Product Description
From the Manufacturer
The high-performance HDTVa amplified indoor HDTV antenna from Terk Technologies is designed to capture both UHF and VHF signals (channels 2 to 69) while extending the reception range for all local HDTV broadcasts. The HDTVa uses an ultra-low-noise, high-gain amplifier with Terk's exclusive Dual-Drive Amplifier technology for clear reception of both distant and close HDTV and DTV stations.
Capture both UHF/VHF signals while extending the reception range for all local HDTV broadcasts. Click here for a larger image
Features a curved, tapered, polished-aluminum look.
Integrated 75-ohm cable.
Enjoy Full-Resolution Broadcasts
Suitable for those living in city apartments as for those in suburban homes, the compact HDTVa lets viewers experience HDTV broadcasts in full resolution. Designed for total reception versatility, the HDTVa's high-gain antenna array can be oriented either horizontally or vertically within its mounting base to achieve optimum capture of off-air broadcasts.
The antenna is engineered to receive all local HDTV channels, with an operating bandwidth covering both the VHF (channels 2 to 13) and UHF (channels 14 to 69) frequency ranges. Its highly directional log periodic UHF and precision VHF elements are designed to receive HDTV broadcasts with maximum signal strength while rejecting all or most interference.
Boost Weak Signals
Set the amplifier to high-gain mode to compensate for signals that are too weak or might otherwise be bypassed for a stronger signals nearby.
Easy Installation
Simplifying your installation, the HDTVa uses Terk's Power Injector to derive power via its coaxial connecting cable. The result? One cable is all you have to connect, making it easy to install the HDTVa atop or near your television.
Great Modern Looks
As an added bonus, the HDTVa is as exceptional in appearance as it is in performance: its curved, tapering, polished-aluminum antenna elements are mounted in a slim base with a contoured front that visually complements the curve of the antenna elements.
Specs
- Dimensions: Base 13" x 9.125 x 16 Inches
- Height of Dipoles Open: 44 Inches
- Operating Bandwidth: VHF Channels 2-13; UHF Channels 14-69
- Output Impedance: 75 Ohms
- Amplifier Gain: 12 dB Typical VHF (11 dB UHF)
What's in the Box
Antenna With Integrated 75-ohm Cable, Instruction Manual, Warranty Information
Model | FDTV2  | FDTV2A  | FDTV1A  | HDTVA  | HDTVI  |
Operating Bandwidth: VHF | 174-216 MHz | 174-216 MHz | 174-216 MHz | Channels 2-13 | Channels 2-13 |
Operating Bandwidth: UHF | 470-698 MHz | 470-698 MHz | 470-698 MHz | Channels 14-69 | Channels 14-69 |
Output Impedance: | 75 Ohms | 75 Ohms | 75 Ohms | 75 Ohms | 75 Ohms |
Amplifier Gain: | - | 10dB Typical | 10dB Typical | VHF: 12dB Typical | - |
Power Supply: | - | 12V DC 100mA | 12V DC 100mA | - | - |
Accessories Included: | Mounting stand, mounting hardware | Mounting stand, power injector, | Mounting stand, power injector, | Power injector, instruction manual | Instruction Manual |
Product Description
Terk indoor amplified hd-tv uhf/vhf ant.
What Other Items Do Customers Buy After Viewing This Item?
Customer Reviews
Most Helpful Customer Reviews
1,670 of 1,691 people found the following review helpful
By A. R. Harris
Having spent a bundle acquiring a Sony LCD HDTV and upgrading our Dish service to include its limited set of HDTV channels, we were anxious to see what an Over-the-Air Antenna might add.
In all, we tested 5, including the highly rated Zenith log periodic (about $40 at Sears), an amplified Samsung (about $99 at Best Buy), an outdoor Terk 32 (about $80 at Circuit City), our old roof mounted VHF/UHF antenna (circa 1985), and the amplified Terk HDTVa (about $50 at Radio Shack). The Terk HDTVa won hands down; no contest, blowing away the much touted Zenith.
