Infinity Reference 5350a High Performance 5-Channel Amplifier (Silver/Black)

by Infinity

Product Details

• Product Dimensions: 2.7 x 9 x 16.6 inches ; 9 pounds
• Shipping Weight: 16 pounds (View shipping rates and policies)
• Shipping: This item is also available for shipping to select countries outside the U.S.
• Shipping Advisory: This item must be shipped separately from other items in your order. Additional shipping charges will not apply.
• ASIN: B000R22X1A
• Item model number: Infinity Reference 5350a
• Average Customer Review: 3.8 out of 5 stars  See all reviews (4 customer reviews)

Product Description

Amazon.com Product Description

The Infinity 5350a is a 5-Channel complete system amplifier with on-board electronic crossover and variable bass boost circuit. Drive front and rear speakers as well as subwoofers from a single amplifier with this complete solution.

Infinity Reference Series Amplifiers Looking for a more moving audio experience? Take Infinity car audio for a ride. Innovative materials and breakthrough engineering have always put Infinity products out in front of the competition. So expect extreme output from Reference Series amps, but be prepared for accuracy and detail that may surprise you. There is no better way to make your car audio system stand up and deliver than by powering your speakers and subs with Infinity electronics.

---

Drive front and rear speakers as well as subwoofers from a single amplifier with this complete solution. Click to enlarge.

Infinity 5350a Features

Class D Subwoofer Amps
Efficiency is the benefit of the Infinity Reference Series Class D subwoofer amplifiers. A higher percentage of the power the amp extracts from the car's charging system is converted into output to the speakers, and less is wasted as heat. That is really important if you're trying to provide power to a 1000-watt amplifier. Class D technology turns the analog input signal into a series of pulses that can be amplified more efficiently by transistors used as switches, rather than valves. They're either on and operating at their most efficient level, or they're off. The pulses are converted back into an analog signal by an output filter.

CEA-2006-Compliant
All Infinity amplifiers are tested in accordance with CEA-2006, which provides a testing procedure to help customers compare amplifiers accurately--apples to apples. Specs are based on industry-accepted standards, rather than on the whims of amplifier companies' marketing departments. Look for the CEA-2006 logo when comparing amplifiers, to be sure you're getting the power you're paying for.

Audiophile-Quality Full-Range Amplifiers
Class AB full-range amplifiers offer audiophile quality performance and the best compromise between efficiency, low distortion, maximum available headroom and output power.

Amps That Don't Break
Infinity amplifiers are tested according to the strictest and most demanding reliability-testing regimen ever designed for car audio amplifiers. They are shaken, baked, frozen, dropped and shocked--all while they're operating. When they've passed all these tests, they are tested again. The result is a series of amplifiers that just don't break.

DBO Bass-Optimization Circuit
provides superior control and adjustability, compared to traditional bass-boost. DBO is a 2nd order high-pass filter that can be adjusted between 20Hz and 80Hz. The boost (or Q) adjustment boosts the signal above the highpass filter frequency. Used with a sealed box, it can help to increase output for more "fun" if it's set to about 45Hz. If it's used with a vented box, it should be set at or slightly below the tuned frequency of the box. That will prevent woofer unloading, and provide more output at the frequency where the box is tuned and the woofer's excursion is minimized--where it can handle more power.

Onboard Electronic Crossovers
Reference Series amplifiers include 2nd order (12dB/octave) slopes and are continuously variable from 32Hz to 200Hz.

Variable Bass-Boost
Provides up to 12dB of boost at 50Hz in the Reference Series full-range amplifiers.

Direct-Connect Terminals
Eliminate the need for additional solder-on or crimp-on terminals and provide an easy and reliable connection for power, ground and speaker wires.

Full-Range Preamp Outputs
Eliminates the need for signal splitters.

