| Brand | Gikfun |
|---|---|
| Item model number | LYSB00Y20JYTM-ELECTRNCS |
| Item Weight | 0.8 ounces |
| Product Dimensions | 5.3 x 0.4 x 3.4 inches |
| Item Dimensions LxWxH | 5.3 x 0.4 x 3.4 inches |
| Voltage | 5 Volts |
Enjoy fast, FREE delivery, exclusive deals and award-winning movies & TV shows with Prime
Try Prime
and start saving today with Fast, FREE Delivery
Amazon Prime includes:
Fast, FREE Delivery is available to Prime members. To join, select "Try Amazon Prime and start saving today with Fast, FREE Delivery" below the Add to Cart button.
Amazon Prime members enjoy:- Cardmembers earn 5% Back at Amazon.com with a Prime Credit Card.
- Unlimited Free Two-Day Delivery
- Instant streaming of thousands of movies and TV episodes with Prime Video
- A Kindle book to borrow for free each month - with no due dates
- Listen to over 2 million songs and hundreds of playlists
- Unlimited photo storage with anywhere access
Important: Your credit card will NOT be charged when you start your free trial or if you cancel during the trial period. If you're happy with Amazon Prime, do nothing. At the end of the free trial, your membership will automatically upgrade to a monthly membership.
-
-
-
-
-
-
-
VIDEOS -
-
Image Unavailable
Color:
-
-
-
- To view this video download Flash Player
Gikfun DIY SMD SMT Welding Practice Soldering Skill Training Board Led EK7026_
- Free returns are available for the shipping address you chose. You can return the item for any reason in new and unused condition: no shipping charges
- Learn more about free returns.
- Go to your orders and start the return
- Select the return method
- Ship it!
Purchase options and add-ons
| Brand | Gikfun |
| Personal computer design type | Computer Tower |
| Human Interface Input | Numeric Keypad |
About this item
- After welding, just connect electricity (3-12V) to see the effect. You can quickly judge the welding effect. The welding product is a beautiful water lamp circuit.
- The back of the board with mm/Inch ruler, Easy to measure component
- This is a perfect Soldering skills training materials for beginners. This Soldering Project requires basic electronic knowledge and hands-on ability. We have uploaded the user guide on the Amazon page at Technical Specification.
- High quality PCB, has clearly marked the electronics components, even beginners can easily solder successfully.
- Since the accessories are very small, it is recommended to use a pointed clip to assist welding. ASIN: B095BP53HJ
-
Gikfun DIY SMD SMT Welding Practice Soldering Skill Training Board$15.38$15.38 $15.56$15.56This bundle contains 2 items -
Gikfun SMD Practice Soldering Skill Training Board, NE555 Water Flowing Led for Electronic Enthusiast DIY$16.38$16.38 $16.86$16.86This bundle contains 2 items
Frequently bought together

More items to explore
Soldering Practice Kit,3 Kits SMD SMT Weldering Skills Training Board(Soldering-All)Amazon's Choicein Soldering Stations
Compare with similar items
Product Description
Gikfun Inc focus on electronic design, development and marketing of Arduino.
We'd like to receive your valuable suggestions for our products and make your idea come true.
|
|
|
|
|---|---|---|
Beautiful water lamp circuit
|
Complete accessories
|
Improve the welding skills
|
Convenient measurement design
- The back of the PCB board is marked with mm/in scale for easy measurement of components, and also marked with PCB line width example, can be used as a design PCB reference
- PCB Size: 85.6mm(L)x 54mm (W) x1.6mm (H)
- Operating Voltage: 3-12V
- This is red Led, we also have blue Led version, ASIN is B00VWB8F8K
- The product is used for learning. Suitable for people who want to improve the welding skills.
- Please make sure all components in right direction and right place; and check whether pseudo and float welding, this is very important in practicing and testing.
- Comes with English user manual and online file, which will guide you how to finish step by step. If you need technology supports, or meet other problem, please send e-mail to us, we will help you as soon as possible.
Videos
Videos for this product

0:05
Click to play video

Customer Review: I spent five hours making the whole thing.
BigThink

Videos for related products

0:08
Click to play video

SMD Welding Practice Soldering Skill Training Board
Gikfun_Official_Store
Videos for related products

0:32
Click to play video

Gikfun Soldering Practice Kit SMD SMT
Gikfun_Official_Store
Videos for related products

1:44
Click to play video

Gikfun Practice Board Soldering Skill Training diy Kit
Gikfun_Official_Store
Videos for related products

