From the Manufacturer
Offering a comprehensive combination of speed, accuracy and image quality, the EOS-1D Mark IV is the perfect choice for professional photographers and subjects on the move. With a completely redesigned 45-point AF system including 39 cross-type points, a new AI Servo II AF focus tracking system with improved algorithm combined with 10 fps continuous shooting, the EOS-1D Mark IV can handle even high speed situations with ease. An APS-H sized 16.1-megapixel CMOS sensor, Dual DIGIC 4 image processors, a spectacular ISO range of 100-12800 (up to 102400 in H3 mode) with an advanced noise reduction system helps ensure sharp, low-noise images in even low-light situations. Add advanced Live View shooting, Full HD movie recording with selectable frame rates and manual exposure control plus a host of new features that enhance every facet of the shooting process. The EOS-1D Mark IV is the choice of professionals looking for the ultimate in SLR performance.
EOS-1D Mark IV Features & Highlights
New 45-point Area AF sensor including 39 cross-type AF points
The EOS-1D Mark IV has a newly developed, high-precision Area AF sensor with 45 manually selectable points including 39 cross-type, high-precision AF points for exacting and fast focusing no matter the subject. New AI Servo II AF focus tracking features improved algorithms that help improve stability, reliability and focus no matter the situation. Whether shooting a fast paced soccer game or shooting a close-up of a bee on a wind-blown flower during macro photography, AI Servo II AF helps ensure sharp focus every time. AF point selection has been improved as well.
Photographers can select their own point through either the camera's Multi-controller or Main Dial/Quick Control Dial. Automatic selection is as simple as the press of a button. With Custom functions, photographers can select their own default focus point to automatically switch between horizontal and vertical shooting and can even choose to have primary focus supported by adjacent focus points for more accuracy with moving subjects.
ISO 100-12,800 (expandable to L: 50, H1: 25600, H2: 51200, H3: 102400) for shooting from bright to dim light
Blown highlights, such as the shading of a bride's dress, can be avoided and photographers can use wider apertures to control depth-of-field in ways not possible at higher ISO settings. Additionally, the EOS-1D Mark IV features the Auto Lighting Optimizer (ALO), which automatically adjusts the brightness and contrast during image processing to minimize the need for expensive, and time consuming post-production processing. Auto Lighting Optimizer is available in most shooting modes, including Manual mode and can be applied to RAW images using the included Canon Digital Photo Professional software.
EOS HD movie with manual exposure control and multiple frame rates
When shooting HD video in AE modes, the EOS-1D Mark IV employs Center-Weighted average metering to help ensure stable motion-picture exposure with the camera automatically selecting the ISO speed, shutter and aperture. Full manual exposure control is also available while shooting video when the camera is set to Manual mode.
Video can be captured at 1920 x 1080 resolution at frame rates of 24 (23.976), 25 or 30 (29.97) frames per second, for up to 4GB per clip. Movies are saved as MOV files and can be viewed in Full HD with HDMI output. Other recording sizes include HD at 1280 x 720 (50/60 (59.94) fps) or SD/VGA at 640 x 480 (50/60 (59.94) fps). The EOS-1D Mark IV has a built-in microphone for simple mono recording and stereo sound can be recorded through a self-powered external microphone.
16.1-megapixel APS-H CMOS sensor and Dual DIGIC 4 imaging processors
The EOS-1D Mark IV features a high-resolution APS-H sized 16.1-megapixel CMOS sensor (with a focal length multiplier effect of 1.3x) and Dual DIGIC 4 image processors that can process images at full resolution continuously up to 10 frames-per-second. The combination of the CMOS sensor and Dual DIGIC 4 image processors help to ensure smooth, detailed and refined images that are recorded quickly, accurately and reliably. This impressive combination of speed, quality and performance will make the EOS-1D Mark IV a staple among many professional photographers, including sports photographers, and a familiar sight on the sidelines of professional sporting events.
10.0 fps continuous shooting up to 121 Large/JPEGS or 28 RAW using a UDMA CF card
The EOS-1D Mark IV's rugged, high speed shutter can shoot up to 10.0 frames per second (fps) for up to 28 consecutive RAW files or 121 full-resolution JPEGs when used in conjunction with UDMA (Ultra Direct Memory Access) Mode 6 CF cards. The EOS-1D Mark IV's spectacular new 45-point high speed AF sensor locks on and maintains focus, ensuring that the camera keeps up with its amazing shutter.
3.0-inch Clear View II LCD monitor with 160-degree viewing angle
The EOS-1D Mark IV features the finest Canon LCD screen to date (October 2009): the new, high resolution, 3.0-inch Clear View II VGA LCD has 920,000 dot resolution and provides a new level of clarity and sharpness with a 160 degree angle of view. Its performance is admirable, not only in confirming focus and composition, but in composing and shooting in Live View mode, or when shooting video.
Magnesium alloy body with shutter durability up to 300,000 cycles
A lightweight and incredibly strong magnesium alloy construction helps the EOS-1D Mark IV to endure almost any condition, and the EOS-1D Mark IV features a shutter designed to shoot 300,000 cycles. All the EOS-1D Mark IV's controls, buttons and external covers are dust- and water-resistant, ensuring uninterrupted operation whether shooting in the rain, in a windstorm and everything in between.
Dust is managed with the advanced Canon EOS Integrated Cleaning System, which helps to suppress dust generation, removes existing dust and uses the combination of Dust Delete Data and DPP software to eliminate any remaining dust spots on your images. When the EOS-1D Mark IV is used with a dust- and water-resistant EF lens or external Speedlite, the entire camera system is nearly impervious to the elements.
