Infinity Reference 9632cf 6x9-Inch, 300-Watt High Performance Two-Way Loudspeaker (Pair)

by Infinity

Product Details

• Product Dimensions: 10 x 5 x 5 inches ; 5 pounds
• Shipping Weight: 10 pounds (View shipping rates and policies)
• Shipping: This item is also available for shipping to select countries outside the U.S.
• ASIN: B002CIU78I
• Item model number: 9632cf
• Average Customer Review: 4.5 out of 5 stars  See all reviews (19 customer reviews)
• Amazon Best Sellers Rank: #2,419 in Electronics (See Top 100 in Electronics)

Product Description

Amazon.com Product Description

Infinity's 6 x 9-inch 9632cf is a two-way loudspeaker with Plus One woofer cone and edge-driven textile dome tweeter, and offers an ideal--and simple--upgrade to your factory drivers.

The Infinity Reference Series Infinity's Reference Series has been engineered to deliver best-in-class performance for those looking to replace or upgrade their factory speakers. Features like Infinity's Plus One (patent pending) woofer cones and edge-driven-dome tweeters have helped position Infinity Reference as the number-one line of automotive loudspeakers for the past six years straight.

---

An ideal upgrade to your factory drivers.

Infinity 9632cf Features

Plus One woofer cones
This patent pending technology deliver a cone with more surface area than competing models of the same size. The result is increased bass output and higher efficiency.

True Four Ohms
All Reference speakers feature two ohm voice coils. Original factory-installed speaker wiring in many cars is 18-22 gauge. This wire, and heating in the voice coil when power is applied, increase the impedance "seen" by the amplifier or head unit. The impedance of Reference Speakers has been adjusted to compensate for this increase and can be safely driven by any head unit.

Edge-driven textile dome tweeters
These are not commonly used w-domes, but fully-edge-driven domes like those found in better home audio speakers. The benefit is increased power handling and reduced distortion at high output levels. This technology also allows for better integration with the mid/woofer.

Unipivot
Infinity's Unipivot (patent no. 6,002,780) allows the tweeter to be pointed at the listener's location even when the speaker is mounted off axis. This optimizes the stereo image and ensures a more uniform response.

Tweeter level adjustment
The 9632cf also features a tweeter level adjustment located on the front of the speaker and can be set at the reference level of 0dB. If the speakers are located low in the doors or if you are looking for a brighter sound, set the tweeter at +3dB.

Rubber surrounds
This material provides optimum cone-edge suspension and absorbs distortions that may travel up the cone edge, adding stronger low-end.

---

Infinity 9632cf Specifications

	Power Handling, RMS:	100 Watts
	Power Handling, Peak:	300 Watts
	Sensitivity (2.83V @ 1m):	94dB
	Frequency Response:	46Hz - 21kHz
	Impedance:	2 Ohms
	Mounting Depth:	3-1/16 inches

---

About Infinity

Infinity was founded in 1968 on a unique blend of technology, performance, and design. Today, Infinity offers three tiers of automotive speakers comparable to the best home-audio components. Infinity Kappa Perfect, Kappa, and Reference Series speakers deliver performance that rivals the best the competition has to offer.

---

What's in the Box

Infinity Reference 9632cf 6 x 9-Inch 300-Watt Two-Way Loudspeaker (pair), Installation Hardware, User Manual

---

Infinity Reference Series Multi-element Options

Multi-elements are clearly the easiest way to upgrade your system. They consist of an integrated tweeter and midrange/woofer. These speakers are designed to fit right into your factory locations with few, if any modifications. Infinity offers two extremely compelling lines of multi-element loudspeakers. Our Reference Series represents perhaps the best value of any premium brand in its price range, and our Kappa Series multi-elements are simply spectacular. These speakers have won numerous awards for their incredible audiophile-grade performance.

