Makita 9564PC 4-1/2-Inch Angle Ginder with Paddle Switch

by Makita

Product Description

Amazon.com Product Description

Makita's 4-1/2-Inch SJS Angle Grinder combines 13 AMP power with comfort and motor-protection features for longer-lasting industrial performance. The 9564PC is engineered with Makita's innovative Super Joint System (SJS) to protect the gears for longer tool life.

View larger

9564PC Features POWER - 13 AMP motor delivers 11,500 RPM PERFORMANCE - Super Joint System (SJS) helps prevent gear damage DURABILITY - Labyrinth construction, zig-zag varnish and thicker coil wires for longer tool life COMFORT - Large paddle switch for easy operation; (only 4.2 lbs.) INCLUDES - Grinding wheel, wheel guard, side handle, inner flange, lock-nut, and wrench

Tool Specifications Grinding wheel 4-1/2" Wire cup brush 3-1/2" Sanding disc 4-1/2" No load speed 11,500 RPM Spindle thread 5/8"-11 UNC AMPS 13.0 Overall length 12-1/8" Net weight 4.2 lbs.

13 AMP Power with SJS to Protect Gears
The 9564PC is powered by a 13 AMP motor that delivers 11,500 RPM, with soft start for smooth start-ups. Labyrinth construction protects the motor with a complex set of channels, prohibiting dust and contamination. In addition, the protective zig-zag varnish seals the motor and bearings from dust and debris by creating a barrier under rotation. The 9564PC is engineered with SJS, an innovation from Makita that protects the gears by automatically disengaging the motor should the grinding wheel accidentally catch or bind.

Comfort and Ergonomics
The 9564PC weighs just 4.2 pounds and is built with comfort and ergonomic features for extended use. The paddle switch provides easy operation, and the gear housing can be positioned every 90° for operator convenience. In addition, the side handle can be easily installed on either side of the tool as well as the top, and the "tool-less" wheel guard adjustment provides easy clamping.

Versatile Design for a Range of Applications
The 9564PC is a versatile and powerful grinder engineered for demanding applications including cutting, ferrous metal, paint and rust removal, shipyard maintenance, heavy machinery, metal polishing, general steel grinding, auto repair work, cutting brick and masonry, and restoration work. The grinder is built for welders, fabricators, plumbers, masons, electricians, automotive technicians, stone and tile workers, HVAC, and general contractors seeking a best-in-class industrial quality angle grinder. The 9564PC is just another example of Makita's commitment to innovative technology and best-in-class engineering.

About Makita's Super Joint System (SJS)
Super Joint System (SJS) is an innovation from Makita engineering where the motor armature and spiral bevel gear are linked by a coil spring. If the grinding wheel catches or binds, the coil spring relaxes and disengages the gears from the motor. As the grinding wheel stops, the gears and motor are protected. Makita's growing line of SJS-equipped grinders includes models ranging from a 1/4" die grinder to a 7-inch angle grinder.

About Makita
Makita is a worldwide manufacturer of industrial quality power tools and offers a wide range of industrial accessories. Makita applies leading-edge innovation to engineer power tools that are more compact and energy efficient, yet deliver industrial strength power and results. Makita U.S.A., Inc. is located in La Mirada, California, and operates an extensive distribution network located throughout the U.S. For more information, please call 800/4-MAKITA (800/462-5482) or visit makitatools.com. Makita is Best in Class Engineering.

Warranty
Every Makita tool is thoroughly inspected and tested before leaving the factory. If you are not satisfied with any Makita tool within 30 days of purchase, return it and Makita will provide a replacement or refund. Each Makita tool is warranted to be free of defects from workmanship and materials for the period of ONE YEAR from the date of original purchase. Should any trouble develop during this one-year period, return the COMPLETE tool, freight prepaid, to one of Makita's Factory or Authorized Service Centers. Please see makitatools.com for complete details.

What's in the Box
Makita 9564 PC 4-1/2-Inch 13 AMP SJS Angle Grinder with Paddle Switch, 4-1/2-inch grinding wheel, side handle, tool-less guard, inner flange, lock nut and lock nut wrench.

Product Description

The Makita 9564PC is a 4-1/2-Inch SJS (Super Joint System) Angle Grinder with Paddle Switch.

Features:

• Powerful 13.0 Amp motor delivers more output for increased performance
• Super Joint System (SJS) helps prevent gear damage
• Gear housing rotates 90 for operator convenience
• Refined design at only 4.2-pounds
• Labyrinth construction seals the motor from dust and debris by creating a complex set of channels prohibiting contamination
• Large ergonomic paddle-switch for operator comfort
• Tool-less wheel cover for easy wheel change
• Ideal for Welders, Fabricators, Masons, Maintenance/Repair etc

What's In The Box:

• Makita 9564PC 4-1/2-Inch SJS (Super Joint System) Angle Grinder with Paddle Switch
• 4-1/2-Inch Grinding Wheel (741423-0-1)
• Side Handle (153489-2)
• Tool-Less Guard (135107-4)
• Inner Flange (224399-1)
• Lock Nut (224568-4)
• Lock Nut Wrench (782424-9)

See all Product Description

Product Details

• Shipping Weight: 7.2 pounds (View shipping rates and policies)
• Shipping: This item is also available for shipping to select countries outside the U.S.
• ASIN: B001ASDTOU
• Item model number: 9564PC
• Average Customer Review: 4.5 out of 5 stars  See all reviews (2 customer reviews)
• Amazon Best Sellers Rank: #63,662 in Home Improvement (See Top 100 in Home Improvement)

Customer Reviews

Most Helpful Customer Reviews

1 of 1 people found the following review helpful:

4.0 out of 5 stars Powerhouse of a grinder!, March 9, 2010

By

Gerald A. Farmer "Farinoh" (Cleveland, Ohio USA) - See all my reviews
(REAL NAME)

Amazon Verified Purchase

This review is from: Makita 9564PC 4-1/2-Inch Angle Ginder with Paddle Switch (Tools & Home Improvement)

As a welder/fabricator, grinding is not my favorite part of any job. This grinder makes things go a little quicker. It has a LOT of power for its size and has very little vibration. Doesn't get real hot like some of the cheaper brands that I have had in the past. Nice soft start feature and the SJS feature is also helpful. Overall, this tool makes less WORK for me, and I like that. My first 4 1/2 in Makita lasted 11 years...then I bought the "yellow brand" at a big box hardware and it lasted 1 1/2 years. Going back to Makita was a no brainer!

*UPDATE* Bought in March of 2010 and here it is November 2011 and I have used and abused this grinder and it has not skipped a beat. I have been through literally hundreds of grinding wheels and not one complaint. Though, the soft start takes a little (very little) getting used to. The appearance at this point makes the grinder look 10 years old but it performs like new. I will keep updating until it dies...if it dies!

5.0 out of 5 stars Makita 13 amp grinder, June 18, 2011

By

Hacker - See all my reviews

Amazon Verified Purchase

This review is from: Makita 9564PC 4-1/2-Inch Angle Ginder with Paddle Switch (Tools & Home Improvement)

This grinder is exactly what I was searching for. Millwaukee just doesn't make grinders like they used too, and Metabo, even though they are highly ranked and priced, just didn't have what I wanted in a grinder. The soft start takes a bit to get use to, but the overall design and power makes this an almost perfect tool. Also, the price I aquired it at was very reasonable.
