Micro Firewall Appliance Intel 2.5GbE i225 LAN J4125 Quad Core, 4 Ports Fanless Mini PC Mini Computer 4GB DDR4, 64GB mSATA SSD, Network Gateway Soft Router PC, Support AES NI

Visit the VNOPN Store

4.3 48 ratings

| Search this page

This item cannot be shipped to your selected delivery location. Please choose a different delivery location.

Brand	VNOPN
Operating System	Pf-sense
CPU Model	Celeron
CPU Speed	2 GHz
Cache Size	4 MB
Graphics Card Description	Integrated
Memory Storage Capacity	64 GB
Memory Slots Available	1
Specific Uses For Product	Education
Personal computer design type	Mini PC

About this item

【Stable Processor & OS】This 4 nic mirco pc uses Intel Quad cores J4125 Processor, up to 2.7GHz, supports AES NI. It tested with win 10, linux ubuntu and other popular open source firewall router software. Support Auto Power On, Wake on LAN, RTC wake and PXE boot ("DEL" key to enter BIOS)
【4x Intel 2.5GbE Ethernet Ports】This fanless mini pc all uses Intel i225 chip, supports 4x 2.5 Gigabit ethernet to keep stable and high speed(the device would work at 1G if the system installed is Pfsense.). It has a good compatibility for soft routing, home firewall and other network appliances. This compact pc has more I/O Interface to meet your more needs: 1x HDMI, 1x VGA, 4x RJ45 LAN, 2x USB3.0, 1x DC IN
【High Capacity Storage】This small firewall box comes with 4GB DDR4 RAM and 64GB mSATA SSD. The memory has 1x sodimm slot, max support to 16GB. The storage is 1x mSATA, max support to 512GB. Large storage can meet the vpn router box requirements of different network security firewall software and hypervisor applications
【Portable & Silent】This small form factor PC built for micro firewall appliance and edge router use, it’s only 5.27 x 5 x 1.43 inch and 0.6kg and has a mounting bracket that allows it to be hung on the back of the monitor or TV to save more space. In addition, this mini computer uses fanless passive cooling design and has low power consumption to save energy and 24/7 hours quiet running
【 Package List & Service】1x Vnopn firewall hardware, 1x 12V/3A power adapter, 1x US power plug, 1x user manual, 1x Back mount bracket & Screws. If you have any questions, we will provide you with a satisfactory solution.More info. please visit our store

› See more product details

Report an issue with this product or seller

Note: Products with electrical plugs are designed for use in the US. Outlets and voltage differ internationally and this product may require an adapter or converter for use in your destination. Please check compatibility before purchasing.

Consider a similar item

Dell OptiPlex 7050 Micro Computer, Intel Quad Core i5-6500T up to 3.1GHz, 16G DDR4, 256G SSD, Windows 10 Pro 64 Bit-Multi-Language Supports English/Spanish/French(Renewed)

(514)

$123.00

Climate Pledge Friendly

Brief content visible, double tap to read full content.

Full content visible, double tap to read brief content.

Videos for similar products

Looking for specific info?

Customer reviews

48 global ratings

How customer reviews and ratings work

Customers say

Customers like the functionality, build quality, and ease of setup of the computer. They mention it works well, is sturdy, and well-protected. However, some customers have reported that the computer won't boot to Sophos UTM.

AI-generated from the text of customer reviews

Select to learn more

Functionality Build quality Ease of setup Boot speed

6 customers mention "Functionality"6 positive0 negative

Customers are satisfied with the functionality of the computer. They mention it works well and handles the senses fine.

"Device is running great with no hiccups so far, 65days of uptime on pfsense...." Read more

"...Loaded both pfsense and opnsense on the box - both run fantastically well, the only oddity was that opnsense numbers the ports in the reverse order..." Read more

"This thing worked great for the first year I had it, but i'm already having to replace it...." Read more

"...and installed opnsense firewall on it, was easy to do and it handles opnsense fine." Read more

4 customers mention "Build quality"3 positive1 negative

Customers like the build quality of the computer. They mention it's sturdy, stable, and well-protected.