0:29
Click to play video

finished product display
tingbowie
Videos for related products

0:22
Click to play video

Soldering Practice Kit
tingbowie
Product information
Technical Details
Additional Information
| ASIN | B00Y20JYTM |
|---|---|
| Customer Reviews |
4.3 out of 5 stars |
| Best Sellers Rank | #206,051 in Automotive (See Top 100 in Automotive) #1,931 in Welding Equipment & Accessories |
| Date First Available | May 22, 2015 |
Warranty & Support
Feedback
Customer reviews
Customer Reviews, including Product Star Ratings help customers to learn more about the product and decide whether it is the right product for them.
To calculate the overall star rating and percentage breakdown by star, we don’t use a simple average. Instead, our system considers things like how recent a review is and if the reviewer bought the item on Amazon. It also analyzed reviews to verify trustworthiness.
Learn more how customers reviews work on AmazonReviewed in the United States on April 21, 2016
-
Top reviews
Top reviews from the United States
There was a problem filtering reviews right now. Please try again later.
So now its a circuit diagnostic trainer. lol! It might be helpful to have a few spares of the parts that may be more heat sensitive, or prone to fail when running. But its an $8 kit, so can't expect too much.
You will need a 20x magnifier to inspect for solder defects, as well as a reasonably good temp control solder station, an assortment of soldering iron tips, an assortment of tweezers, flux, solder wick, and an anti-slip surface to work on to be able to complete this device reasonable well. 60/40 tin/lead solder would be recommended, but if you want to try doing this with RoHS solder, you will likely bump the difficulty from an 8 up to an 11 unless you're using a hot air system, or other professional soldering station equipment like a Metcal.
After assembling the board and troubleshooting with my multimeter, I found that there was problem with the large IC (pins 10 and 12 had no continuity) and one resistor had less than optimal continuity. All other components worked.
I bought the red version of this last year and ruined it completely; I tried soldering the components roughly the same way I'd solder THT (Through hole) components. The tiny components in the kit stuck to my iron, or I took so long trying to solder them to a pad I'd completely fry them.
I managed to get a bit of formal SMD soldering training in at work, and I studied on techniques. I decided to try this blue version out to try my skills again.
This one turned out better, and the functional LED circuit works. This kit is a heck of a workout if you don't have a microscope though!
I used a jeweler's headband magnifier, which goes to 10x magnification. That level felt like the bare minimum to my eye, any lower magnification power and I couldn't clearly see what I was doing. But since I was wearing a head band to see, I had to slump forward over my rolling workstation toolbox to get in focus. So, if you don't have a microscope, use a headband like I did. An eye loupe will place your face dangerously close to the soldering iron, and you could get solder spatter in your other eye. Even with my headband, I got a few breaths of soldering fumes, so again, a microscope with enough clearance for your soldering iron to get under is very strongly recommended!
I sorted out the components by reading the values on the resistors and comparing the quantities of components that came with the kit to the materials and supplies list that came with the instructions, which have hastily scrawled instructions for SMD soldering but little instruction on how to assemble this kit. Once I got everything sorted out, I soldered the "extra" components on the practice areas. There are a lot of pads, so you'll get PLENTY of practice here. I then went on to solder the components to functional part of the board, soldered lead wires to the + and - pads, and voila! My project lit up!
The finished product is simple in aesthetics and function, so only the individual that solders this kit together is going to get any enjoyment out of watching this light up. So I would only recommend this kit if you want a solid amount of SMD soldering experience outside of formal training. With the right equipment and experience, this kit isn't horribly difficult, but I wouldn't call it easy either!
The description is somewhat lacking, so I'll try to clear up some of the confusion. This is a beginner SMD soldering kit, intended for practice. It includes two "sections" on the front of the board: practice and an LED circuit. The back contains several rulers in standard and metric, a trace-width gauge, and standard SMD component pad patterns for reference.
The first section is is a practice area for various surface mount components, and consists of the three vertical rows on each side of the board. These rows consist of solder pads for four different sizes of SMD parts: 1206, 0805, 0603, and 0402 (Google "SMD sizes" to find out what those numbers mean if you don't already know). The kit includes resistors and capacitors to solder to these rows, and I believe the values are random. These rows aren't electrically connected to the LED circuit, so it's fine if you make mistakes or lose components. They even include a few extra of each, which was good because I managed to lose a few of the 0402 resistors when they slipped out of my tweezers. Those things are TINY.
The second section is the actual LED circuit, and it's located in the center of the board between the two groups of practice rows. It consists of a 4017 decade counter which drives a ring of red LEDs. The LED's light one at a time, chasing around the circle. Four blue LEDs at the corners of the center section pulse on and off together once per revolution (on for half, off for half). A 555 timer provides the pulses to drive the counter, and also illuminates a red LED in the center of the circle with each timing pulse. The circuit incorporates several SOT23 transistors and DO diodes. The ICs are both SOIC packages. The speed and brightness of the LEDs will depend on the input voltage you apply.
ASSEMBLY:
I don't think I could have done this without a good pair of tweezers, some form of hands-free magnification (I love my Brightech - LightView PRO SuperBright 56 LED Magnifier Lamp - Adjustable Swivel Arm - 5 Diopter 5" Lens - Space Saving Clamp - White ), and a fine-tipped soldering iron. Having the right tools for the job is a huge advantage.
My instructions were in English, but not as clear as I'd like. First I separated all the components into the two groups, one for each section (the practice parts and the "real" LED circuit). The component values for the LED circuit are shown on the instructions. They should all be pretty obvious because there are small numbers of most of them. The only confusing one was the strip of 330-Ohm resistors. Make sure you put the strip of resistors marked "331" in the LED circuit pile. After separating the LED circuit parts, you should have 6 leftover strips of resistors and capacitors. These leftover strips should have about 14 components each of the 1206s and 0805s, and about 16 each of the 0603s and 0402s. Start with these and practice your technique. It's probably easiest to start with the larger components and work your way down to the smaller ones. Search online for SMD soldering tutorials if you need to.
Once the practice rows are done, you should be ready for the main circuit. The trickiest part is the polarities of the diodes. Use the picture guide in the instructions and note that the LED polarity symbol is on the underside of the part. For the ICs, solder one corner first, then the opposite corner to hold the part steady. Then solder the rest of the pins. If you accidentally connect two pins, use some solder wick to mop up the excess solder. The wick won't pull the solder from between the IC and the board, so you can make a really clean-looking connection this way.
Lastly, check that power is not shorted to ground (use the continuity mode on your multimeter and test the positive and negative terminals at the bottom of the board). Then hook up the power! I used some alligator clips and a 9v battery (I believe 3V to 12V is recommended).
This was my first SMD project and if I figured it out, you probably can too. If you have any questions, leave a comment and I'll do my best to answer you quickly. Have fun!
Reviewed in the United States 🇺🇸 on April 21, 2016
The description is somewhat lacking, so I'll try to clear up some of the confusion. This is a beginner SMD soldering kit, intended for practice. It includes two "sections" on the front of the board: practice and an LED circuit. The back contains several rulers in standard and metric, a trace-width gauge, and standard SMD component pad patterns for reference.
The first section is is a practice area for various surface mount components, and consists of the three vertical rows on each side of the board. These rows consist of solder pads for four different sizes of SMD parts: 1206, 0805, 0603, and 0402 (Google "SMD sizes" to find out what those numbers mean if you don't already know). The kit includes resistors and capacitors to solder to these rows, and I believe the values are random. These rows aren't electrically connected to the LED circuit, so it's fine if you make mistakes or lose components. They even include a few extra of each, which was good because I managed to lose a few of the 0402 resistors when they slipped out of my tweezers. Those things are TINY.
The second section is the actual LED circuit, and it's located in the center of the board between the two groups of practice rows. It consists of a 4017 decade counter which drives a ring of red LEDs. The LED's light one at a time, chasing around the circle. Four blue LEDs at the corners of the center section pulse on and off together once per revolution (on for half, off for half). A 555 timer provides the pulses to drive the counter, and also illuminates a red LED in the center of the circle with each timing pulse. The circuit incorporates several SOT23 transistors and DO diodes. The ICs are both SOIC packages. The speed and brightness of the LEDs will depend on the input voltage you apply.
ASSEMBLY:
I don't think I could have done this without a good pair of tweezers, some form of hands-free magnification (I love my [[ASIN:B00UW2IRJ2 Brightech - LightView PRO SuperBright 56 LED Magnifier Lamp - Adjustable Swivel Arm - 5 Diopter 5" Lens - Space Saving Clamp - White]]), and a fine-tipped soldering iron. Having the right tools for the job is a huge advantage.
My instructions were in English, but not as clear as I'd like. First I separated all the components into the two groups, one for each section (the practice parts and the "real" LED circuit). The component values for the LED circuit are shown on the instructions. They should all be pretty obvious because there are small numbers of most of them. The only confusing one was the strip of 330-Ohm resistors. Make sure you put the strip of resistors marked "331" in the LED circuit pile. After separating the LED circuit parts, you should have 6 leftover strips of resistors and capacitors. These leftover strips should have about 14 components each of the 1206s and 0805s, and about 16 each of the 0603s and 0402s. Start with these and practice your technique. It's probably easiest to start with the larger components and work your way down to the smaller ones. Search online for SMD soldering tutorials if you need to.
Once the practice rows are done, you should be ready for the main circuit. The trickiest part is the polarities of the diodes. Use the picture guide in the instructions and note that the LED polarity symbol is on the underside of the part. For the ICs, solder one corner first, then the opposite corner to hold the part steady. Then solder the rest of the pins. If you accidentally connect two pins, use some solder wick to mop up the excess solder. The wick won't pull the solder from between the IC and the board, so you can make a really clean-looking connection this way.
Lastly, check that power is not shorted to ground (use the continuity mode on your multimeter and test the positive and negative terminals at the bottom of the board). Then hook up the power! I used some alligator clips and a 9v battery (I believe 3V to 12V is recommended).
This was my first SMD project and if I figured it out, you probably can too. If you have any questions, leave a comment and I'll do my best to answer you quickly. Have fun!