We live in the sparsely populated, low hill countryside of Western Massachuetts. The THDTVa effortlessly brings in between 20 and 30 analogue and digital (incl hdtv) channels broadcast most from 12 to 45 miles away, and some as far as 65+ miles away in Connecticut. Some digital OTA channels actually come in more sharply than some of the (Dish) satellite digital channels.
This is definitely a keeper: a great value, gem of an antenna. So good, in fact, we are debating giving up our $50/month Dish service, putting $15 of that to Netflix to replace HBO, and banking the remaining $35.
In all, we tested 5, including the highly rated Zenith log periodic (about $40 at Sears), an amplified Samsung (about $99 at Best Buy), an outdoor Terk 32 (about $80 at Circuit City), our old roof mounted VHF/UHF antenna (circa 1985), and the amplified Terk HDTVa (about $50 at Radio Shack). The Terk HDTVa won hands down; no contest, blowing away the much touted Zenith.
We live in the sparsely populated, low hill countryside of Western Massachuetts. The THDTVa effortlessly brings in between 20 and 30 analogue and digital (incl hdtv) channels broadcast most from 12 to 45 miles away, and some as far as 65+ miles away in Connecticut. Some digital OTA channels actually come in more sharply than some of the (Dish) satellite digital channels.
This is definitely a keeper: a great value, gem of an antenna. So good, in fact, we are debating giving up our $50/month Dish service, putting $15 of that to Netflix to replace HBO, and banking the remaining $35.
581 of 589 people found the following review helpful
By TerrierLover
I'm in SF Bay Area, about 30 miles from Sutro Tower. This was my first antenna and it worked out of the box for me. It is not perfect and I'm holding between 70 and 90% signal strength on all the majors with better reception than satellite. I can't compare it to any others but to say "it doesn't work" is insane. You won't know until you try it. This is not an all or nothing deal. It will work great for some, not at all for others and anywhere in between.
To check your specific situation, I recommend you try www.antennaweb.org. Click button on first page, enter your full address and you will get a report unique to your home about how/where your channels are broadcast, including a map showing exactly how you should point your antenna. In my case, all my required channels were "yellow" and all in the same compass direction. If you are very far from broadcast source or channels are coming from many different directions, it may not work. However, with good return policy, it can't hurt to try.
To check your specific situation, I recommend you try www.antennaweb.org. Click button on first page, enter your full address and you will get a report unique to your home about how/where your channels are broadcast, including a map showing exactly how you should point your antenna. In my case, all my required channels were "yellow" and all in the same compass direction. If you are very far from broadcast source or channels are coming from many different directions, it may not work. However, with good return policy, it can't hurt to try.
1,723 of 1,803 people found the following review helpful
By YSC
Amazon Verified Purchase
I'm a first timer at getting OTA HDTV. This has been an experiment in progress for the past 5 weeks. I have gone through four antennas (they are all here as I write this) before finding something that's satisfactory (rather than tolerable).
I live around 25 miles from Manhattan, where the towers of most TV stations are located. I am also aware of the directional information from [...], and have experimented accordingly with its effects on reception. My apartment's windows all face north, while the signals all comes from southwest. I cannot get signals from where it comes from, and thus needed to get signals from deflections perhaps off nearby buildings and trees. It's a very poor circumstance for over-the-air reception, maybe just slightly better than being underground. Signals are weak, and are affected by weather. Stormy and windy days have shown effects at disrupting signal reception.
With this said, and without going into much detail, let's talk about the antennas. Now all these antenna have been tested with the same equipment, setup, directional adjustments, location, etc. etc. and have been tested through good an foul weather, day and night, to observe differences.
1.Terk HDTVa Terk HDTVa Indoor Amplified High-Definition Antenna for Off-Air HDTV Reception- After reading some rave reviews and high ratings at [...], log periodic types (looks like a fishbone) seems to be the way to go. I got the Terk HDTVa first, thinking that the amplification and VHF antenna should nail my reception problems at the start. However, after more than two weeks of fidgeting around ad nauseam (directions, locations, amplifications, different devices, etc.), I only managed to pick up two ATSC channels' signals, and even those don't have strong enough signals to display anything. I thought maybe it's just my poor location, and that I should probably give up on the attempt. The included in-line amplifier dongle doesn't work at all. Powering it on makes no difference in signal strength readings, which hovered around 5-10%.