Infinity Reference 3032cf 3.5-Inch 75-Watt Two-Way Loudspeaker	Infinity Reference 4032cf 4-Inch 105-Watt Two-Way Loudspeaker	Infinity Reference 5032cf 5.25-Inch 135-Watt Two-Way Loudspeaker	Infinity Reference 6032cf 6.5-Inch 180-Watt Two-Way Loudspeaker
Infinity Reference 6432cf 4 x 6-Inch 120-Watt Two-Way Loudspeaker	Infinity Reference 6832cf 6 x 8/5 x 7-Inch 180-Watt Two-Way Loudspeaker	Infinity Reference 9632cf 6x9-Inch 300-Watt Two-Way Loudspeaker	Infinity Reference 9633cf 6 x 9-Inch 300-Watt 3-Way Loudspeaker

Product Description

Looking for a more moving audio experience? Take Infinity car audio for a ride. Innovative materials and breakthrough engineering have always put Infinity products out in front of the competition’s. So expect extreme output from these speakers, but be prepared for accuracy and detail that may surprise you. Infinity Reference Series loudspeakers continue to be the top-selling premium speakers in the world. For instance, the 6-1/2-inch Reference coaxial model has been the number-one-selling car audio multielement speaker for five years straight. With proprietary features such as patent-pending Plus One cones, true 4-ohm topology, UniPivot edge-driven tweeters and the industry-leading Intermount III and I-Mount mounting systems, as well as the Starfish tweeter-mounting adapter, Reference Series speakers leave the competition scrambling to keep up.

Customer Reviews

Most Helpful Customer Reviews

6 of 6 people found the following review helpful:

5.0 out of 5 stars Excellent sound and price, January 30, 2010

By

F. Ong (Kailua, Hawaii USA) - See all my reviews
(REAL NAME)

Amazon Verified Purchase

This review is from: Infinity Reference 9632cf 6x9-Inch, 300-Watt High Performance Two-Way Loudspeaker (Pair) (Electronics)

Bought these for my new 2010 MINI Cooper S rear speaker replacements. Fit like a charm without any major retrofitting or machining. I did have to add some foam stripping between the body panels and the speakers to get the exact fit but that only helped to seal the sound cavity even better and would have been done anyways to prevent the hard speaker to body rattles/knocking from occurring.
Sound was excellent, much better than the OEM speakers - Bass was rich, full. Treble was nicely present w/o being harsh. The tweeter rotates on the spindle so I was able to cross feed the sound from the back locations to the front seat areas and there is a -3dB switch to attenuate the treble is desired.
I was able to get these at a a close-out price of $79 w/ free shipping so there are certainly no complaints here!

2 of 2 people found the following review helpful:

5.0 out of 5 stars Incredible sound and value, July 9, 2010

By

Soccercap - See all my reviews

Amazon Verified Purchase

This review is from: Infinity Reference 9632cf 6x9-Inch, 300-Watt High Performance Two-Way Loudspeaker (Pair) (Electronics)

I used these to replace my rear deck speakers (of course with an adaptor bracket) of my 94 BMW 318is, the sound is incredibly nice for such an affordable pair of speakers. The lows are mellow and the highs are crisp. It improved the acoustic in my car for at least 100%. Would recommend to anyone who has the space for a pair of these in their car.
Driven directly from a Clarion 4x50W head unit, no amp was needed.

1 of 1 people found the following review helpful:

5.0 out of 5 stars Great Sound, Great Price, October 22, 2010

By

Max in Valrico - See all my reviews

Amazon Verified Purchase

This review is from: Infinity Reference 9632cf 6x9-Inch, 300-Watt High Performance Two-Way Loudspeaker (Pair) (Electronics)

Purchased these to replace the dead stock speakers in my daughters 98 Camry along with a new head unit. Installed these first and they sounded excellent with the stock head unit. Upon replacing the head unit the sound from them literally exploded. Great highs, fairly decent lows even without a sub. Can't beat them for the price.
