Noctua Cooling Solutions
Noctua's premium cooling components are internationally renowned for their superb quietness, exceptional performance and quality.
Product Description
Featuring advanced aerodynamic design measures such as Flow Acceleration Channels and Noctua’s AAO frame, the NF-A4x10 is an award-winning, premium-quality quiet fan in size 40x10mm. The PWM version sports Noctua’s custom-designed NE-FD1 IC for fully automatic speed control via 4-pin fan headers and comes with a Low-Noise Adaptor as well as an OmniJoin Adaptor Set for easy connection to proprietary fan headers. Its superb running smoothness, reference-class SSO2 bearing and Noctua’s trusted premium quality make it an elite choice for the highest demands.
AAO frame
Noctua's AAO (Advanced Acoustic Optimisation) frames feature integrated anti-vibration pads as well as Noctua's proprietary Stepped Inlet Design and Inner Surface Microstructures, both of which further refine the fan's performance/noise efficiency.
|
|
|
|
|
|---|---|---|---|
Flow Acceleration ChannelsThe NF-A4x10 impeller features suction side Flow Acceleration Channels. By speeding up the airflow at the crucial outer blade regions, this measure reduces suction side flow separation and thus leads to better efficiency and lower vortex noise. |
SSO2 BearingThe NF-A4x10 features the further optimised second generation of Noctua's renowned, time-tested SSO bearing. With SSO2, the rear magnet is placed closer to the axis to provide even better stabilisation, precision and durability. |
Integrated Anti-Vibration PadsIntegrated Anti-Vibration Pads made from extra-soft silicone minimise the transmission of minute vibrations while maintaining full compatibility with all standard mounting systems and fan clips used on heatsinks. |
Inner Surface MicrostructuresWith the tips of the fan blades ploughing through the boundary layer created by the Inner Surface Microstructures, flow separation from the suction side of the blades is significantly suppressed, which results in reduced blade passing noise and improved airflow and pressure efficiency. |
Reduced motor hub size
Thanks to its streamlined, compact motor design, the NF-A4x10's motor hub is smaller than with conventional 4cm fans. This allows for more blade surface area and thus contributes to the NF-A4x10's superior airflow and pressure performance.
|
|
|
|
|
|---|---|---|---|---|
| NF-A4x10 PWM | NF-A4x10 FLX | NF-A4x10 5V PWM | NF-A4x10 5V | |
| Connector | 4-pin PWM | 3-pin | 4-pin PWM | 3-pin |
| Voltage | 12V | 12V | 5V | 5V |
| RPM | Max: 5000 / Min: 1000 | 4500 | Max: 5000 / Min: 1000 | 4500 |
| RPM with L.N.A. | 3700 | 3700 | - | - |
| Acoustical Noise | 19,6 dB(A) | 17,9 dB(A) | 19,6 dB(A) | 17,9 dB(A) |
| Acoustical Noise with L.N.A. | 12,9 dB(A) | 12,9 dB(A) | - | - |
| Size | 40x40x10 mm | 40x40x10 mm | 40x40x10 mm | 40x40x10 mm |
| Colour | Brown & Beige | Brown & Beige | Brown & Beige | Brown & Beige |
Compare with similar items
Bought 3 of these to put in a bracket from etsy, as a case mod for the nzxt h1. They are all connected via 3 way splitter and the fans being pwm, i was able to set them to the same fan curve as gpu fans. 1 of the few 3080's that fit in the gen 1 nzxt h1 is the evga 3080 xc3 without any modifications. Put these fans as exhaust to pull the warm air out that the gpu produced while gaming. Temps under load dropped from 75c to 70c. Even when on 80% power, they are still quieter than the gpu fans at 50%. Wish they had a black fan option instead of just brown, but once the back perforated cover is on, you can barely see them. Nice upgrade without breaking the bank, and not having to change to a different pc case.
Images in this review
Top reviews from the United States
There was a problem filtering reviews right now. Please try again later.
Reviewed in the United States 🇺🇸 on July 26, 2022
Move alot of air for being so small
Reviewed in the United States 🇺🇸 on July 26, 2022
Bought 3 of these to put in a bracket from etsy, as a case mod for the nzxt h1. They are all connected via 3 way splitter and the fans being pwm, i was able to set them to the same fan curve as gpu fans. 1 of the few 3080's that fit in the gen 1 nzxt h1 is the evga 3080 xc3 without any modifications. Put these fans as exhaust to pull the warm air out that the gpu produced while gaming. Temps under load dropped from 75c to 70c. Even when on 80% power, they are still quieter than the gpu fans at 50%. Wish they had a black fan option instead of just brown, but once the back perforated cover is on, you can barely see them. Nice upgrade without breaking the bank, and not having to change to a different pc case.
