Signstek TL866PLUS Universal USB MiniPro EEPROM Flash BIOS Programmer AVR GAL PIC SPI Support 40 Pin

Visit the Signstek Store

88 ratings

| 52 answered questions

Currently unavailable.

We don't know when or if this item will be back in stock.

This fits your .

Make sure this fits by entering your model number.

Supports a variety of models of 51 series of microcontroller, AVR microcontroller, including ATMEGA series, ATtiny Series, AT90XXX Series MCU, MICROCHIP PIC10 PIC12 PIC16 PIC18 MCU, programming of GAL programmable logic device, SRAM test, 54/74 and CMOS4000 series IC comprehensive function tests.
Support a wide range of chips: All kinds of 26, 27, 28, 29, 37, 39, 49, 50 parallel ROM, EPROM, EEPROM, 24, 25, 35, 85, 93, 95 Series EEPROM, Serial parallel ROM chips, fully supporting to the 48-PIN chips of 64Mbits capacity.
VPP and VCC programming voltages are independently program-controlled: programmable VCC is from 3.3V to 6.5V; VPP is from 3.3V to 18V. The fluctuation of power supply is minor because of the multi-stage LC filter.
Automatically identify the operating system to install and run under WIN 2000/WIN XP/WIN 2003/WIN 2008/WIN VISTA/WIN7.
40PIN universal pin: Don't need to move or turn around the chip when programming.

Specifications for this item

Brand Name	Signstek
Ean	6922302507442
Interface Type	USB , Parallel , SPI
Item Weight	6.4 ounces
Part Number	US-171018-03
Size	TL866CS
Style	TL866CS
UNSPSC Code	32100000
