Makita 9566PC 6-Inch Cut-Off/Angle Grinder with Paddle Switch

by Makita

Product Description

Amazon.com Product Description

Makita's 6-Inch SJS Cut-Off/Angle Grinder combines 13 AMP power with comfort and motor-protection features for longer-lasting industrial performance. The 9566PC is engineered with Makita's innovative Super Joint System (SJS) to protect the gears for longer tool life.

View larger

9566PC Features POWER - 13 AMP motor delivers 10,000 RPM PERFORMANCE - Super Joint System (SJS) helps prevent gear damage DURABILITY - Labyrinth construction, zig-zag varnish and thicker coil wires for longer tool life COMFORT - Large paddle switch for easy operation; only 4.2 lbs. INCLUDES - Cut-off wheel, wheel guard, side handle, inner flange, lock-nut and wrench

Tool Specifications Grinding wheel 6" Cut-off wheel 6" Wire cup brush 3-1/2" Sanding disc 6" No load speed 10,000 RPM Spindle thread 5/8"-11 UNC AMPS 13.0 Overall length 12-1/8" Net weight 4.2 lbs.

13 AMP Power with SJS to Protect Gears
The 9566PC is powered by a 13 AMP motor that delivers 11,500 RPM, with soft start for smooth start-ups. Labyrinth construction protects the motor with a complex set of channels, prohibiting dust and contamination. In addition, the protective zig-zag varnish seals the motor and bearings from dust and debris by creating a barrier under rotation. The 9566PC is engineered with SJS, an innovation from Makita that protects the gears by automatically disengaging the motor should the grinding wheel accidentally catch or bind.

Comfort and Ergonomics
The 9566PC weighs just 4.2 pounds and is built with comfort and ergonomic features for extended use. The paddle switch provides easy operation, and the gear housing can be positioned every 90° for operator convenience. In addition, the side handle can be easily installed on either side of the tool as well as the top, and the "tool-less" wheel guard adjustment provides easy clamping.

Versatile Design for a Range of Applications
The 9566PC is a versatile and powerful grinder engineered for demanding applications including cutting, ferrous metal, paint and rust removal, shipyard maintenance, heavy machinery, metal polishing, general steel grinding, auto repair work, cutting brick and masonry, and restoration work. The grinder is built for welders, fabricators, plumbers, masons, electricians, automotive technicians, stone and tile workers, HVAC, and general contractors seeking a best-in-class industrial quality cut-off/angle grinder. The 9566PC is just another example of Makita's commitment to innovative technology and best-in-class engineering.

About Makita's Super Joint System (SJS)
Super Joint System (SJS) is an innovation from Makita engineering where the motor armature and spiral bevel gear are linked by a coil spring. If the grinding wheel catches or binds, the coil spring relaxes and disengages the gears from the motor. As the grinding wheel stops, the gears and motor are protected. Makita's growing line of SJS-equipped grinders includes models ranging from a 1/4" die grinder to a 7-inch angle grinder.

About Makita
Makita is a worldwide manufacturer of industrial quality power tools and offers a wide range of industrial accessories. Makita applies leading-edge innovation to engineer power tools that are more compact and energy efficient, yet deliver industrial strength power and results. Makita U.S.A., Inc. is located in La Mirada, California, and operates an extensive distribution network located throughout the U.S. For more information, please call 800/4-MAKITA (800/462-5482) or visit makitatools.com. Makita is Best in Class Engineering.

Warranty
Every Makita tool is thoroughly inspected and tested before leaving the factory. If you are not satisfied with any Makita tool within 30 days of purchase, return it and Makita will provide a replacement or refund. Each Makita tool is warranted to be free of defects from workmanship and materials for the period of ONE YEAR from the date of original purchase. Should any trouble develop during this one-year period, return the COMPLETE tool, freight prepaid, to one of Makita's Factory or Authorized Service Centers. Please see makitatools.com for complete details.

What's in the Box
Makita 9566PC 6-Inch 13 AMP SJS Cut-Off/Angle Grinder with Paddle Switch, 6-inch cut-off wheel, side handle, cut-off wheel guard, inner flange, lock nut and lock nut wrench.

Product Description

Super Joint System (SJS) helps prevent gear damage. Powerful 13 AMP motor delivers more output for increased performance. Gear housing rotates 90 degrees left and right for cutting and grinding applications. Refined design at only 4.2 lbs. Tool-less wheel guard to help increase productivity. Labyrinth construction seals and protests the motor from dust and debris by creating a complex set of channels prohibiting contamination. Externally accessible brushes for greater serviceability. Ideal for welders, fabricators,masons, maintenance repair and more.

See all Product Description

Product Details

• Item Weight: 8 pounds
• Shipping Weight: 7.5 pounds (View shipping rates and policies)
• Shipping: This item is also available for shipping to select countries outside the U.S.
• ASIN: B001ASA09C
• Item model number: 9566PC
