| Brand | FSP |
|---|---|
| Item model number | FSP300-50FGBBI(M) |
| Item Weight | 2.2 pounds |
| Product Dimensions | 5.9 x 1.59 x 3.2 inches |
| Item Dimensions LxWxH | 5.9 x 1.59 x 3.2 inches |
| Color | 250W |
| Manufacturer | FSP Group USA |
| ASIN | B07W218FCV |
| Date First Available | August 1, 2019 |
Customers also viewed these products
Page 1 of 1 Start overPage 1 of 1
Customers who bought this item also bought
Page 1 of 1 Start overPage 1 of 1
Exclusive items from our brands
Page 1 of 1 Start overPage 1 of 1
From the manufacturer
|
|
|
|
|---|---|---|
85% Efficiency ConversionThe efficiency of your power supply is important because it directly affects you system’s performance.
|
Application Field
|
Safety Protection
|
|
|
|
|
|---|---|---|
Firm Installation with Flexible Bracket DesignStanding out from Flex-ATX PSU marketing, FSP pioneered the development of bracket design for FlexGuru series, strengthening the fixation adequacy by 25% to fit in most of the Flex-ATX chassis. |
High Power DensityFlexGuru series offers 20% high power density than any Flex PSU in same wattage and frame. |
Excellent Thermal PerformanceDiffer from the general FLEX PSU, FlexGuru series is designed with inner 40 mm fan, noise cancellation and achieving maximum cooling at all times. |
|
|
|
|---|---|---|
| FlexGuru 250W | FlexGuru 300W | |
| Model | FSP250-50FGBBI(M) | FSP300-57FCB |
| Rated Output Power | 250W | 300W |
| Form Factor | FLEX ATX | FLEX ATX |
| Input Voltage | 100-240V | 100-240V |
| Input Current | 4-2A | 6-3A |
| Input Frequency | 60-50Hz | 60-50Hz |
| PFC | Active PFC | Active PFC |
| Efficiency | 85% | 90% |
| Dimensions(L x W x H) | 150 x 40.5 x 81.5 mm | 5.9 x 1.59 x 3.2 in | 150 x 40.5 x 81.5 mm | 5.9 x 1.59 x 3.2 in |
| Protection | UVP, OVP, SCP, OPP, OTP | UVP, OVP, SCP, OPP, OTP |
Customer Questions & Answers
Customer reviews
Top reviews from the United States
There was a problem filtering reviews right now. Please try again later.
Reviewed in the United States on September 29, 2019
Verified Purchase
Total joke - impractical and barely useable
By ParaPilot on September 29, 2019
I have purchased over 200 FSP brand computer PSUs. They have proved to be extremely high quality and very reliable, however whoever designed these and wrote the description must have been smoking dope. On the positive side they are high quality and they run very cool so I suspect if you can get them into the case they might be reliable which is why I gave them 3 stars, however they are a total joke as regards suitability for ITX cases and to state they are modular is beyond a total a joke. EVERY PC needs to have a Motherboard and unless it has an M.2 SSD it needs one SATA power connector. Any good modular PSU comes with multiple plug in leads. If you don't need the old style LP4 connectors then you don't plug that lead in, same for the Motherboard CPU power header or the video card power connector. However this PSU has one gigantic power connector just for the 24 way Motherboard connector that doesn't even have the CPU header on it. There is only one other modular plug in so unless you have an extremely weird setup you need both plug ins (there are only 2) and all the leads just like any normal non-modular design. Worse still these are not lovely flat and all in one flat cables, the motherboard connector is connected with around 5 different flat cables twisted around like birds nest soup at the end so the correct terminals connect into the connector. Since I only needed the 1 SATA power connector then trying to get rid of around 5 other multi-connector leads neatly in an ITX case was nothing short of a nightmare. The flat cables take up more than twice the room of the equivalent FSP250-60FAG non modular normal wired PSU and why any sane person would have a Floppy Connector on a modern PC PSU when I haven't used one in 20 years beggars belief. See my photos for 2 attempts of trying to neatly install this nightmare. I bought 4 of these, I certainly would not recommend them for ITX cases and will not be buying any more.
By ParaPilot on September 29, 2019
