Infinity Reference 6030cs 6.5-Inch 270-Watt Two-Way Component System

by Infinity

Product Details

• Product Dimensions: 10 x 5 x 5 inches ; 5 pounds
• Shipping Weight: 124 pounds (View shipping rates and policies)
• Shipping: This item is also available for shipping to select countries outside the U.S.
• ASIN: B002BS5YAA
• Item model number: 6030cs
• Average Customer Review: 4.7 out of 5 stars  See all reviews (45 customer reviews)
• Amazon Best Sellers Rank: #1,040 in Electronics (See Top 100 in Electronics)

Product Description

Amazon.com Product Description

Infinity's 6030cs is a 6-1/4-inch, two-way component system including Plus One woofer and 1-inch textile dome tweeter with I-mount tweeter kit and Starfish OEM adapter.

The Infinity Reference Series Infinity's Reference Series has been engineered to deliver best-in-class performance for those looking to replace or upgrade their factory speakers. Features like Infinity's Plus One (patent pending) woofer cones and edge-driven-dome tweeters have helped position Infinity Reference as the number-one line of automotive loudspeakers for the past six years straight.

---

Component Systems are the perfect platform when developing a system with superior imaging and staging.

Infinity 6030cs Features

Plus One woofer cones
This patent pending technology deliver a cone with more surface area than competing models of the same size. The result is increased bass output and higher efficiency.

Rubber surrounds
This woofer surround material provides optimum cone-edge suspension and absorbs distortions that may travel up the cone edge, adding stronger low-end.

True Four Ohms
All Reference speakers feature two ohm voice coils. Original factory-installed speaker wiring in many cars is 18-22 gauge. This wire, and heating in the voice coil when power is applied, increase the impedance "seen" by the amplifier or head unit. The impedance of Reference Speakers has been adjusted to compensate for this increase and can be safely driven by any head unit.

Edge-driven textile dome tweeter
These are not commonly used w-domes, but fully-edge-driven domes like those found in better home audio speakers. The benefit is increased power handling and reduced distortion at high output levels. This technology also allows for better integration with the mid/woofer.

Crossover network with tweeter adjustment
Each Infinity Reference component system includes a pair of laboratory optimized passive crossover networks that include tweeter adjustment. If the tweeters are located low in the doors or if you are looking for a brighter sound, you can set the tweeter at +3dB.

Versatile Mounting
To facilitate proper installation and location of the tweeter, each Reference component system includes Infinity's patented I-Mount (patent no. 5,859,917) tweeter mounting kit including the Starfish OEM adapter.

---

Infinity 6030cs Specifications

	Power Handling, RMS:	75 Watts
	Power Handling, Peak:	225 Watts
	Sensitivity (2.83V @ 1m):	92dB
	Frequency Response:	67Hz - 21kHz
	Impedance:	2 Ohms
	Mounting Depth:	2-1/4 inches

---

About Infinity

Infinity was founded in 1968 on a unique blend of technology, performance, and design. Today, Infinity offers three tiers of automotive speakers comparable to the best home-audio components. Infinity Kappa Perfect, Kappa, and Reference Series speakers deliver performance that rivals the best the competition has to offer.

---

What's in the Box

Two Woofers, Two Tweeters, Two Crossovers, Two Grilles, Mounting Hardware, User Manual

---

Infinity Reference Series Component Systems

Component Systems are the perfect platform when developing a system with superior imaging and staging. These systems consist of a separate tweeter, crossover, and midrange/woofer. Infinity offers three levels of component systems. Each offers "best in class" performance and delivers incredible sonic detail and realism.

Infinity Reference 5030cs 5.25-Inch 225-Watt Two-Way Component System	Infinity Reference 6030cs 6.25-Inch 270-Watt Two-Way Component System	Infinity Reference 6830cs 6 x 8/5 x 7-Inch 270-Watt Two-Way Component System

Product Description

Looking for a more moving audio experience? Take Infinity car audio for a ride. Innovative materials and breakthrough engineering have always put Infinity products out in front of the competition’s. So expect extreme output from these speakers, but be prepared for accuracy and detail that may surprise you. Infinity Reference Series loudspeakers continue to be the top-selling premium speakers in the world. For instance, the 6-1/2-inch Reference coaxial model has been the number-one-selling car audio multielement speaker for five years straight. With proprietary features such as patent-pending Plus One cones, true 4-ohm topology, UniPivot edge-driven tweeters and the industry-leading Intermount III and I-Mount mounting systems, as well as the Starfish tweeter-mounting adapter, Reference Series speakers leave the competition scrambling to keep up.

Customer Reviews

Most Helpful Customer Reviews

6 of 6 people found the following review helpful:

5.0 out of 5 stars Sound great out of the box and even better if you add an amp., June 13, 2011

By

Pacman (CA, USA) - See all my reviews

Amazon Verified Purchase

This review is from: Infinity Reference 6030cs 6.5-Inch 270-Watt Two-Way Component System (Electronics)

I purchased a set of these about 6 months ago to replace the front factory Dodge Infinity speakers that were blown in my Durango. I just installed them and kept the factory amp and did not install the included crossovers. They sounded pretty good (the highs were much better than the factory tweeters), but the low end was lacking unless the volume was pushed up. Not a big deal since I also have a small subwoofer, but it was noticeable. When my back pair of factory Infinity's died, I purchase another pair of these and this time installed the crossovers for both front and back and added an aftermarket amplifier (Kicker ZX350.4, 90 watt per channel amp). WHAT A DIFFERENCE! The sound came alive. The lows from these are incredible and I almost don't need the sub (almost...these speakers seem to be good to around 80Hz and then fall off pretty fast, my sub is good for the lower frequencies and I have the crossover set to 80Hz for that). Still, all the way down to 80Hz is really good for 6 inch door speakers! Of course having great big Durango doors probably helps!

Anyhow, if you are getting these for your vehicle, and you want them to sound their best, you really should back them up with an aftermarket amplifier and use the included crossovers. If not, they still sound better than factory speakers, even the "premium" ones! I am very pleased with these.

2 of 2 people found the following review helpful:

5.0 out of 5 stars great speakers, November 24, 2009

By

David Babb - See all my reviews
(REAL NAME)

Amazon Verified Purchase

This review is from: Infinity Reference 6030cs 6.5-Inch 270-Watt Two-Way Component System (Electronics)

i have 4 of these speakers being pushed by a infinity reference amp. these speakers are clean and worth the money.

4 of 5 people found the following review helpful:

5.0 out of 5 stars Excellent Speaker System, October 6, 2010

By

Adam "Adam" (Wisconsin) - See all my reviews

Amazon Verified Purchase

This review is from: Infinity Reference 6030cs 6.5-Inch 270-Watt Two-Way Component System (Electronics)

I have a 2001 Dodge Durango R/T with Infinity Premium sound. I purchased these speakers to replace the stock Infinity speakers that were already in the vehicle. They installed easily and sound even better than the stock ones used too. I am so glad that I got these as a replacement.
