Noctua NF-F12 PWM, Premium Quiet Fan, 4-Pin (120mm, Brown)
|Price:||+ $5.00 shipping|
|Power Connector Type||4-Pin|
About this item
- Make sure this fits by entering your model number.
- Premium quiet fan, 120x120x25 mm, 12V, 4-pin PWM, max. 1500 RPM, max. 22.4 dB(A), >150,000 h MTTF
- Award-winning 120x25mm fan with Focused Flow frame for high static pressure and superior quiet cooling performance
- Ideal for CPU heatsinks (e.g. Noctua NH-U12(S) series) and water cooling radiators, perfect replacement fan for loud all-in-one (AIO) coolers
- 4-pin PWM version for automatic speed control via 4-pin PWM fan headers, broad 300-1500rpm speed range (1200rpm max. with supplied Low-Noise Adaptor)
- Includes anti-vibration mounts, fan screws, Low-Noise Adaptor, extension cable and y-cable for running two PWM fans on the same header
Frequently bought together
Customers who viewed this item also viewed
Customers who bought this item also bought
Have a question?
Find answers in product info, Q&As, reviews
Your question might be answered by sellers, manufacturers, or customers who bought this product.
Please make sure that you are posting in the form of a question.
Please enter a question.
Teaming up eleven stator guide vanes with a specially conceived seven blade impeller, the NF-F12’s Focused Flow system creates outstanding static pressure and focuses the airflow for superior performance on heatsinks and radiators. At the same time, a wide range of advanced aerodynamic design measures, second generation SSO-Bearing and Noctua’s new, custom designed PWM IC for fully automatic control assures astounding quietness of operation. The NF-F12 comes with modular cabling, integrated anti-vibration pads and two speed settings for full flexibility. Its commanding performance, exhaustive set of features and Noctua’s trusted premium quality make it an elite choice for use on air coolers, radiators and other pressure demanding applications.
Focused Flow frame
Designed for pressure demanding applications such as heatsinks and radiators, the Focused Flow frame features eleven stator guide vanes that straighten, channel and focus the airflow, which allows the NF-F12 to rival the performance of conventional fans running at much faster speeds.
Custom designed for the new Focused Flow frame and to work in tandem with the eleven stator guide vanes, the NF-F12's seven blade Heptaperf impeller has been carefully optimised to achieve a perfect balance between power and quietness.
The NF-F12 is the first fan to feature the further optimised second generation of Noctua's renowned, time-tested SSO bearing. With SSO2, the rear magnet is placed closer to the axis to provide even better stabilisation, precision and durability.
Varying Angular Distance and Vortex Control Notches
The NF-F12's stator guide vanes are set out in Varying Angular Distance and feature Vortex-Control Notches. Both measures help to spread the noise emission over a broader frequency spectrum and thus make the fan's sound pattern more agreeable to the human ear.
Scope of Delivery
Integrated anti-vibration pads
Integrated anti-vibration pads made from extra-soft silicone minimise the transmission of minute vibrations while maintaining full compatibility with all standard screws and other mounting systems.
|NF-F12 PWM||NF-F12 5V PWM||NF-F12 5V||NF-F12 PWM chromax.black.swap|
|Connector||4-pin PWM||4-pin PWM||3-pin||4-pin PWM|
|RPM||Max: 1500 / Min: 300||Max: 1500 / Min: 300||1500||Max: 1500 / Min: 300|
|RPM with L.N.A.||1200||-||-||-|
|Acoustical Noise||22,4 dB(A)||22,4 dB(A)||22,4 dB(A)||22,4 dB(A)|
|Acoustical Noise with L.N.A.||18,6 dB(A)||-||-||-|
|Voltage||12 V||5 V||5 V||12 V|
|Colour||Brown & Beige||Brown & Beige||Brown & Beige||Black with swappable coloured anti-vibration pads|
Compare with similar items
Noctua NF-S12A PWM, Premium Quiet Fan, 4-Pin (120mm, Brown)
Noctua NF-F12 PWM chromax.Black.swap, Premium Quiet Fan, 4-Pin (120mm, Black)
Noctua NF-P14s redux-1500 PWM, High Performance Cooling Fan, 4-Pin, 1500 RPM (140mm, Grey)
Noctua NF-F12 iPPC 3000 PWM, Heavy Duty Cooling Fan, 4-Pin, 3000 RPM (120mm, Black)
|Sold By||AmaMax (USA) Since 1993 l iMBAPrice® Authorized Distributor||Noctua Cooling Solutions||Noctua Cooling Solutions||Noctua Cooling Solutions||Noctua Cooling Solutions|
|Item Dimensions||4.72 x 0.98 x 4.72 inches||4.72 x 0.98 x 4.72 inches||4.72 x 4.72 x 0.98 inches||5.51 x 0.98 x 5.51 inches||4.72 x 4.72 x 0.98 inches|
|Item Weight||7.05 ounces||6.40 ounces||—||5.29 ounces||—|
Top reviews from the United States
There was a problem filtering reviews right now. Please try again later.
Expensive, but quality is great, and they're effective.
Noctua hasn't let me down yet. You could say I'm... a fan.
It's worth noting that both fans do have the low noise adapter installed and are running about ~1200 RPM give or take. Absolute silence. Nothing to hear whatsoever. The F12 is designed for static pressure and in turn it's at home on a radiator. My observed temps have stayed the same within margin of room temperature fluctuations and never once have I heard them. Also of note, on stock fans the H100i sounds like a jet taking off on startup. It's brief but it roars when you come out of standby or power up. Not with these. You will not regret buying these fans.
