| Display Type | Single 0.65 DMD DLP Technology by Texas Instruments | Resolution | Native WXGA (1280 x 800) |
| Maximum Resolution | UXGA (1600 x 1200) | Brightness (Typical) | 2800 ANSI Lumens |
| Contrast Ratio | 3000:1 (Full On/Full Off) | Lamp Life and Type | 4000/3000 Hours (STD/Bright)185W P-VIP |
| Throw Ratio | 1.55 to 1.7:1 (Distance/Width) | Projection Distance | 3.28 to 32.8 (1.0 to 10m) |
| Image Size (Diagonal) | 27.2 to 300 (0.69 to 7.62m) | Aspect Ratio | 16:10 |
| Offset | 112% | Displayable Colors | 1.07 Billion |
| Uniformity | 85% | Audio | 2-Watt Speaker |
| Remote Control | IR Remote | Computer Compatibility | UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible |
| Video Compatibility | NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (720p, 1080i/p) | Monitor Loop Through | D-Sub 15 pin VGA Output (Functional in Both Normal and Standby Modes) |
| Projection Lens | F=2.5-2.67, f=21.8-23.98mm, 1.1x Manual Zoom and Focus | User Controls | Complete On-Screen Menu Adjustments in 23 Languages |
| I/O Connectors | HDMI, VGA-In, VGA-Out, S-Video, Composite Video, Stereo Audio-In, Stereo Audio-Out and RS-232 | Security | KensingtonR Lock Port, Security Bar and Keypad Lock |
| Projection Method | Front, Rear, Ceiling Mount, Table Top | Weight | 5 lbs (2.27kg) |
| Dimensions (W x H x D) | 11.28 x 3.98 x 7.6 (287 x 101 x 193 mm) | Noise Level (STD/Bright) | 30dB/32dB |
| Keystone Correction | ±40° Vertical | Horizontal Scan Rate | 15.3 - 91.1 KHz |
| Vertical Refresh Rate | 24 - 120 Hz | Operating Temperature | 41 to 104°F (5 to 40°C), 85% Max Humidity |
| Power Supply | AC Input 100-240V, 50-60Hz, Auto-Switching | Power Consumption | 255 Watts (Bright), 207 Watts (STD), <1 Watt (Standby) |
| Standard Accessories | AC Power Cord, VGA to VGA Cable, Remote Control, Batteries for Remote, Carrying Case, Lens Cap, Multilingual CD-ROM Users Manual, Quick Start Card and Warranty Card | Optional Accessories | HDMI cable, Ceiling Mount, VGA to Component Cable, S-Video Cable, Composite Video Cable, RS-232 Cable and Panoview Series Screens |
| Warranty | 1 Year Limited Parts and Labor, 90 Days on Lamp | | |
| Using the inherent speed of DLP technology, select Optoma projectors can output video and images at an astonishing rate of 120Hz allowing you to view colorful stereoscopic 3D full screen image. | | The 3D effect is generated by splitting the 120Hz signal into two standard video streams, one for each eye. Using DLP® Link technology, the 3D active shutter glasses synchronize with the on-screen image to filter each stream to the left and right eye. Your brain then combines the two streams to provide a three dimensional image. Optoma 3D enabled projectors can be used with compatible 3D PC based content. Examples of 3D content includes educational software, video games and design/modeling programs. |
| Optoma projectors cannot be used to display 3D TV broadcasts or 3D Blu-ray discs. Optoma projectors may support these applications in the future but will require additional hardware at extra cost. | | *3D source, 3D content and active LCD shutter glasses are required |
