Lorex 8 Channel Triplex Surveillance DVR with 250GB Hard Drive, Integrated DVD-RW & Internet Remote Accessibility

by Lorex

Product Details

Lorex Support Contact Information [356kb PDF]

• Product Dimensions: 12.8 x 14.5 x 2.8 inches ; 5 pounds
• Shipping Weight: 11 pounds
• Shipping: Currently, item can be shipped only within the U.S.
• ASIN: B0012YTOH8
• Item model number: L208D251
• Average Customer Review: 1.0 out of 5 stars  See all reviews (1 customer review)
• Date first available at Amazon.com: September 14, 2004

Product Description

From the Manufacturer

The L208D251 supports high quality video and audio recording, comes with 250GB HDD, optical drive (CD/DVDRW) for convenient backup of critical video, USB backup and network support for local and remote viewing on a PC. This full featured DVR also supports composite and VGA output for viewing on any monitor, PTZ camera control, IR controller and PS/2 mouse navigation.

All this in a compact and an easy to install package.

The easy to use and install L208D251 is ideal for Business and Home use.

SEE everything:
Connect up to 8 cameras (not included). Monitor your property, indoors and outdoors, day or night.

RECORD what happens:
High-capacity, security-certified hard drive provides a reliable solution for your critical data. Extend recording duration with flexible recording triggered by motion, alarm or schedules. Triplex operation allows you to view, record and playback simultaneously.

PROTECT what matters:
Connect anytime, from anywhere in the world using the internet remote monitoring software to view or playback video that is important to you.

Technical Details:

Digital Video Recorder:

• Triplex (view, record & playback simultaneously) Digital Video Recorder with 1 audio channel
• Large storage capacity recording (Supports 2 internal “security certified” disk drives up to 1TB total)* 250GB disk drive is included
• USB port for convenient transferring of critical data to USB flash drive
• DVD RW Drive
• Pan-tilt-zoom camera control, RS485 interface (PTZ camera not included)
• Multiple recording modes (continuous, motion, alarm sensor, schedule)
• Adjustable frame rate for each channel (optimize recording characteristics)
• Mouse enabled menu system for easy set up and configuration (mouse sold separately)
• MJPEG video compression enables high resolution video recording
• Alarm input-4/output-1 (connect to existing intruder alarm or alarm panel)
• Supports up to 8 cameras (not included)
• BNC Cable Connectors

Software:

• Internet Remote Functions**: View, Search & Playback, Backup and Setup
• Compatible with Windows XP / Windows Vista
• Free Lorex DDNS (Dynamic Domain Name System) service keeps you connected anywhere all the times

* Recording capacity may vary based on recording resolution & quality, lighting conditions and movement in the scene.
** Requires a high speed internet connection and router - not included.

L208D251 Highlights:

Password Protected
The system is Password Protected to protect data from being tampered with.

Mouse Control
A mouse can be used with this DVR for Playback and Menu controls.

Camera Display Modes
Cameras can be displayed in 4 different modes:

• Single Channel
• QUAD1 (channel 1~4)
• QUAD2 (channel 5~8)
• 8CH-Split

The Virtual Keyboard
The Virtual Keyboard control is used when a keyboard input is needed for entering information such as Names, Network Information, etc.

Search Options
There are 6 options to search through recorded video.

• TIME SEARCH: Searches for video based on Time and Date.
• NORMAL RECORD EVENT: Searches for video that was recorded manually.
• TIME RECORD EVENT: Searches for video that was recorded on a schedule.
• MOTION RECORD EVENT: Searches for video that was recorded when motion was detected.
• SENSOR RECORD EVENT: Searches for video that was recorded during a sensor event.
• TOTAL RECORD EVENT: Displays all recorded video.

Backup Options
There are 2 options for backing up recorded data

• The DVD-RW drive
• A USB Flash drive (not included)

PTZ Camera The L208D521 supports a PTZ Camera via the RS485 Serial Interface. A PTZ Camera allows the user to Pan, Tilt and Zoom the camera for greater coverage of an area.

Lorex Client Application All you need is an internet connection on a remote computer, and you can do remote viewing with the Lorex Client Application. The Lorex Client has the ability to view live video and playback video on the PC.

Product Description

8 Channel Internet Remote Surveillance DVR with 250GB HDD, DVD-RW Optical Drive and Triplex Technology

Customer Reviews

Most Helpful Customer Reviews

9 of 11 people found the following review helpful:

1.0 out of 5 stars FAIR, September 22, 2008

By

wc - See all my reviews

This review is from: Lorex 8 Channel Triplex Surveillance DVR with 250GB Hard Drive, Integrated DVD-RW & Internet Remote Accessibility (Electronics)

LOTS OF NICE FEATURES BUT DON'T TRY CONNECTING A VGA MONITOR TO THIS DVR IF LATER IN THE FUTURE YOU WOULD LIKE TO USE THE TV VIDEO OUTLETS. THIS WILL RENDER THE COMPOSITE OUTLETS USELESS AND TO NEVER WORK AGAIN! I'VE TRY RESETING AND REMOVING THE INTERNAL BATTERY TO TRY TO GET THIS DVR BACK TO ORIGINAL STATE, TO NO AVAIL. IF YOU START OUT USING THE TV OUTLETS AND NEVER CONNECT A VGA MONITOR TO THE UNIT, YOU PROBABLY WOULD NEVER KNOW THERE WAS A PROBLEM. I HAVE TWO OF THESE CVR'S. LOREX TECHINCAL SUPPORT CAN'T HELP, BECAUSE THEY DON'T THINK THERE'S A PROBLEM OR WON'T FESS UP TO IT.
