Product Description
Step up to GeForce GTX and enter the incredibly detailed world of DirectX 11 with an NVIDIA GeForce GTX 550 Ti graphics card. Driving up to 6x the gaming performance of previous generation graphics, GeForce GTX 550 Ti transforms your PC into a next-gen gaming rig.
From the Manufacturer
Overview
Step up to GeForce GTX and enter the incredibly detailed world of DirectX 11 with an NVIDIA® GeForce® GTX 550 Ti graphics card. Driving up to 6x the gaming performance of previous generation graphics1, GeForce GTX 550 Ti transforms your PC into a next-gen gaming rig.
PC Gamers trust GeForce GTX to supply them with the graphic ammunition they need to rule their competition. From NVIDIA® 3D Vision™ to Surround multi-monitor gaming, PhysX® and the unbeatable power of NVIDIA® SLI® ñ with GeForce GTX you know you are well armed.
Product Details Frame Buffer Memory 1024MB GDDR5 Memory Interface 192-bit Memory Bandwidth 98.5 GB/s CUDA cores 192 Graphics Clock (MHz) 900 MHz Processor Clock (MHz) 1800 MHz Texture Fill Rate (billion/sec) 28.8 Max Power Consumption 116 W Physical Dimensions 4.376" H x 8.25" Dual Slot Number of Displays Supported 2 DisplayPort No DVI Yes VGA w/ Adapter HDMI Output Yes (HDMI Mini) Graphics Bus PCI Express 2.0 x16 NVIDIA 3D Vision Ready Yes Warranty 3 Year Warranty PNY Part # VCGGTX550TXPB Built for DirectXÆ 11
Enjoy all the visual glory of the latest DirectXÆ 11 blockbuster games like Crysis 2, HAWX 2, and Civilization 5. With massive geometry processing power of the GeForce lets you enjoy incredibly detailed environments and characters.
© 2011 Crytek GmbH. All Rights Reserved. All other trademarks are the property of their respective owners.Built for DirectXÆ 11
With 3x the performance of previous generations1, GeForce lets you crank up the gaming realism.
NVIDIA Endless City image © 2010 NVIDIA Corporation. All Rights Reserved.
1. Compared to GeForce 8800 GT
GeForce Gaming
GeForce delivers performance and technologies for a superb gaming experience ñ from 3D Vision to Surround multi-monitor gaming, PhysX and the unbeatable power of SLI ñ with GeForce you know you've got the best.
Features and Benefits
Microsoft® DirectX® 11 Support
DirectX 11 GPU with Shader Model 5.0 support designed for ultra high performance in the new API's key graphics feature, GPU-accelerated tessellation.
NVIDIA 3D Vision Ready*
GeForce GPU support for NVIDIA 3D Vision, bringing a fully immersive stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses and advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. In addition, you can watch 3D movies and 3D digital photographs in eye popping, crystal-clear quality.
NVIDIA CUDA™ Technology
CUDA technology unlocks the power of the GPU's processor cores to accelerate the most demanding tasks such as video transcoding, physics simulation, ray tracing, and more, delivering incredible performance improvements over traditional CPUs.
NVIDIA PhysX® Technology
Full support for PhysX technology, enabling a totally new class of physical gaming interaction for a more dynamic and realistic experience with GeForce.
NVIDIA SLI Technology**
Industry leading NVIDIA SLI Technology offers amazing performance scaling for the world's premier gaming solution.
32x Anti-aliasing Technology
Lightning fast, high-quality anti-aliasing at up to 32x sample rates obliterates jagged edges.
NVIDIA PureVideo HD Technology***
The combination of high-definition video decode acceleration and post-processing that delivers unprecedented picture clarity, smooth video, accurate color, and image scaling for movies and video.
HDMI Output
HDMI output enables sending both high-definition video and audio signals to an HDTV via a single cable.
Dualñlink DVI Support
Able to drive industry's largest and highest resolution flat-panel displays up to 2560x1600 and with support for High-bandwidth Digital Content Protection (HDCP).
PCI Express 2.0 Support
Designed for the new PCI Express 2.0 bus architecture offering the highest data transfer speeds for the most bandwidth-hungry and 3D applications, while maintaining backwards compatibility with existing PCI Express motherboards for the broadest support.
Package Contains
- NVIDIA GeForce GTX 550 Ti Graphics Card
- Quick Installation Guide
- Installation CD, which includes:
- Detailed Installation Guide
- NVIDIA Graphics Drivers
- PhysX System Software
- 3DVision Software - One DVI-to-VGA adapter
- One Mini HDMI-to-HDMI adapter
- One 6-pin PCIe to Molex power adapter
Minimum System Requirements
- PCI Express® or PCI Express 2.0-compliant motherboard with one dual-width x16 graphics slot
- Two 6-pin PCI Express supplementary power connectors
- A minimum 300W or greater system power supply (with a minimum 12V current rating of 22A)****
- Intel Pentium 4, AMD Athlon XP class processor or higher
- 200MB of available hard disk space
- 2GB system memory (4GB recommended)
- Microsoft Windows XP, Vista, or Windows 7 Operating System (32 or 64-bit)
- DVD-ROM drive for installation
- DVI or HDMI or VGA compatible monitor
Warranty
1 year (will be extended for the lifetime of the original purchaser upon completion of a registration form on PNY's website)
Bonus Movie Download
- Choose from 35 titles - there's something for everyone
- Watch as many times as you want from up to 2 different PCs
* NVIDIA 3D Vision requires NVIDIA 3D Vision glasses and a 3D Vision-Ready display. See www.nvidia.com/surround for more information.
** A GeForce GTX 550 GPU must be paired with another GeForce GTX 550 GPU with the same frame bugger size. SLI requires sufficient system cooling and a compatible power supply. Visit www.slizone.com for more information and a listing of SLI-Certified components.
*** Support video software is required to experience certain features. Visit www.nvidia.com for more details.
**** Minimum system power requirement based on a PC configured with an Intel Core i7 3.2GHz processor