Reviewed in the United States 🇺🇸 on July 26, 2022
Images in this review
Reviewed in the United States 🇺🇸 on September 19, 2022
There are MANY uses to the A4x10. In my case, no pun intended, I have it help exhaust any additional GPU heat away from the CPU's AIO radiator. Is it a massive impact competing against 120x30 and 120x25 fans? Nope. Does it let some of that exhaust go out somewhere else? Yeah, kinda.
Either way, it runs at 5000rpm and sends a bit air around the place. I may get a couple more to direct air against the RAM or M.2 sticks.
If you have a bit more space, the 20mm version offers a bit more oomph
Either way, it runs at 5000rpm and sends a bit air around the place. I may get a couple more to direct air against the RAM or M.2 sticks.
If you have a bit more space, the 20mm version offers a bit more oomph
Images in this review
Reviewed in the United States 🇺🇸 on June 5, 2022
I already had a heatsink for my Samsung EVO 970 Plus NVMe SSD, but I wasn't happy with the temperatures so I bought this Noctua 40mm fan. Here are some numbers:
Heatsink only:
- Cold idle: 43deg C
- Streaming 720p video from Youtube in Firefox: 50deg C
- CrystalDiskMark 8 64GB speed test: 60deg C
Heatsink and Noctua 40mm fan:
- Cold idle: 41deg C
- Streaming 720p video from Youtube in Firefox: 42-43deg C
- CrystalDiskMark 8 64GB speed test: 52deg C
Note that I actually had to go into the bios and REDUCE the fan speed because at idle it was keeping the NVMe drive below 40deg C. I have read a couple of sources that going below 40deg C on NVMe drives will actually reduce the lifespan of the drive. So if you wanted to, you could easily go below 40deg C with this Noctua fan. Mine was only spinning at 2,000 RPM and it was keeping the NVMe drive temps below 40deg C. Also, the fan is silent at the speeds I have ran it.
Heatsink only:
- Cold idle: 43deg C
- Streaming 720p video from Youtube in Firefox: 50deg C
- CrystalDiskMark 8 64GB speed test: 60deg C
Heatsink and Noctua 40mm fan:
- Cold idle: 41deg C
- Streaming 720p video from Youtube in Firefox: 42-43deg C
- CrystalDiskMark 8 64GB speed test: 52deg C
Note that I actually had to go into the bios and REDUCE the fan speed because at idle it was keeping the NVMe drive below 40deg C. I have read a couple of sources that going below 40deg C on NVMe drives will actually reduce the lifespan of the drive. So if you wanted to, you could easily go below 40deg C with this Noctua fan. Mine was only spinning at 2,000 RPM and it was keeping the NVMe drive temps below 40deg C. Also, the fan is silent at the speeds I have ran it.
Images in this review
Reviewed in the United States 🇺🇸 on August 23, 2022
Top reviews from other countries
James Cecil
The best case fan I've EVER bought!
Reviewed in the United Kingdom 🇬🇧 on December 8, 2019
James Cecil
Reviewed in the United Kingdom 🇬🇧 on December 8, 2019
I've built plenty of PCs, and used many different kinds of case fans, but this particular build is a fanless PC that I upgraded to use a second SSD hard drive. I noticed that the temperature was increasing a bit to over 50C - still in the SSD safe zone, but higher than I wanted so decided to add a case fan, accepting that it would probably be quite noisy.
Not so!
This fan comes with all the connectors you could need. I used the Low-Noise Adapter with the extension, and the anti-vibration mounts, and the result is almost silent operation. The fan speed varies properly according to the SYS_FAN output on the motherboard, and the temperature of the SSD drive no longer exceeds 36C.
I have to say a word about presentation, as the packaging is incredible (considering it's a case fan)! The box has to be the most luxurious packaging for a case fan that I've ever seen. The box has flaps on the front and back so you can see the fan and the anti-vibration mounts, and with information about the fan. Opening the box reveals well presented accessories and the fan itself. I feel that the effort spent on packaging (while probably reflected in the price of the fan) reflects really well on the manufacturer.
Overall, while this is not the cheapest case fan around, for me it represents the best value, and the near silent operation was a real surprise. I highly recommend this fan.
Images in this review
Masquerade
Amazing for the size
Reviewed in the United Kingdom 🇬🇧 on September 8, 2020
Mr. R. Greer
Amazing Ender 3 upgrade
Reviewed in the United Kingdom 🇬🇧 on July 8, 2020Mark P.
Can't really go wrong with Noctua fans...
Reviewed in the United Kingdom 🇬🇧 on March 15, 2020