I had to actually look at the fan to ensure it was on and spinning. I could barely hear it if I pressed my ear against the case. CPU temps? Everything's cool as a cucumber. Yeah, they don't match the black aesthetic of my case, but if you want a silent, quality fan, this is the one you want.
Keep in mind, though, that this is best as a radiator/heatsink fan rather than a standard case fan. If you want something blowing air out the back of your case, take a gander at the NF-S12A (also a fantastic product).
After poking around on the internet, a tech geek site forum section mentioned that this was a very good fan to replace very loud fans. That seemed to fit my bill so I bought it here because it was $15 less than the site they recommended to buy it from. So I swung for the fences and purchased this fan that did not match my build's color scheme at all. After reviewing my own fashion sense.... or lack thereof.... I figured it would fit nicely in it's new home.
I received it mere hours prior to writing this review and the results were fantastic enough to make me write this before more awesomeness destroys my household and the rainbows and puppy-dogs displace all breathable oxygen around my living area where my computer now resides.... in silence.
This fan is seriously quiet. I can barely hear it run at all. My computer resides in the living room where it will be turned into a one-stop-entertainment shop so quiet running is a must. It now makes my computer run quieter than my PS2, PS3 and quite possibly my PS4 which is odd to me.
This fan is easily installed and comes with tabs to attach to the back of the case without tools. It's nice that the manufacturers threw in a two extension cords and a Y-bridge so you can hook more fans together, but be warned that all sound will be sucked out of the room because of how quiet these fans run.
This fan is a great value at $20 and will make your computer exponentially silent. Buy it now.
I like that these come with the the splitter and extra parts. Having had a sleeve bearing gunk up and brick a power supply these sealed bearing fans with the accessories are ABSOLUTELY worth the extra money.
Think of it like this, YES you can save $5 to $8 and get something else but then you might need the splitter which will cost a few more $ anyway. Fans are always an afterthought but after having stuff burn up because of terrible fans (like I did) you'll be willing to spend the extra cash on the fan.
If you'll buy a $300 mobo, $400 graphics card and $200 in RAM why not spend the extra $10 on a good fan?
The quality really might not be there but you'll save money. Personally, I get these not for their looks (because they are super ugly) I get them for performance and reliability.
For me, a casual gamer; they're performing as good as I could expect. Low noise and low temps. I would buy them again. iI fact I did, I've replaced all my fans with them!
Top reviews from other countries
Size 120x120x25 mm
Mounting hole spacing 105x105 mm
Connector 4-pin PWM
Blade Geometry Heptaperf™
Frame Technology Focused Flow™
Rotational Speed (+/- 10%) 1500 RPM
Rotational Speed with L.N.A. (+/- 10%) 1200 RPM
Min. Rotational Speed (PWM, +/-20%) 300 RPM
Airflow 93,4 m³/h
Airflow with L.N.A. 74,3 m³/h
Acoustical Noise 22,4 dB(A)
Acoustical Noise with L.N.A. 18,6 dB(A)
Static Pressure 2,61 mm H₂O
Static Pressure with L.N.A. 1,83 mm H₂O
Max. Input Power 0,6 W
Max. Input Current 0,05 A
Voltage 12 V
MTTF > 150.000 h
Scope of delivery
Low-Noise Adapter (L.N.A.)
30cm Extension Cable
4 Fan Screws
PERFECT for radiators, CPU heatsinks and for front intake next to HDD bays if your not running a raid 10 array of m.2 or SATA 3 1Gb SSD's Bit noisy for me as its at full rpm as I think I made a boo boo but temps came down 20 degrees celcius so I did something better than before
It's worth noting that I use mine as a CPU heatsink fan. In my opinion, the similar Noctua NF-S12A is the marginally better choice as a case fan. It's the same price at this moment in time: Noctua NF-S12A PWM Case Fan 120 mm . The S12A is even quieter than this one, and slightly better at shifting large volumes of air. Whereas the F12 is better at generating static pressure, which is what you would want from a CPU cooler fan. An internet search for 'noctua which fan is right for me?' will take you to Noctua's website with much more detailed information...
But the subtlety above aside, if you're looking for quality, you've probably found the right choice.
as I bought the NF-F12 fan to cool my fan heatsink t his is a big deal as I cannot do it?
searching Amazon and with Google search I found nothing regards Steel Clips if anyone knows where to find them or advice how to please let me know
emailed Noctua direct and advised them of my problem hope they help out
** removed a star so only 4 star, this for the missing Steel Clips
*** update 2/3/18
Noctua posted me 4x Steel clips! received them 7 days after contacting Noctua customer support! (easy 5 Amazon stars for great customer service
Fan is ultra quiet, running on quality bearings, no signs heat build up whatsoever, i have to look at the switch to check that it's on, otherwise you wouldn't know, yes i could have bought one for half the price but noctua make quality products, i leave this on for 6 plus hours after the event, it draws virtually no power that is noticeable on my leisure battery & i am confident in years of trouble free use.
They're whisper-quiet, the engineering quality is amazing and so is the longevity - I've never had one fail, even after >5 years regular usage and despite looking pretty grubby.
The packaging is probably the best I've seen for any product and the included accessories cover silent rubber or screw mounting, an extension cable, and a speed reduction cable (which reduces the minimal noise still further).
