| Brand | VTooLand |
| Item Weight | 2.9 ounces |
| Product Dimensions | 3.9 x 3.9 x 2.2 inches |
| Item model number | S-BYHM-016 |
| Manufacturer Part Number | S-BYHM-016 |
Additional Information
| ASIN | B004KL0I9I |
| Best Sellers Rank | #13 in Automotive (See top 100) |
| Shipping Weight | 2.1 pounds (View shipping rates and policies) |
| Date First Available | January 23, 2011 |
Feedback
Would you like to give feedback on images?
Product Description
* Works with all OBD-II compliant vehicles
* Wireless (Bluetooth)
* Software included for Windows PC
* Software included for Windows Smartphone
* ISO15765-4 (CAN)
* ISO14230-4 (KWP2000)
* ISO9141-2
* J1850 VPW
* J1850 PWM Note: pls be sure that your car compatible with these agreement before you buy Functions: * Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).
* Clear trouble codes and turn off the MIL ("Check Engine" light)
* Display current sensor data, including:
* Engine RPM
* Calculated Load Value
* Coolant Temperature
* Fuel System Status
* Vehicle Speed
* Short Term Fuel Trim
* Long Term Fuel Trim
* Intake Manifold Pressure
* Timing Advance
* Intake Air Temperature
* Air Flow Rate
* Absolute Throttle Position
* Oxygen sensor voltages/associated short term fuel trims
* Fuel System status
* Fuel Pressure
* Many others
Customer Reviews
Most Helpful Customer Reviews
168 of 176 people found the following review helpful
Amazon Verified Purchase
I am using this on a 2003 Ford Explorer with a Droid Razr and the App called "Torque."
I was about ready to return this item, but then after some internet searching via Torques "Help" button [...] I was able to figure out how to get it to communicate with the "Torque" app. I would give it a five star if the manufacturer/retailer had included better guidance on getting it to work. I suppose with all the different phones/tablets/apps it's hard to provide a single, unified set of instructions....
1) Plug the ELM 327 device in the OBDII port under the car's dashboard (it's directly inline with the steering column on my Explorer).
2) Start the car (you probably don't actually need to do this step to make it work.)
3) Go to your smartphone Wireless & Networks settings and turn Bluetooth ON.
4) Go to the the phone's Bluetooth Settings and "Scan for Devices" and look for "CBT" to be found, which is the ELM 327.
5) Pair with the this device (The code is 1234).
6) Then start the "Torque" app.
7) Go to the "Settings" in Torque and select OBD2 Adapter Settings.
8) Pick Connection Type = Bluetooth.
9) Go to Choose Bluetooth Device and pick "CBT."
10) Suggest also select "Auto Bluetooth On/Off" and "Only if BT was already off."
11) Then go back to the "Torque" main screen and things should be working!
12) Good luck!
I was about ready to return this item, but then after some internet searching via Torques "Help" button [...] I was able to figure out how to get it to communicate with the "Torque" app. I would give it a five star if the manufacturer/retailer had included better guidance on getting it to work. I suppose with all the different phones/tablets/apps it's hard to provide a single, unified set of instructions....
1) Plug the ELM 327 device in the OBDII port under the car's dashboard (it's directly inline with the steering column on my Explorer).
2) Start the car (you probably don't actually need to do this step to make it work.)
3) Go to your smartphone Wireless & Networks settings and turn Bluetooth ON.
4) Go to the the phone's Bluetooth Settings and "Scan for Devices" and look for "CBT" to be found, which is the ELM 327.
5) Pair with the this device (The code is 1234).
6) Then start the "Torque" app.
7) Go to the "Settings" in Torque and select OBD2 Adapter Settings.
8) Pick Connection Type = Bluetooth.
9) Go to Choose Bluetooth Device and pick "CBT."
10) Suggest also select "Auto Bluetooth On/Off" and "Only if BT was already off."
11) Then go back to the "Torque" main screen and things should be working!
12) Good luck!
47 of 49 people found the following review helpful
By F. Thomas
Amazon Verified Purchase
|
Length:
8:01
Mins
56 of 61 people found the following review helpful
By CStradling24
Amazon Verified Purchase
I bought this to connect to my 2008 Escalade and used dash commander on my IPhone 4 and IPad two. I connected it and thought it didn't work as a lot of people said here. Then I tried it with my computer and it worked right away. After googling a little, Apple, which restricts EVERYTHING, will only le their devices connect to Bluetooth items in which they certify. Fortunately I have both items jail broken and there is an app on Cydia called RoqyBT which costs $6 and allows the iPhone t connect without an issue.
The device now works great with my iPhone and iPad.
The device now works great with my iPhone and iPad.
Most Recent Customer Reviews
5.0 out of 5 stars
Touchy but works
Works great on my 2008 Beetle. The sync time is about 15 seconds the first time but after that it's fine.
Published 9 hours ago by Pepsikat
1.0 out of 5 stars
fickle, unreliable piece of ish
It doesn't pair with android 2.3.
It pairs sometimes with windows. When it does pair, it doesn't always communicate with the laptop. Read more
It pairs sometimes with windows. When it does pair, it doesn't always communicate with the laptop. Read more
Published 15 hours ago by Mr. David Hoang
4.0 out of 5 stars
Good OBDII Adapter for the Price
Works as described and it's hard to be the price. It does have issues connecting every once in a while, but it's hard to tell if that's the computer or the adapter. Read more
Published 22 hours ago by Aaron C Hall
5.0 out of 5 stars
just wow it works
after the first one i had to order a few for some friends cause they liked it a lot a great investment if you do your own car work just amazing
Published 23 hours ago by jean
5.0 out of 5 stars
Works great, this is my second one.
I use it with torque and android. It works great. Gave my first one to a mechanic friend. It will give you codes, clear them and it can be used just to save on gas monitor... Read more
Published 1 day ago by lhatch
5.0 out of 5 stars
Works on every car i have tried it on.
Combined with the Torque app on my android phone this works perfectly. very nicely done :)
Shows engine readings such as RPM and even has a mini dyno using the accelerometer... Read more
Shows engine readings such as RPM and even has a mini dyno using the accelerometer... Read more
Published 3 days ago by Captain Trips
4.0 out of 5 stars
very useful
this is a very useful tool, i have being using it for about two months and so far works perfectly, i recommend this item
Published 3 days ago by Radhames Garcia
4.0 out of 5 stars
Guess I'm lucky, got one that worked. :)
After reading a bit online, seems people run into issues very often with these cheap ELM327 readers. Still, plenty of good reviews and I'll add to that list. Read more
Published 5 days ago by vietsb
3.0 out of 5 stars
It works Ok for the price..I tested it with iPhone 4S IOS 6.1
This device has worked out of the box at least for now. Just got it today.
Setting it up with iPhone is a little time consuming. Read more
Setting it up with iPhone is a little time consuming. Read more
Published 5 days ago by sugup32803
1.0 out of 5 stars
Cheapest piece of equipment ever
I bought this a couple of months ago, i was not even able to use it, all pin were kinda loose and when i connect it to the ecu they went up except for two. Read more
Published 8 days ago by Ramvarg