It is well built, looks nice, good concepts, but it just didn't work.
2.Phlips PHDTV1 Philips PHDTV1 Digital HDTV-UHF Indoor Antenna- The venerated "silver sensor" which was previously sold under the Zenith brand also had great ratings and reviews. It's in fact nearly legendary. I decided, in desperation, to try it out, even if it doesn't have amplification. It seems all my local HD channels are in UHF anyway, so I won't miss the VHF dipoles.
The unit has startlingly poorer build quality compared to the Terk. It has paint bubbles, hairs and dusts trappings in the paint, sharp edged cheap plastics and much thinner metal blades that's covered in oil and has some dings and bendings. I wasn't impressed with the quality, and didn't expect much from it as I set it up.
To my surprise, it picked up 9 working channels (note: the terk got two channels' signals, but they didn't work) from the start, even if it's randomly placed. It's thrilling as it was the first time I saw OTA HDTV. After some adjustment and location experiments, I was able to receive 19 channels. However, not all of these channels work well given the same direction.
The directionally sensitive antenna needs to be adjusted as I switch channels. e.g. NBC and CBS seems to work well in one direction, while ABC has its own favorite direction, which works also with FOX. I tried as best as possible to find a compromise point where everything works. I couldn't. It just needs to be adjusted constantly.
The transmission is often dogged by reception fluctuations. Signal quality tend to fluctuate quite a bit, especially affected by weather. That means the TV playback would get choppy at times, with its severity dependent on the direction I point the antenna at. I didn't think fluctuating signals was a characteristic until I tried the latter two antennas later. I also found that I had to constantly play with the directional positioning to get a stable signal from each of the stations.
It works, and I was impressed, but then in retrospect it could only be best described as a "tolerable" HDTV experience as I struggled for a smooth signal delivery.
3.RCA ANT111 Basic Indoor Antenna- While shopping in stores, I saw this basic and classic RCA loop/dipole antenna for less than $[...]. I couldn't resist the temptation to try it out, just for the heck of it. It is also a different type of antenna than the previous two.
Again, I was surprised. This cheap antenna worked well, especially considering how it's only a fraction of the price of the two I'd tried. I ended up getting 17 channels, a few less than the PHDTV1, with the same location and setup. Some channels also don't work, even if signals were detected. The quality of the signals seems to be the key.
So what's so special about it? It strangely had better signal delivery for the channels that worked. It's not as choppy, and quality level is very steady. It is also not as affected by directional positioning. I was for the first time able to view FOX, ABC, CBS, NBC without adjusting the antenna. However, the lack of directionality also makes it ambiguous when I lost the signal. It seems that there's no "favorite direction" for the channels, which also means I can't pull in stronger signals at my choosing. It is also quite susceptible to weather changes, particularly wind (which probably affected signals reflected by trees?)
The signal strength also seems to be a little weaker, though the signal quality tend to be higher in general. That probably contributed to the smoother video delivery. It also tempted me to get a similar design that has amplification.
4.Philips MANT510 Philips High Performance Amplified Indoor Uhf/ Vhf/ Fm Antenna- This unit has a "digital TV optimized, patent pending UHF panel array". I thought I'd try it out just for the slightly different antenna design, if not just for the adjustable amplification.
Well, it works, and works quite well. The antenna doesn't work without power, and with amplification turned off it works a little less than unpowered PHDTV1 and ANT111. Yet with the amplification turned on, I get 24 channels, with strength up to 81% (compared to 3-10% unamplified, and quality consistently above 60 and usually in the 70-90%+. That generates the most reliable video delivery of all the ones tried.
While thunderstorms still managed to distrupt signals, it's much less often and only momentarily. I also don't have to worry about hunting for signals as I just point it in one general direction and I get everything but three NJN channels (they are even further from here.. maybe a good 50 miles).