---

Infinity 5350a Specifications

	Power Output:	50 watts RMS x 4 channels + 150 watts RMS x 1 channels at 4 ohms and less than or equal to 1% THD + Noise 60 watts x 4 + 300 watts x 1 at 2 ohms, 14.4V supply and less than or equal to 1% THD + N2
	Signal-to-Noise Ratio:	85dBA (reference 1 watt into 4 ohms)
	Dynamic Power:	89 watts (channels 1,2,3,4); 332 watts (channels 5) at 2 ohms
	Effective Damping Factor:	6.3 at 4 ohms
	Frequency Response (-3dB):	10Hz to 100kHz (channels 1,2,3,4) 10Hz to 302Hz (channels 5)
	Maximum Input Signal:	6V
	Maximum Sensitivity:	100mV
	Dimensions (L x W x H):	16-9/16 x 9 x 2-11/16 inches (421 x 229 x 6 8mm)

---

About Infinity

Infinity was founded in 1968 on a unique blend of technology, performance, and design. Today, Infinity offers three tiers of automotive speakers comparable to the best home-audio components. Infinity Kappa Perfect, Kappa, and Reference Series speakers deliver performance that rivals the best the competition has to offer.

---

What's in the Box

Infinity Reference 5350a 5-channel amplifier (silver/black), mounting hardware, fuses, and user's manual.

---

Infinity Amplifier Options

Infinity has approached the amplifier category with the objective of delivering maximum CEA-rated power with all the right features to get the job done. Infinity's Reference amps simply deliver.

Infinity Reference 1300a Mono Subwoofer Amplifier	Infinity Reference 1600a Mono Subwoofer Amplifier	Infinity Reference 5350a 5-Channel Amplifier	Infinity Reference 475a 4-Channel Full-Range Amplifier

Product Description

The Infinity REF5350A Reference Series Amplifier comes outfitted with three variable 12dB per octave electronic crossovers allowing you to optimize system tuning based on speaker selections and location.

Customer Reviews

Most Helpful Customer Reviews

2.0 out of 5 stars Inifinity's 5350a Car Amp, September 20, 2010

By

No Pro - See all my reviews

This review is from: Infinity Reference 5350a High Performance 5-Channel Amplifier (Silver/Black) (Electronics)

I bought this amp brand new less than a year ago and it has already died on me. My entire system was professionally installed and sounded great but for the price of the amp I certainly expected it to last much longer. I will be purchasing the Alpine PDX-5 as the replacement since there is no warranty. I loved the amp but would warn anyone due to it's short life span. The amp was installed in my pickup which is used on weekends, etc. and I never neglected my system like someone younger may have done. Buyer beware!

5.0 out of 5 stars Great amp"", August 18, 2009

By

L. J. Wade "videoluvr" (lake elsinore, ca United States) - See all my reviews
(VINE VOICE)    (REAL NAME)

Amazon Verified Purchase

This review is from: Infinity Reference 5350a High Performance 5-Channel Amplifier (Silver/Black) (Electronics)

I couldnt be happier with this amp.Im running 4 infinity 6 3/4 speakers and and infinity 12 inch boxed sub in my trunk.2 of the 6 3/4 in the front doors and two on the rear deck of my toyota corolla.I had to add 2 ground loop isolators to get rid of the whining sound from the alternator also.Im using a kenwood cd player in the dash that is made for the car.Sounds outstanding.I paid less than 1000 dollars for the whole setup which isnt bad for a decent car stereo.

5.0 out of 5 stars 5-channel amp, March 16, 2009

By

Earl D. Roberts "eroberts" (vacaville, CA) - See all my reviews
(REAL NAME)

This review is from: Infinity Reference 5350a High Performance 5-Channel Amplifier (Silver/Black) (Electronics)

I was worried after purchasing the amp because I read a poor review. Knowing that my daughter wanted a hard-hitting sub, I was worried. However, after listening to her stereo my fears were unwarranted. The stereo sounds great and my daughter is very happy with her system.
