Linemaster L-2-S Lektro-Lok Rocker Action Foot Switch, Electrical, Single Pedal, Momentary, SPDT Each Side, No Guard, Black

4.3 4.3 out of 5 stars 22 ratings

Operation Mode ON-OFF
Current Rating 10 Amps
Operating Voltage 125 Volts
Contact Type Normally Open
Connector Type Clamp
Brand Linemaster
Terminal Spdt
Item dimensions L x W x H 9 x 6 x 12 inches
Circuit Type Single Pole
Actuator Type Rocker
Switch Type
Rocker
Material
Steel
Mounting Type
Plug In Mount
Specification Met
UL

About this item

  • 10 amp 125-250V, 1/2 HP foot switch for use with light-duty electrical devices
  • Formed steel housing for strength and durability
  • Non-skid base for stability and safety
  • Rocker action mechanical interlock system prevents both circuits from being operated at the same time
  • Integral, adjustable strain relief clamp protects cord (sold separately) from strain or pulling

Product details

  • Product Dimensions ‏ : ‎ 9 x 6 x 12 inches; 11.2 ounces
  • Item model number ‏ : ‎ B005GRDV4Y
  • Date First Available ‏ : ‎ September 30, 2010
  • Manufacturer ‏ : ‎ Linemaster
  • ASIN ‏ : ‎ B005GRDV4Y
  • Customer Reviews:
    4.3 4.3 out of 5 stars 22 ratings

Product Description

This Linemaster L-2-S Lektro-Lok 10 amp, 125-250V, 1/2 HP foot switch has a formed steel housing, non-skid base, and a rocker action switch. This foot switch is suitable for use in applications in which users need hands-free, on-and-off power activation. The foot switch has a rocker action mechanical interlock system that prevents both circuits from being operated at the same time. Pressure on one side opens or closes the line, release of pressure returns the switch to a normal off position, and pressure on the other side opens or closes the circuit, independent of the first. This foot switch has a formed steel housing for strength and durability, and the non-skid base gives the foot switch stability to help prevent sliding on smooth floors. An adjustable strain relief clamp protects the cord (not included) from damage caused by pulling or stretching. It This foot switch is certified by the Canadian Standard Association (CSA), meets United States Underwriters Laboratories (UL) standards for quality assurance, and has an Ingress Protection (IP) rating of 20 for protection against small amounts of dripping water and access with a finger. This momentary operation foot switch is suitable for light-duty applications such as dental chairs, medical tables, microscopes, lifts, cameras, among others.

Specifications

Output10 amp, 125-250VHP1/2MountingNo Circuitry SPDT, Form C contactUnit weight0.65 lb. Dimensions1.21 x 2.75 x 5" (H x W x D)QualityCSA, ULDegree of protectionIP20

*H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back.

Foot switches are used to turn on and off electrical devices and may also provide control over the device's speed and mode of operation. They come with up to three pedals and can have a maintained, momentary, variable, or anti-trip switch action. For maintained action switches, one press of the pedal controls the power, whereas momentary action switches require constant pressure on the pedal for power. Variable action switches (also called foot potentiometers) function similarly to momentary action switches, but also provide control over the connected device's operating speed. Anti-trip action switches require users to release a safety latch before pressing down for momentary action. Foot switches vary in their contact specifications, amp ratings, plugs and receptacles, and material construction to suit different applications, device amperages, plug configurations, and environments. Foot switches are commonly used with power tools, sewing machines, musical instruments, dental equipment, and lighting, and in the construction, laboratory, production, and medical fields, among others.

Linemaster Switch Company manufactures electromechanical, pneumatic, digital, linear Hall effect, and wireless foot switches for use in the industrial, medical, computer, and musical fields, among others. The company, founded in1952, is headquartered in Woodstock, Connecticut, and meets International Organization for Standardization (ISO) 2001:2008 and ISO 13485:2003 standards.

Looking for specific info?

Customer reviews

4.3 out of 5 stars
4.3 out of 5
22 global ratings

Top reviews from the United States

Reviewed in the United States on September 17, 2019
I replaced the foot switch pedal on my chiropractic adjusting table with this new pedal. Works so much better than the worn out switch that it had on it when I bought it. It takes very little pressure to operate it. It'll last a very long time before I'll ever wear it out.
2 people found this helpful
Report
Reviewed in the United States on December 3, 2014
Arrived quickly, in great condition and works perfectly. Very happy.
Reviewed in the United States on November 13, 2023
This is the exact replacement part originally installed by the manufacturer. Sturdy switch for foot operation.
Reviewed in the United States on January 16, 2015
The right part at a good price. Works great!
Reviewed in the United States on January 14, 2015
great buy
Reviewed in the United States on January 28, 2020
Works great!
Reviewed in the United States on March 23, 2018
as described