Fully compatible with over 50 optional EF lenses and a wide range of optional EOS System accessories
The EOS-1D Mark IV is compatible with all Canon lenses in the EF lineup (excluding EF-S lenses), ranging from ultra-wide angle to super telephoto lenses. Canon lenses employ advanced optical expertise and micron-precision engineering to deliver outstanding performance in nearly all facets of the photographic process. Special optical technologies, such as aspherical optics and fluorite elements are featured in the widely acclaimed L-Series lenses, and Canon Image Stabilizer technology in select lenses helps to minimize the effect of camera shake. Through Canon lenses, photographers can truly maximize the quality and liberating performance of the 1D Mark IV.
The EOS-1D Mark IV features the acclaimed E-TTL II flash metering system. With any of the flashes in the EX Speedlite line, E-TTL II provides reliable flash output whether shooting fill-in flash pictures in sunlight, or using flash in total darkness. The camera's new 63-zone Evaluative Metering Sensor is also used for flash metering with an improved flash metering algorithm which reduces the chances of overexposure with wide-angle shots in which the main subject occupies a small area. If you prefer a broader area for flash metering, Custom Function II-4-1 allows shifting flash metering so that all 63 zones of the sensor are used equally to calculate flash exposures.
The Speedlite 580EX II is perfectly suited to the EOS-1D Mark IV. It has improved reliability of communications through the direct contacts, has a metal flash "foot," and is dust-/water-resistant as with the 1D Mark IV. Other new features include a PC socket on the flash unit, and an external metering sensor for non-TTL autoflash if desired. With the EOS-1D Mark IV, you can set most flash settings using the camera's menu. It has the same power as the previous Speedlite 580EX (maximum guide number of 190 ft./58m at ISO 100) and, when mounted on the camera, automatically compensates for the camera's sensor size, enabling high output flash, with more flashes per charge. It includes an AF-assist Beam, which works in conjunction with the EOS-1D Mark IV's focusing system, and automatically sends color temperature information to the camera when the flash fires, for more accurate white balance rendition with flash photography.
Canon EOS Digital Solution Disk (Version 21.2)
The EOS-1D Mark IV comes bundled with a Canon EOS Digital Solution Disk, which features powerful software programs designed to extend the EOS experience to the computer. These include Canon's EOS Utility (Version 2.7.2), Digital Photo Professional (Version 3.7.3), ZoomBrowser EX for Windows (Version 6.4.1), ImageBrowser for Macintosh OS X (Version 6.4.1), the Picture Style Editor (Version 1.6.1), MovieEdit Task (Win/Mac, Version 3.3.0) PhotoStitch (Windows Version 3.1.2/Mac Version 3.2.4), Memory Card Utility (Win/Mac, Version 1.2.2), WFT Utility (Win/Mac, Version 3.4.1), and Original Data Security Tools 1.7.1 (Win). Each application is designed to perfect the captured images and streamline the digital workflow.
Compatible Operating System
Windows: Windows XP SP2 or SP3 / Windows Vista (all version except the Starter Edition) / Windows 7 32-bit and 64-bit versions.
Macintosh: OS X 10.4 to 10.5
EOS Utility (Version 2.7.2) for Macintosh or Windows handles the connection between the camera and computer whenever they're connected via USB. It allows remote controlled shooting from the computer, handles downloading of images from the camera to the computer, and allows seamless linking to either Canon's ZoomBrowser EX/ImageBrowser or Digital Photo Professional software once images have been copied to the hard drive. Furthermore, it's used to upload settings back into a USB-connected camera.
Digital Photo Professional (Win/Mac, Version 3.7.3) is an image processing program that enables high-speed RAW image processing, high-speed previewing for real-time image adjustment and support for sRGB, Adobe RGB and Wide Gamut RGB color spaces. Because it's CMS (Color Management System) compatible, Digital Photo Professional allows for easy image layout and printing in Adobe RGB in conjunction with Easy-PhotoPrint and PictBridge printers. It also features the Dust Delete Data Detection tool for cleaner images.
Picture Style Editor (Win/Mac, Version 1.6.1) Canon's Picture Style Editor enables you to create custom Picture Style profiles that can be used to customize the appearance of JPEG and RAW images captured with EOS Digital SLR cameras. Picture Style files created with Picture Style Editor can be loaded into the EOS cameras that support Picture Style and may also be used when processing RAW images in Canon software applications Digital Photo Professional, ZoomBrowser EX (for Windows) and ImageBrowser (for Mac).
ZoomBrowser EX (Version 6.4.1) for Windows and ImageBrowser (Version 6.4.1) for Mac OS X are the easy, user-friendly options for viewing and editing of JPEG and even RAW image files. Both allow viewing of numerous types of images including finished TIFF and BMP files. Both also have a variety of search options for finding images, allow re-naming of single images or batches of files, and offer a variety of options for printing without using a separate image-editing program.
What's in the Box
- EOS-ID Mark IV Digital SLR Body
- Eyecup Eg
- Wide Neck Strap L6
- Stereo AV Cable AVC-DC400ST
- USB Interface Cable IFC-200U
- Cable Protector
- Battery Pack LP-E4
- Battery Charger LC-E4
- CR2025 Lithium Battery
- EOS Digital Solution Disk
- Software Instruction Manual