"...Built sturdy, competitively priced, and it has been ticking along for several weeks. Very stable." Read more

"...The packaging is quite nice and it’s well protected...." Read more

"...So I replaced the ram. Still random crashes. I replaced the hard drive. Still same, random crashes. Often times I can not get the unit to post...." Read more

"Solid box, some quirks..." Read more

4 customers mention "Ease of setup"4 positive0 negative

Customers find the setup of the computer easy. They mention they had no issues with the initial setup and connection to the device. Some say everything is easy with the keyboard, except they were unable to select the time zone.

"...I had no issues with initial setup and connection to the device. It boots to Windows 10 (unlicensed)...." Read more

"...Everything was easy with the keyboard except I was unable to select the time zone. Easily solvable after the install...." Read more

"...The packaging is quite nice and it’s well protected. Setting up pFSense was a breeze and it immediately resulted in full 1.2-1.4gbps download..." Read more

"...this as a prime day sale and installed opnsense firewall on it, was easy to do and it handles opnsense fine." Read more

3 customers mention "Boot speed"0 positive3 negative

Customers are dissatisfied with the boot speed of the computer. They mention it boots every time to a grub prompt and won't take a Sophos UTM install.

"...I changed BIOS settings to legacy, and it still will not boot to Sophos. I tried Opnsense, and it locks with boot...." Read more

"...Power button illuminates as well as the nic ports, but won't boot. No video output from hdmi. A few seconds later it just shuts itself back off...." Read more

"...No BIOS, no boot... nothing. Reseated the memory, SSD. Attempted to clear the CMOS, but nothing seems to make a difference." Read more

Reviews with images

See all photos

Sort reviews by

Top reviews from the United States

There was a problem filtering reviews right now. Please try again later.

Raphael

Running pfsense great for 2months+ so far. Reliable uptime.

Reviewed in the United States on January 22, 2024

Size: 4G DDR4 64G SSDVerified Purchase

Device is running great with no hiccups so far, 65days of uptime on pfsense. Way to go as an improvement from running pfsense on hyper-v, where windows updates would put my network down every week.
I'm glad with this little micropc/appliance now, much more reliable setup.
To be honest, I did got some problems turning python-mode on pfsense pfblockerng, while I did not have this problem on the same setup but running in diferent hardware. But I'll give it the doubt of the issue being some other software bug.

One person found this helpful

Helpful

Vinnie J

Solid MiniPC - pfSense Compatible

Reviewed in the United States on March 30, 2021

Verified Purchase

I purchased the 8GB RAM/128GB SSD version of this product to run a home firewall. Overall initial impression was great when I applied power to the unit. I had no issues with initial setup and connection to the device. It boots to Windows 10 (unlicensed). I made a backup and then restarted the device and adjusted the boot order to load from a USB stick. Zero issues as far as that was concerned. Loaded pfSense to the SSD and have not turned back.

Just for fun, I decided to try enabling the wireless adapter so I can manage my firewall from my phone. No issues with version 2.5.0-RELEASE.

4 people found this helpful

Helpful

Nick Claypool

Humming along

Reviewed in the United States on July 26, 2024

Size: 8G DDR4 128G SSDVerified Purchase

This fanless micro firewall appliance was exactly what I was looking for. Built sturdy, competitively priced, and it has been ticking along for several weeks. Very stable.

Helpful

Tyler Pomerhn

Solid box, some quirks

Reviewed in the United States on August 24, 2022

Size: 8G DDR4 128G SSDVerified Purchase

I purchased one of these to test its applicability for pfsense/opnsense in a Caribbean environment (think - hot and humid, and remote, so no moving parts to fail over time, and high heat tolerance).