I finally can just set the antenna and forget it. It lets me focus on the programming rather than antenna adjustment. While it needs to be powered, it gives me the confidence to finally enjoy HDTV, rather than tweaking and tolerating it. It's good enough that I can probably stop searching. I hope it'll be helpful to you who may be going through the same purchasing decision nausea as I have.
I live around 25 miles from Manhattan, where the towers of most TV stations are located. I am also aware of the directional information from [...], and have experimented accordingly with its effects on reception. My apartment's windows all face north, while the signals all comes from southwest. I cannot get signals from where it comes from, and thus needed to get signals from deflections perhaps off nearby buildings and trees. It's a very poor circumstance for over-the-air reception, maybe just slightly better than being underground. Signals are weak, and are affected by weather. Stormy and windy days have shown effects at disrupting signal reception.
With this said, and without going into much detail, let's talk about the antennas. Now all these antenna have been tested with the same equipment, setup, directional adjustments, location, etc. etc. and have been tested through good an foul weather, day and night, to observe differences.
1.Terk HDTVa Terk HDTVa Indoor Amplified High-Definition Antenna for Off-Air HDTV Reception- After reading some rave reviews and high ratings at [...], log periodic types (looks like a fishbone) seems to be the way to go. I got the Terk HDTVa first, thinking that the amplification and VHF antenna should nail my reception problems at the start. However, after more than two weeks of fidgeting around ad nauseam (directions, locations, amplifications, different devices, etc.), I only managed to pick up two ATSC channels' signals, and even those don't have strong enough signals to display anything. I thought maybe it's just my poor location, and that I should probably give up on the attempt. The included in-line amplifier dongle doesn't work at all. Powering it on makes no difference in signal strength readings, which hovered around 5-10%.
It is well built, looks nice, good concepts, but it just didn't work.
2.Phlips PHDTV1 Philips PHDTV1 Digital HDTV-UHF Indoor Antenna- The venerated "silver sensor" which was previously sold under the Zenith brand also had great ratings and reviews. It's in fact nearly legendary. I decided, in desperation, to try it out, even if it doesn't have amplification. It seems all my local HD channels are in UHF anyway, so I won't miss the VHF dipoles.
The unit has startlingly poorer build quality compared to the Terk. It has paint bubbles, hairs and dusts trappings in the paint, sharp edged cheap plastics and much thinner metal blades that's covered in oil and has some dings and bendings. I wasn't impressed with the quality, and didn't expect much from it as I set it up.
To my surprise, it picked up 9 working channels (note: the terk got two channels' signals, but they didn't work) from the start, even if it's randomly placed. It's thrilling as it was the first time I saw OTA HDTV. After some adjustment and location experiments, I was able to receive 19 channels. However, not all of these channels work well given the same direction.
The directionally sensitive antenna needs to be adjusted as I switch channels. e.g. NBC and CBS seems to work well in one direction, while ABC has its own favorite direction, which works also with FOX. I tried as best as possible to find a compromise point where everything works. I couldn't. It just needs to be adjusted constantly.
The transmission is often dogged by reception fluctuations. Signal quality tend to fluctuate quite a bit, especially affected by weather. That means the TV playback would get choppy at times, with its severity dependent on the direction I point the antenna at. I didn't think fluctuating signals was a characteristic until I tried the latter two antennas later. I also found that I had to constantly play with the directional positioning to get a stable signal from each of the stations.
It works, and I was impressed, but then in retrospect it could only be best described as a "tolerable" HDTV experience as I struggled for a smooth signal delivery.
3.RCA ANT111 Basic Indoor Antenna- While shopping in stores, I saw this basic and classic RCA loop/dipole antenna for less than $[...]. I couldn't resist the temptation to try it out, just for the heck of it. It is also a different type of antenna than the previous two.
Again, I was surprised. This cheap antenna worked well, especially considering how it's only a fraction of the price of the two I'd tried. I ended up getting 17 channels, a few less than the PHDTV1, with the same location and setup. Some channels also don't work, even if signals were detected. The quality of the signals seems to be the key.
