It is vey difficult to install thick 3/4" cable into the box with big #6-4 wire.
1. Knock out box is needed professional tool to cut it (1" knock out tool set). You can not hammer it out like standard. Be prepare to buy additional tools to cut it.
2.To install big #6 wire is very difficult. I had to pull cable out (cable still inside hole). Install wire to terminal then slowly pull the cable out from box thru bottom hole.
3.If your cable came with #6 ground wire, it won't fit box ground terminal. You would have to trim some strand wire out to fit. If ground wire is #10, it probably OK
4. It is very tricky to put the terminal back inside. It took me a while to do it. The wire is hard and strong.
5. You would need ground and neutral bar adaptor to fit #6 Neutral and ground wire to neutral & ground bar.
#6 wire will not fit existing neutral and ground bar inside electrical panel
I wish there are better box with easy installation. My wire is #6/4 Bulk cable - SOOW jacket 50A. 4W.
It work well. I had to buy Tesla adaptor. It charge about 30 miles/hr. (240v.1ph standard house hold voltage)
| Manufacturer | RVGUARD |
|---|---|
| Part Number | ARGRP50 |
| Item Weight | 4.66 pounds |
| Package Dimensions | 7.01 x 6.89 x 5.28 inches |
| Item model number | ARGRP50 |
| Size | 50 Amp |
| Batteries Included? | No |
| Batteries Required? | No |
