engine light are all displayed along with the code itself.

    The CD included with the unit is designed for Windows users. However, it contains the manual in PDF form, plus an instructional video that played just fine on my Mac. I cannot comment on anything else on the CD, but it's certainly not required to use the tool. And as I mentioned, code lookup can easily be done on the Innova website, with the URL printed on the front of the tool. I have the hope that they will keep their database of trouble codes up-to-date, which is often better than software on a CD.
    Read more ›
    1 Comment Was this review helpful to you? Yes No Sending feedback...
    Thank you for your feedback. If this review is inappropriate, please let us know.
    Sorry, we failed to record your vote. Please try again
    153 of 156 people found the following review helpful By John on September 25, 2008
    Verified Purchase
    This is what it is and does what it does. It is a basic bare bones code reader (doesn't give you any live telemetry data) but has the advantage of being future proof. This is one of the most affordable code readers that works with the older On-Board Diagnostics (OBDII) and the newer Controller-area network (CAN or CAN-bus). CAN has been in use by some car manufacturers since the 1990's but as of 2008 all new cars sold in the U.S. are required to use CAN. Both protocols use the same type of connector on most cars. Even if you have a car that is OBDII don't be tempted to save a few bucks on an OBDII only reader; you're bound to have a CAN type car in the future.

    It is well made, the LCD and status lights are highly readable and the controls are simple and easy to learn. Amazon is shipping the updated 3030a model that is virtually the same as the one pictured except for a slightly different button placement and a newer processor that apparently is more compatible with all car manufacturers.
    Comment Was this review helpful to you? Yes No Sending feedback...
    Thank you for your feedback. If this review is inappropriate, please let us know.
    Sorry, we failed to record your vote. Please try again
    238 of 247 people found the following review helpful By Lane10 on January 26, 2006
    Verified Purchase
    As a backyard mechanic I was frustrated with the new cars and the check engine light that results in a $60 charge to read at a garage. Now that the price of a reader is less than $80 it makes sense to try the Equus Innova 3030 car reader and I was happy I did. It works great and is easy to use but does have a minor problem I discovered. My Subaru would not communicate with the 3030. The tech support phone line was tied up, but they quickly responded to my email and sent me a new Innova 3030 with a new chip set. Apparently Subarus, Mazdas and Volkswagons tend to have a problem in communication and in this case require a newer chip set in the 3030 which apparently works on all brands (I checked my Honda and toyota OK), so if you have one of the former car brands ask for the newer chip set. The manual has one misprint and the key must be turned to on position before plugging the 3030 into the car. Tech support at the website was great and called back later. I had already saved $60 on reading my codes plus saved $80 labor by installing a failed sensor myself although I think many other codes require a shop manual to actually track down the problem part. In summary a great tool for backyard mechanics to read the codes, fix the car and turn off the check engine light.
    1 Comment Was this review helpful to you? Yes No Sending feedback...
    Thank you for your feedback. If this review is inappropriate, please let us know.
    Sorry, we failed to record your vote. Please try again
    76 of 81 people found the following review helpful By CS on October 14, 2006
    Verified Purchase
    I did my research and I don't think you'll find a better featured OBDII compliant code scanner for the money. Comes with complete instructions and a bonus CD with more information. It plugged right in and ran its diagnostics without any problems. This unit will probably pay for itself after one or two uses to check stored codes if your vehicle's MIL comes on. Even if you don't do the repairs yourself, you'll be in more of a position to know and understand what needs to be done when you take it in for service. Certainly less chance of being misled as well. Highly recommended. Obviously, before you buy, make sure you are buying it for use on OBDII compliant vehicle(s)-generally 1996 and later. Otherwise it won't do you any good.
    Comment Was this review helpful to you? Yes No Sending feedback...
    Thank you for your feedback. If this review is inappropriate, please let us know.
    Sorry, we failed to record your vote. Please try again
    50 of 55 people found the following review helpful By S. Naimpally on May 15, 2008
    Modern (post 1996) cars provide on-board diagnostic information. All car manufacturers use the format because it was mandated to make it easy to perform emissions tests.

    The Equus Innova 3030 code reader retreives diagnostic codes from your car's engine and displays the error code(s) on its display. The 3030 does not need batteries either because it is powered by your car's battery via the OBDII port. You can then look up these codes in the manual or on the Equus website to get details of the problem. These codes enable you to determine what is wrong with the car and then take corrective measures. For example, if the code indicates a cylinder misfire and the spark plugs were recently changed, the cylinder misfire may indicate a bad spark plug. You can then change the spark plug for that cylinder.

    This device will also clear the check engine light (CEL). This is useful when you have taken corrective measures, such as replacing a defective part, and you want to determine if you have solved the problem. Replace the defective part, clear the CEL, and run the car. If the CEL does not come on again, the problem is fixed. If the CEL comes on again, then the problem probably lies elsewhere so you might have to try replacing a different part.

    This device is also useful for going to the auto mechanic armed with some knoweldge of the problem and will save you the cost of your mechanic having to plug in his much more expensive OBDII reader just so that he can make the same diagnosis.

    The manual says not to turn on the car but I kept getting an error message when I plugged in the 3030 to my 08 Mazda with just the key in at the ACC position.
    Read more ›
    1 Comment Was this review helpful to you? Yes No Sending feedback...
    Thank you for your feedback. If this review is inappropriate, please let us know.
    Sorry, we failed to record your vote. Please try again
