Hitachi B13F 10-Inch Benchtop Drill Press with Laser

Other products by Hitachi

Product Description

Amazon.com Product Description

The Hitachi B13F 10-Inch Drill Press with Laser is ideal for drilling applications that require precision and accuracy. The compact press features an adjustable X-Y laser for precision drilling and five speed settings for handling a variety of different materials. The powerful induction motor and cast-iron table are built for durability, and the smooth gear system makes for trouble-free use.

For precision, this drill press includes an X-Y axis laser and a locking depth-scale. View larger.

B13F 10-Inch Drill Press with Laser Tool Specifications Chuck 1/16"-1/2" RPMs 680; 1,160; 1,780; 2,380; 3,000 Weight 61.8 lbs. X-Y Axis Laser Fully Adjustable Motor 1/3 HP Induction Motor Cast Iron Table 7-13/16" square; tilts up to45° (L x R) Table Adjustment Smooth Rackand Pinion Gearing System

Fully Adjustable Features for Accurate Drilling
The B13F's integrated Class III-A laser-beam adjusts along the X-Y axis for pinpoint accuracy when drilling. Easy laser adjustment knobs allow for easy calibration of the drill press.

Additionally, the B13F lets you lock in depths for precise drilling. The depth-scale ring, located at the base of the feed handle, means you can make quick and easy depth adjustments without the need for special tools.

Powerful Induction Motor with Five Speed Settings
The B13F features a 1/3-horsepower induction motor that is powerful enough to drill a wide variety of materials, including wood, aluminum, plastic, mild steel, stainless steel and more. And with five speed settings--680, 1,160, 1,780, 2,380, and 3,000 RPM--you can choose the speed that's best for your material and bit size (the chuck accepts drill bits from 1/16- to 1/2-inch).

Smart Design That's Built to Last
Everything, from the induction motor to the 7-13/16-inch-square cast-iron table, is built for reliable performance. The cleverly designed table moves along a smooth rack-and-pinion gearing system and locks in place for reliable support during operation. An added bonus, the table adjusts 45 degrees to the right or left for angled drilling.

At 67.8 pounds, the B13F is lightweight enough for easy storage and portability. It is backed by Hitachi's two-year warranty.

About Hitachi: A Tradition of Innovation
Hitachi Power Tools (Hitachi Koki USA, Ltd.) provides professional-grade power tools for a variety of applications, including woodwork, metalwork, concrete, drilling, cutting, and fastening. Hitachi is a leader in power tool research and development and has achieved many firsts in the power tool industry. Today, Hitachi continues the tradition of innovation and engineering with new features in addition to classic quality.

What's in the Box
B13F Drill Press, hex wrench, two batteries, and chuck key

With a 1/3-horsepower induction motor, it powers through a variety of materials, including wood, plastic, and stainless steel. Five speed settings let you to choose the most appropriate speed. View larger.

Product Description

FEATURES AND BENEFITS Hitachi B13F 10" BT Drill Press w/ Laser Marker Features a fully adjustable x-y axis laser for precision drilling and pinpoint accuracy Delivers five speeds (620, 1,150, 1,770, 2,450 and 3,100 rpm) to tackle many different applications 1/3 HP induction motor also adds to its longer life and quieter operation Cast iron table measures 7-13/16" square and tilts up to 45 degrees left or right Easy adjustment of the table is achieved by a smooth rack and pinion gearing system Chuck accepts bits from 1/16" up to 1/2" Weighs 61.8 lbs and is compact for easy transport SPECIFICATIONS Chuck1/16" - 1/2" Speeds620, 1,150, 1,770, 2,450, 3,100 rpm Table MaterialCast Iron Table Dimensions7-13/16" x 7-13/16" Table TiltUp to 45 degrees L or R Weight61.8 lbs

See all Product Description

Product Details

• Item Weight: 61 pounds
• Shipping Weight: 61.2 pounds (View shipping rates and policies)
• Shipping: Currently, item can be shipped only within the U.S. and to APO/FPO addresses. For APO/FPO shipments, please check with the manufacturer regarding warranty and support issues.
• Shipping Advisory: This item must be shipped separately from other items in your order. Additional shipping charges will not apply.
• ASIN: B000SMJD44
• Item model number: B13F
• Average Customer Review: 3.0 out of 5 stars  See all reviews (8 customer reviews)
• Amazon.com Sales Rank: #28,002 in Home Improvement (See Bestsellers in Home Improvement)

  Popular in this category: (What's this?)

  #25 in

  Home Improvement > Power Tools > Drill Presses

Customer Reviews

Most Helpful Customer Reviews

37 of 41 people found the following review helpful:

3.0 out of 5 stars ok, but wuth issues, October 23, 2007

By	yosemite sam - See all my reviews

Amazon Verified Purchase

the table does not line up with the base, which does not affect the machine workings but does throw the user's eye off. i have yet to find the stops for drilling consistent hole depth. the laser is totally useless and flimsy. the belt adjustment is not easy. there is a grinding noise coming from the spindle. i would say this item is not worth the price asked, but i got mine on the initial offer which had 100 off, maing the price 50...and that is about what it is worth.

i have since writing the above had more time with the machine and like it even less. the motor is not at all powerful; when drilling thru 1/4" steel the press easily gets overloaded and stalls out. this makes for tedious and long drilling times; having to go slow and all to keep the thing from stalling out under this modest load.

17 of 17 people found the following review helpful:

3.0 out of 5 stars Its just ok, March 16, 2008

By	L. Judd (MI) - See all my reviews (REAL NAME)

I recently purchased this same tool at Lowes for $139.00. I usually buy from Amazon due to their excellent pricing but I needed the press quickly. Its ok. It lacks power and bogged down and stalled when drilling 1/4" teak with a 4" hole saw. I used it for production drilling of rub rails for my boat and it worked fine for that. It pretty much meets my needs but could be a bit more robust.

4 of 4 people found the following review helpful:

2.0 out of 5 stars It's okay.....just okay, March 15, 2009

By	M. Cooper (NC USA) - See all my reviews (REAL NAME)

I purchased this for our business (light and occasional use in wood). It would not come on after assembly, then I noticed the motor housing was crushed on the bottom pinning the fan. I took off the cover and the cheap plastic fan was in pieces. Called and they would not send me replacement parts but said I had to return the entire unit. Not worth the trouble so I have used it without the fan. The lasers are too bright and makes it harder to see what you are drilling. The table will not stay tight and swings to the sides easily making aligment for precision work difficult. This is a $99 drill press and worth $99.....but no more.