So what's so special about it? It strangely had better signal delivery for the channels that worked. It's not as choppy, and quality level is very steady. It is also not as affected by directional positioning. I was for the first time able to view FOX, ABC, CBS, NBC without adjusting the antenna. However, the lack of directionality also makes it ambiguous when I lost the signal. It seems that there's no "favorite direction" for the channels, which also means I can't pull in stronger signals at my choosing. It is also quite susceptible to weather changes, particularly wind (which probably affected signals reflected by trees?)
The signal strength also seems to be a little weaker, though the signal quality tend to be higher in general. That probably contributed to the smoother video delivery. It also tempted me to get a similar design that has amplification.
4.Philips MANT510 Philips High Performance Amplified Indoor Uhf/ Vhf/ Fm Antenna- This unit has a "digital TV optimized, patent pending UHF panel array". I thought I'd try it out just for the slightly different antenna design, if not just for the adjustable amplification.
Well, it works, and works quite well. The antenna doesn't work without power, and with amplification turned off it works a little less than unpowered PHDTV1 and ANT111. Yet with the amplification turned on, I get 24 channels, with strength up to 81% (compared to 3-10% unamplified, and quality consistently above 60 and usually in the 70-90%+. That generates the most reliable video delivery of all the ones tried.
While thunderstorms still managed to distrupt signals, it's much less often and only momentarily. I also don't have to worry about hunting for signals as I just point it in one general direction and I get everything but three NJN channels (they are even further from here.. maybe a good 50 miles).
I finally can just set the antenna and forget it. It lets me focus on the programming rather than antenna adjustment. While it needs to be powered, it gives me the confidence to finally enjoy HDTV, rather than tweaking and tolerating it. It's good enough that I can probably stop searching. I hope it'll be helpful to you who may be going through the same purchasing decision nausea as I have.
Most Recent Customer Reviews
2.0 out of 5 stars
Terk HDTVa Indoor Amplified High Definition Antenna for Off-Air HDTV
Bought this item, and thought that it would work well but unfortunately it barely pick up any signals despite its very cool looking construction (tried it in different areas around... Read more
Published 1 hour ago by Reviewer
5.0 out of 5 stars
Works as advertised
I decided to receive OTA HD channels because I don't watch enough TV to justify paying one of the big cable providers. Read more
Published 1 day ago by hi
5.0 out of 5 stars
Works as advertised
We live 10 miles from our TV stations and the antenna picks up the signal just fine. Also the picture quality is good. Saves us having to go with cable- yeah!
Published 1 day ago by marilyn ruecking
4.0 out of 5 stars
Great reception, but size and shape are awful
As soon as the Terk was connected to my tv, it was picking up 24 channels (a big improvement over 6), and that was before the amp was even plugged in. Read more
Published 1 day ago by absahlin
4.0 out of 5 stars
works
works well but have to make a lot of adjustments to get channels, very dependent on where it's situated and what direction it's pointed, also the higher you can mount it the better
Published 3 days ago by Eric W.
5.0 out of 5 stars
Did the trick
This was a gift for my grandfather who is in a low-signal area and has worked quite well for him. The shape and size are a bit unusual, but it works better than sleeker antennae we... Read more
Published 5 days ago by J. Bennett
3.0 out of 5 stars
Works Well But Poor Design
Does this antenna work? Yes, and it works well. I find that it has around a 40 mile range, as long as it is by a window and pointing in the right direction. Read more
Published 6 days ago by Master Reviewer
3.0 out of 5 stars
Terk HDTVa Indoor Amplified High-Definition Antenna for Off-Air...
Will only get mid range channels. Can not get channels 3 thru 13. Also will not get channels 35 thru 53.
Published 8 days ago by O'Neal Croft
1.0 out of 5 stars
Rather diassapointed
The channels I care about are 2-13. That's where all my local channels are. One thing I didn't realize that I wish I would've about this product is it 'specializes' in the 14-69... Read more
Published 8 days ago by Zach B
1.0 out of 5 stars
Terrible service!
In trying to save on the standard large cable bill, I purchased this product due to its great reviews. When I received it, I was so ecstatic. Read more
Published 8 days ago by Annie