Loaded both pfsense and opnsense on the box - both run fantastically well, the only oddity was that opnsense numbers the ports in the reverse order (i.e. ige0 -> port 4 instead of ige0 -> port 1). I hope that won't impact the long-term upgradability of the unit (i.e. upgrade to new opnsense and it numbers the ports as pfsense does, or vice versa, which would break all connections because cables would be in the wrong ports).

The unit did not come with a VESA mount, as advertised, but that's okay as I don't plan on using that anyways. The unit also has some odd things on the motherboard - there is a second MSATA port but it doesn't work even though there's a second SATA port listed in the BIOS (which, I suppose, is the standard black SATA port on the motherboard, even though there's no provision for a 2.5" disk in this enclosure, as other similar units do). There's also a listed USB and COM interface in the BIOS, which are present on the motherboard but not pinned/cabled/used, and two SIM slots that are empty and unused.

There's also no documentation online for this unit, and no printed instructions came with it. Can't expect that at this price point, but at the same time it would be helpful to know if there was, for instance, a jumper or BIOS setting that would enable the second MSATA port, or why enabling the watchdog timer sends the unit into an endless BIOS reboot spiral until you hold the reset button. No website to download things like manuals or BIOS updates is a risk you have to take on something this inexpensive.

All in all, it's a powerful unit, and if you're looking for a small, fanless pfsense/opnsense/untangle box, this is an excellent choice. But I would urge customers to look at other units like the Protectli, or the HUNSN RJ03, which has all the same basic hardware but also dual NVME slots, dual screen outputs, a slightly faster CPU, and provision for a 2.5" drive, for around $50 more (but the upgrades are worth it, IMO).

12 people found this helpful

Helpful

Shane Lash

Started dying at 1-1/2 years

Reviewed in the United States on October 24, 2024

Size: 8G DDR4 128G SSDVerified Purchase

This thing worked great for the first year I had it, but i'm already having to replace it. I have installed proxmox running PFSense and it worked great for a while, then all of a sudden I would loose internet access.

If I log into proxmox everything looks fine, but I can't access the web UI of PFSense. Reboot PFSense and it will work for a while, and then crash again. I believe my LAN nic is starting to have issues, since I can still access the proxmox web UI (through one of the other onboard nics)just not the PFSense web UI.

I installed OPNsense instead thinking maybe it was a PFSense issue, and boom, same thing. Now the power LED is barely illuminating, and the router only works with a very light load, as soon as im streaming video or downloading at full speed it crashes the NIC and stops internet traffic.

If you are going to use this, maybe buy a USB fan to minimize heat. My guess is the unit got to hot for one of the NICs and now its having issues, but it was able to dissipate the heat to not hurt the processor, but I'm just guessing. Word of warning!

Helpful

Stef

Will it last?!

Reviewed in the United States on January 20, 2024

Size: 4G DDR4 64G SSDVerified Purchase

Best thing for a firewall ever! I think I'll put one or two in the SUV next.

Helpful

Flux Capacitor

Perfect for a sophisticated VPN router

Reviewed in the United States on May 6, 2021

Verified Purchase

I'm primarily using this as a Speedify VPN router. I installed Ubuntu 20 from a bootable USB drive. There are only 2 USB slots and I didn't have a USB hub so I had to install by only using the keyboard. Everything was easy with the keyboard except I was unable to select the time zone. Easily solvable after the install. Buy a USB hub if you plan on using anything more than a keyboard and mouse. I usually only access via VNC so I don't leave the keyboard or mouse plugged in.

2 people found this helpful

Helpful

rfpa1

Small, powerful Mini PC

Reviewed in the United States on July 1, 2023

Size: 4G DDR4 64G SSDVerified Purchase

I 'm using this mini pc with 16g memory and a 512gb drive for PFsense and its working great.
It run warm to hot so I suggest if you can to point some fan to the pc.

Helpful
